Page 3129 of 4323

SA2352
R04323
Z00699
Proper ContactHeel Contact
Toe ContactFace Contact
Flank Contact Select an adjusting washer that will bring the
drive pinion closer to the ring gear.
Select an adjusting washer that will shift the
drive pinion away from the ring gear.
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±125
3121 Author: Date:
2005 SEQUOIA (RM1146U) 86 2.86 (0.1126)
18 3.18 (0.1252)±
88 2.88 (0.1134)20 3.20 (0.1260)±
11. INSTALL BEARING CAP
(a) Align the matchmarks on the cap and carrier.
(b) Install and torque the 4 bolts.
Torque: 113 N´m (1,150 kgf´cm, 83 ft´lbf)
HINT:
After giving the ring gear 5 rotations or more, recheck the back
lash.
12. MEASURE TOTAL PRELOAD
Using a torque wrench, measure the total preload with the teeth
of the drive pinion and ring gear in contact.
Total preload (at starting):
Drive pinion preload plus 0.4 ± 0.6 N´m (4 ± 6 kgf´cm,
3.5 ± 5.2 in.´lbf)
13. INSPECT TOOTH CONTACT BETWEEN RING GEAR
AND DRIVE PINION
(a) Coat 3 or 4 teeth at three different positions on the ring
gear with red lead primer.
(b) Hold the companion flange firmly and rotate the ring gear
in both directions.
(c) Inspect the teeth pattern.
Page 3130 of 4323

R04554
R11163SST SA±126
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3122 Author: Date:
2005 SEQUOIA (RM1146U)
If the teeth are not contacting properly, use the following table
to select a proper washer for correction.
Washer thickness:
Thickness
Mark mm (in.)Thickness
Mark mm (in.)Thickness
Mark mm (in.)
87 1.87 (0.0736)01 2.01 (0.0791)15 2.15 (0.0846)
88 1.88 (0.0740)02 2.02 (0.0795)16 2.16 (0.0850)
89 1.89 (0.0744)03 2.03 (0.0799)17 2.17 (0.0854)
90 1.90 (0.0748)04 2.04 (0.0803)18 2.18 (0.0858)
91 1.91 (0.0752)05 2.05 (0.0807)19 2.19 (0.0862)
92 1.92 (0.0756)06 2.06 (0.0811)20 2.20 (0.0866)
93 1.93 (0.0760)07 2.07 (0.0815)21 2.21 (0.0870)
94 1.94 (0.0764)08 2.08 (0.0819)22 2.22 (0.0874)
95 1.95 (0.0768)09 2.09 (0.0823)23 2.23 (0.0878)
96 1.96 (0.0772)10 2.10 (0.0827)24 2.24 (0.0882)
97 1.97 (0.0776)11 2.11 (0.0831)25 2.25 (0.0886)
98 1.98 (0.0780)12 2.12 (0.0835)26 2.26 (0.0890)
99 1.99 (0.0783)13 2.13 (0.0839)27 2.27 (0.0894)
00 2.00 (0.0787)14 2.14 (0.0843)28 2.28 (0.0898)
14. REMOVE COMPANION FLANGE (See page SA±113)
15. REMOVE FRONT BEARING (See page SA±113)
16. INSTALL NEW BEARING SPACER, 2 WASHERS AND
FRONT BEARING
(a) Install a new bearing spacer and 2 washers, and place the
front bearing.
(b) Using SST and the companion flange, install the front
bearing then remove the companion flange.
SST 09950±30012 (09951±03010, 09953±03010,
09954±03010, 09955±03030, 09956±03050)
17. INSTALL NEW OIL SEAL
(a) Coat a new oil seal lip with MP grease.
Page 3131 of 4323
R13340
SST
Vinyl Tape
F14486
40 mm
(1.57 in.)
F14485
SST
F14522SST
SA2351
SST
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±127
3123 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Using SST and a plastic hammer, install the oil seal until
its surface is flush with the differential carrier end.
SST 09316±12010, 09649±17010
HINT:
Connect 2 SST with vinyl tape.
18. INSTALL COMPANION FLANGE
(a) Place the companion flange.
(b) Coat the threads of a new nut with hypoid gear oil.
(c) 2WD:
Torque the companion flange nut.
(1) Install the 3 stud bolts so that the heads come out
40 mm (1.57 in.).
(2) Set the SST and install the 3 nuts to the companion
flange.
SST 09213±58013
(3) Using SST to hold the flange, torque the nut.
SST 09330±00021
Torque: 147 N´m (1,500 kgf´cm, 109 ft´lbf)
(d) 4WD:
Using SST to hold the flange, torque the nut.
SST 09330±00021
Torque: 147 N´m (1,500 kgf´cm, 109 ft´lbf)
Page 3132 of 4323

