Page 2833 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B17478 AB ± COOLINGWATER PUMP CO±9 2825 Author: Date: 2005 SEQUOIA (RM1146U) (f) Install the water inlet and housing assembly with the 2 bolts. Alternately tighten the bolts. Torque: 18 N´m (18

Page 2834 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual CO0IU±07 B05865 Water InletThermostat  Gasket N´m (kgf´cm, ft´lbf) : Specified torque  Non±reusable part 19 (195, 14) CO±10 ± COOLINGTHERMOSTAT 2826 Author: Date: 2005 SEQUOIA (RM1146U) T

Page 2835 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual CO0IV±04 B05866 ± COOLINGTHERMOSTAT CO±11 2827 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL HINT: Removal of the thermostat would have an adverse effect, caus- ing a lowering of cooling efficie

Page 2836 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual CO0IW±08 P08849 CO0929 CO0949 Valve Lift CO±12 ± COOLINGTHERMOSTAT 2828 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION INSPECT THERMOSTAT HINT: The thermostat is numbered with the valve openi

Page 2837 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual CO0IX±05 B07218 Jiggle Valve30°30° ± COOLINGTHERMOSTAT CO±13 2829 Author: Date: 2005 SEQUOIA (RM1146U) INSTALLATION 1. PLACE THERMOSTAT IN WATER INLET HOUSING (a) Install a new gasket to the

Page 2838 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B14807 CO1B9±02 CO±14 ± COOLINGRADIATOR 2830 Author: Date: 2005 SEQUOIA (RM1146U) RADIATOR ON±VEHICLE CLEANING INSPECT FINS FOR BLOCKAGE If fins are clogged, wash them with water or a steam cl

Page 2839 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual CO0IZ±08 CO1242 Radiator Cap Tester Radiator Cap 30° or More B07240 Radiator Cap Tester ± COOLINGRADIATOR CO±15 2831 Author: Date: 2005 SEQUOIA (RM1146U) ON±VEHICLE INSPECTION 1. REMOVE RADIA

Page 2840 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual CO1D2±01 B07246 Radiator Assembly A/T Oil Cooler Hose Engine Under Cover (4WD)Upper Radiator Hose Lower Radiator Hose x 5 N´m (kgf´cm, ft´lbf) : Specified torque 12 (120, 9) No.1 Fan Shroud No.2 F
