Page 1441 of 4323
H23995
RMIL A2020
IM1B±R I18
Ignition SW
Combination Meter
BatteryIG2 A2021
E1 A2025
E2 A2026 B
W±B
W±B B±R
IG2 AM26 5
W±RRSCA OFFB±R
C5 40
C612C624
1H11
1C2
1A3 IGN1
1D6
1F9
1F101A6
1A8 Instrument Panel J/B
Engine Room J/B 1C3
1J7
2C1
2D1AM2BR
W±B
W±B
J8
J/C A
A F10
Fusible Link Block 4
5
BBB±O
IEAirbag Sensor
Assembly
1
W±R
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1239
1433 Author: Date:
2005 SEQUOIA (RM1146U)
WIRING DIAGRAM
Page 1442 of 4323

DI±1240
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1434 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
1 Check RSCA OFF indicator condition.
CHECK:
Turn the ignition switch to the ON position, check the RSCA OFF indicator condition.
RESULT:
The RSCA OFF indicator does not come on when the RSCA OFF switch is
operate (remains off).A
The RSCA OFF indicator remains on when the RSCA OFF switch is not
operate (remains on).B
B Go to step 7.
A
2 Prepare for inspection.
PREPARATION:
CAUTION:
Be sure to perform the following procedures before troubleshooting to avoid unexpected airbag de-
ployment.
(a) Turn the ignition switch LOCK position.
(b) Disconnect the negative (±) terminal cable from the battery, and wait for at least 90 seconds.
(c) Disconnect the connectors from the airbag sensor assembly.
(d) Disconnect the connectors from the steering wheel pad.
(e) Disconnect the connectors from the front passenger airbag assembly.
(f) w/ Side and curtain shield airbag:
Disconnect the connectors from the side airbag assembly LH and RH.
(g) w/ Side and curtain shield airbag:
Disconnect the connectors from the curtain shield airbag assembly LH and RH.
(h) Disconnect the connectors from the front seat outer belt LH and RH.
NEXT
Page 1443 of 4323
I28570
C6
C6±24
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1241
1435 Author: Date:
2005 SEQUOIA (RM1146U)
3 Check battery.
CHECK:
Measure the voltage of the battery.
OK:
Voltage: 11 to 14 V
NG Replace battery.
OK
4 Check combination meter (source voltage).
PREPARATION:
Disconnect the connector from the combination meter.
CHECK:
(a) Turn the ignition switch to the ON position.
(b) Measure the voltage according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
C6±24 ± Body groundIgnition switch ON8 to 14 V
NG Repair or replace wire harness (combination
meter ± battery).
OK
Page 1444 of 4323
H01015G27651H23985
RMILAirbag
Sensor
Assembly A Cowl Wire Combination
Meter
A20B C D
DI±1242
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1436 Author: Date:
2005 SEQUOIA (RM1146U)
5 Check cowl wire (short to B+).
PREPARATION:
Connect the negative (±) terminal cable to the battery, and wait
for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position.
(b) Measure the voltage according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A20±20 (RMIL) ±
Body groundIgnition switch ONBelow 1 V
NG Repair or replace cowl wire.
OK
Page 1445 of 4323

H10600 H01012H01070H24042
Combination
Meter
Airbag
Sensor
Assembly
DTC B1661/44 DLC3
CG TC
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1243
1437 Author: Date:
2005 SEQUOIA (RM1146U)
6 Check airbag sensor assembly.
PREPARATION:
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the bat-
tery, and wait for at least 90 seconds.
(c) Connect the connectors to the airbag sensor assembly
and the combination meter.
(d) Connect the negative (±) terminal cable to the battery,
and wait for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(b) Clear the DTCs stored in memory (see page DI±1147).
(c) Turn the ignition switch to the LOCK position.
(d) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(e) Check the DTCs (see page DI±1147).
OK:
DTC B1661/44 is not output.
HINT:
Codes other than DTC B1661/44 may be output at this time, but
they are not related to this check.
NG Replace airbag sensor assembly
(see page RS±82).
HINT:
If the DTC B1661/44 is output after replacing the airbag sensor
assembly, there may be trouble in the combination meter.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal
To make sure of this, use the simulation method to check (see page DI±1137).
Page 1446 of 4323

DI±1244
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1438 Author: Date:
2005 SEQUOIA (RM1146U)
7 Check connection of connectors.
PREPARATION:
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the battery, and wait for at least 90 seconds.
CHECK:
Check that the connectors are properly connected to the airbag sensor assembly and the combination meter.
OK:
The connectors are connected securely.
NG Connect connector, then go to step 1.
OK
8 Prepare for inspection.
PREPARATION:
CAUTION:
Be sure to perform the following procedures before troubleshooting to avoid unexpected airbag de-
ployment.
(a) Disconnect the connectors from the airbag sensor assembly.
(b) Disconnect the connectors from the steering wheel pad.
(c) Disconnect the connectors from the front passenger airbag assembly.
(d) w/ Side and curtain shield airbag:
Disconnect the connectors from the side airbag assembly LH and RH.
(e) w/ Side and curtain shield airbag:
Disconnect the connectors from the curtain shield airbag assembly LH and RH.
(f) Disconnect the connectors from the front seat outer belt LH and RH.
NEXT
Page 1447 of 4323

H01015G27651H23985
RMILAirbag
Sensor
Assembly A Cowl Wire Combination
Meter
A20B C D
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1245
1439 Author: Date:
2005 SEQUOIA (RM1146U)
9 Check combination meter.
PREPARATION:
Connect the negative (±) terminal cable to the battery, and wait for at least 2 seconds.
CHECK:
Turn the ignition switch to the ON position, and check the RSCA OFF indicator condition.
OK:
The RSCA OFF indicator comes on when the RSCA OFF switch is ON.
NG Go to combination meter system
(see page DI±1610).
OK
10 Check cowl wire (short to ground).
PREPARATION:
(a) Turn the ignition switch to the LOCK position.
(b) DIsconnect the negative (±) terminal cable from the bat-
tery, and wait for at least 90 seconds.
(c) Disconnect the connector from the combination meter.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A20±20 (RMIL) ±
Body groundAlways1 MW or higher
NG Repair or replace cowl wire.
OK
Page 1448 of 4323
H22564H23040I27704H23986
Combination
Meter
C5±40RMILA20
C6
A
B C DAirbag
Sensor
Assembly
Cowl Wire
DI±1246
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1440 Author: Date:
2005 SEQUOIA (RM1146U)
11 Check cowl wire (airbag sensor assembly ± combination meter).
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A20±20 (RMIL) ± C5±40AlwaysBelow 1 W
NG Repair or replace cowl wire.
OK
Replace airbag sensor assembly (see page RS±82).