SA2352
SA2352
SA±128
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3124 Author: Date:
2005 SEQUOIA (RM1146U)
19. ADJUST DRIVE PINION PRELOAD
Using a torque wrench, measure the preload of the drive pinion
using the backlash between the drive pinion and ring gear.
Preload (at starting):
New bearing
1.3 ± 1.9 N´m (13 ± 19 kgf´cm, 11.4 ± 16.7
in.´lbf)
Reused bearing
0.8 ± 1.1 N´m (8 ± 11 kgf´cm, 7.0 ± 9.7 in.´lbf)
If the preload is greater than the specified value, replace the
bearing spacer.
If the preload is less than the specified value, retighten the nut
with a force of 13 N´m (130 kgf´cm, 9 ft´lbf) until the specified
preload is reached.
Torque: 451 N´m (4,600 kgf´cm, 333 ft´lbf) or less
If the maximum torque is exceeded while retightening the nut,
replace the bearing spacer and repeat the preload procedure.
Do not loosen the pinion nut to reduce the preload.
20. CHECK TOTAL PRELOAD
Using a torque wrench, measure the total preload with the teeth
of the drive pinion and ring gear in contact.
Total preload (at starting):
Drive pinion preload plus 0.4 ± 0.6 N´m (4 ± 6 kgf´cm,
3.5 ± 5.2 in.´lbf)
21. CHECK RING GEAR BACKLASH
Using a dial indicator, measure the ring gear backlash.
Backlash: 0.13 ± 0.18 mm (0.0051 ± 0.0071 in.)
22. RECHECK TOOTH CONTACT BETWEEN RING GEAR
AND DRIVE PINION (See step 13.)
23. CHECK COMPANION FLANGE RUNOUT
(See page SA±113)
24. STAKE DRIVE PINION NUT
Page 3133 of 4323
SA15R±13
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±129
3125 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
1. INSTALL DIFFERENTIAL CARRIER ASSEMBLY
(a) Install a new gasket.
(b) Install the differential carrier assembly with the 10 washers and nuts.
NOTICE:
Be careful not to damage the installation surface.
Torque: 73 N´m (740 kgf´cm, 54 ft´lbf)
2. CONNECT REAR PROPELLER SHAFT
2WD: See page PR±5
4WD: See page PR±9
3. INSTALL REAR AXLE SHAFTS (See page SA±102)
4. FILL DIFFERENTIAL WITH HYPOID GEAR OIL (See page SA±105)
Page 3134 of 4323
SA0KI±05
F16837
Rear Pneumatic Cylinder
Clip
Air Tube SA±130
± SUSPENSION AND AXLEREAR PNEUMATIC CYLINDER
3126 Author: Date:
2005 SEQUOIA (RM1146U)
REAR PNEUMATIC CYLINDER
COMPONENTS
Page 3135 of 4323

SA2CX±01
F17148260 mm (10.236 in.)
F16838Clip
Center Pin
Slotted
Hole
± SUSPENSION AND AXLEREAR PNEUMATIC CYLINDER
SA±131
3127 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
NOTICE:
Do not extend the pneumatic cylinder by itself. If the
cylinder is fully extended, it cannot be reused.
Do not replenish the pneumatic cylinder by itself with
air.
Do not remove the pneumatic cylinder with air in it.
If reusing the pneumatic cylinder, replace the 2 O±
rings, plate and connector No.2 with new ones.
When installing the pneumatic cylinder, keep the cyl-
inder length 260 mm (10.236 in.) or less.
1. BLEED AIR (See page SA±153)
HINT:
Disconnect the one touch air connector of the height control
valve and bleed the air.
2. REMOVE REAR PNEUMATIC CYLINDER
(a) Jack up the vehicle and support the frame with safety
stands.
NOTICE:
Do the work with the rear axle assy lowered.
Do the work with the shock absorber installed.
(b) Disconnect the height control tube.
(c) Remove the clip on the upper side of the rear pneumatic
cylinder.
HINT:
If the clip cannot be easily removed, thread a wire through
the hole to pull it.
When installing the clip, make sure that the center pin on
the upper side of the rear pneumatic cylinder is in the
slotted hole of the frame.
(d) Remove the rear pneumatic cylinder.
Page 3136 of 4323

F16839
Do not extend
the rear pneumatic
cylinder
Hole
Seating Pin SA±132
± SUSPENSION AND AXLEREAR PNEUMATIC CYLINDER
3128 Author: Date:
2005 SEQUOIA (RM1146U)
HINT:
Perform the following before installation.
When using safety stands and jack:
(1) Jack up the rear axle until the bottom of the rear
pneumatic cylinder touches the rear axle and fit the
seating pin on the lower side of the rear pneumatic
cylinder into the rear axle.
NOTICE:
Do not extend the rear pneumatic cylinder in order to
fit the seating pin into the hole.
Make sure that the seating pin on the lower side of the
rear pneumatic cylinder fits in the hole in the rear
axle.
(2) Remove the safety stands with care not to extend
the rear pneumatic cylinder when jacking down the
vehicle till it sits on the ground.
NOTICE:
Make sure that the diaphragm (rubber part) of the pneumat-
ic cylinder is not deformed.
(3) Start the engine and replenish the rear pneumatic
cylinder with air.
(e) When using a swing arm type lift:
(1) Lower the vehicle till the tires hit the ground, and
continue lowering slowly until the bottom of the rear
pneumatic cylinder touches the rear axle.
(2) Align the seating pin on the cylinder with the hole in
the rear axle and install the rear pneumatic cylinder
on the rear axle.
NOTICE:
Do not extend the rear pneumatic cylinder by lifting
up the rear axle housing after fitting the seating pin.
Make sure that the diaphragm (rubber part) of the
pneumatic cylinder is not deformed.
(3) Lower the lift carefully so as not to extend the rear
pneumatic cylinder.
NOTICE:
Make sure that the diaphragm (rubber part) of the pneumat-
ic cylinder is not deformed.
(4) Start the engine and replenish the rear pneumatic
cylinder with air.
