Page 2953 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual TR0CI±02 F19231 Low Planetary Ring Gear x5Transfer Case Cover Output Shaft Front Needle Roller Bearing Oil Pump Gear Magnet 118 (1,203, 87) Thrust Bearing Race No. 1 N´m (kgf´cm, ft´lbf) : Specifi

Page 2954 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19232   N´m (kgf´cm, ft´lbf) : Specified torque  Non±reusable part  Precoated partTransfer Extension Housing Collar Snap Ring Transfer Output WasherRear Output Shaft Companion Flange 24 (245,

Page 2955 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual TR0DF±01 F19238 F19239 F19240 SST F19241 SST ± TRANSFERTRANSFER ASSEMBLY TR±9 2947 Author: Date: 2005 SEQUOIA (RM1146U) DISASSEMBLY 1. REMOVE FRONT BEARING RETAINER (a) Remove the 5 bolts and f

Page 2956 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19242 F19243 F19244 F19245 F19246 TR±10 ± TRANSFERTRANSFER ASSEMBLY 2948 Author: Date: 2005 SEQUOIA (RM1146U) 6. REMOVE TRANSFER EXTENSION HOUSING (a) Remove the 5 bolts and transfer extension

Page 2957 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19247 F19248 F19249 F19250 F19251 ± TRANSFERTRANSFER ASSEMBLY TR±11 2949 Author: Date: 2005 SEQUOIA (RM1146U) (c) Using a magnetic finger, remove the 2 shift inter±lock pins. 11. REMOVE FRONT

Page 2958 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19253 F19256 F19257 F19258 F19259 TR±12 ± TRANSFERTRANSFER ASSEMBLY 2950 Author: Date: 2005 SEQUOIA (RM1146U) 13. REMOVE REAR NO. 2 STOPPER TRANSFER SHIFT SHAFT 14. REMOVE TRANSFER SHIFT ACTUAT

Page 2959 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19260 F19261 F19262 F19263 F19264 ± TRANSFERTRANSFER ASSEMBLY TR±13 2951 Author: Date: 2005 SEQUOIA (RM1146U) (b) Using a screwdriver, remove the O±ring from the oil pump. NOTICE: Be careful n

Page 2960 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19265 F19266 F19267 Front F19289 F19290 TR±14 ± TRANSFERTRANSFER ASSEMBLY 2952 Author: Date: 2005 SEQUOIA (RM1146U) 19. REMOVE LOW PLANETARY GEAR (a) Using a snap ring expander, remove the snap
