2001 TOYOTA SEQUOIA radio controls

DIDAV±01
± DIAGNOSTICSREAR SEAT ENTERTAINMANT SYSTEM
DI±2081
2275 Author: Date:
2005 SEQUOIA (RM1146U)
SYSTEM DESCRIPTION
1. Outline

As a unique feature of Rear Seat Entertainment (RSE) system, the front and rear seat occupants can
enjoy different audio±visual modes at the same time. Thus, this system offers enhanced entertainment
to the rear seat occupants.

The rear seat occupants can control the audio±visual modes with the remote controller (switch assy),
and listen to audio by using wired or wireless headphones.

The RSE system is controlled by the multi±display controller, and the communication among the audio
head unit, rear display assembly, and DVD player is established via an AVC±LAN (Audio Visual Com-
munication±Local Area Network).
2. Function of Main Component
Television Display Assy

Displays DVD and video images in accordance with video signals from the RSE ECU.

Receives signals from the remote controller and outputs them to the RSE ECU.

Outputs audio signals to the wireless headphones in the form of infrared signals.

Displays the audio±visual control screen.

Displays the adjustment screen.

Displays the diagnosis screen.

The diagnosis screen appears when the diagnosis mode is started on the audio head unit.
Audio Head Unit
w/ Navigation system:
Radio and navigation assy
w/o Navigation system:
Radio receiver assy

Outputs audio signals to the RSE ECU and the stereo component amplifier.

Outputs a request to the RSE ECU to start the diagnosis mode.
RSE ECU (Multi±display Controller)

Processes video and audio signals from the DVD player and video player and audio signals from the
audio head unit, and outputs them to the television display assembly and headphone terminals.

Controls the distribution of the audio±visual mode to the front (audio head unit) and the rear (RSE).
Remote Controller (Switch Assy)Outputs various control signals of the RSE system to the television display assembly in the form of in-
frared signals.
Wireless Headphone

Receives the audio signals from the television display assembly in the form of infrared signals.

Volume adjustment of the wireless headphone can be done by using the volume equipped on the wire-
less headphone.
Headphone Terminal
Outputs audio signals to the wired headphones that are connected.

Adjusts the volume of the wired headphones in accordance with volume control.
VTR TerminalThis terminal is for connecting the video player's video and audio output terminals.

I28598
Multi±display
Controller Sub±assy
LG28
RMUT
IF316
R23
R±W
LG12
LMUT IF34
R23
R±G RMU
MUTE Radio Receiver Assy
19
R19
6
R20 w/o Navigation System:
I28598
Multi±display
Controller Sub±assy
LG28
RMUT
IF316
R23
R±W
LG12
LMUT IF34
R23
R±G RMUT
MUTE Radio and Navigation Assy
19
R27
6
R28 w/ Navigation System:
± DIAGNOSTICSREAR SEAT ENTERTAINMANT SYSTEM
DI±2147
2341 Author: Date:
2005 SEQUOIA (RM1146U)
Mute signal circuit (Radio receiver assy / Radio and navigation
assy ± Multi±display controller sub±assy)
CIRCUIT DESCRIPTION
The multi±display controller sub±assy controls the volume according to the MUTE signal from the radio re-
ceiver assy or radio and navigation assy.
The MUTE signal is sent to reduce noise and a popping sound generated when the mode, etc. is switched.
WIRING DIAGRAM
DIDBK±01

I28480
Combination Meter
SPD G±O 25
C53
R29 J17
J/C
BRadio and Navigation Assy
BG±O
± DIAGNOSTICSNAVIGATION SYSTEM
DI±2291
2485 Author: Date:
2005 SEQUOIA (RM1146U)
Speed signal circuit
CIRCUIT DESCRIPTION
The navigation ECU (built in the radio and navigation assy) receives a vehicle speed signal from the com-
bination meter assy and information about the GPS antenna, and then adjusts vehicle position.
HINT:

A voltage of 12 V or 5 V is output from each ECU and then input to the combination meter. The signal
is changed to a pulse signal at the transistor in the combination meter. Each ECU controls the respec-
tive system based on the pulse signal.

If a short occurs in an ECU, all systems in the speed signal circuit will not operate normally.
WIRING DIAGRAM
DIDDP±01

05_SEQUOIA_U (L/O 0408)
209
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
TONE AND BALANCE
For details about your system's tone and
balance controls, see the description of
your own system.
Tone
How good an audio program sounds to
you is largely determined by the mix of
the treble, midrange, and bass levels. In
fact, different kinds of music and vocal
programs usually sound better with differ-
ent mixes of treble, midrange, and bass.
Balance
A good balance of the left and right stereo
channels and of the front and rear sound
levels is also important.
Keep in mind that if you are listening to
a stereo recording or broadcast, changing
the right/left balance will increase the vol-
ume of one group of sounds while de-
creasing the volume of another.YOUR RADIO ANTENNA
Your vehicle has an antenna printed on
the inside of the rear quarter window.
NOTICE
Attaching the film (especially conduc-
tive or metallic type) on the rear
quarter glass will noticeably reduce
the sensitivity of the radio.
YOUR CASSETTE PLAYER
When you insert a cassette, the exposed
tape should face to the right.
NOTICE
Do not oil any part of the player and
do not insert anything other than cas-
sette tapes into the slot, or the tape
player may be damaged.
YOUR COMPACT DISC PLAYER (type 1)
When you insert a disc, gently push it in
with the label side up. (The player will
automatically eject a disc if the label side
is down.) The player will play from track
1 through the end of the disc. Then it will
play from track 1 again.
NOTICE
Never try to disassemble or oil any
part of the compact disc player. Do
not insert anything other than com-
pact discs into the slot.
The player is intended for use with 12 cm
(4.7 in.) discs only.

05_SEQUOIA_U (L/O 0408)
230
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
CONTROLLER FEATURES
1. ª
º and ªº (DISC/CH/PROG) buttons
2. ª
º and ªº (TUNE/TRACK) buttons
3. ªON/SOURCEº button
4. ªOFFº button1. ª
º and ªº (DISC/CH/PROG) but-
tons
Radio
You can scan only the preset stations for
the band of the front audio system. (For
instructions, see ªÐControls and featuresº
on page 211 in this Section.)
To scan the preset stations:
Push the ª
º or ªº (DISC/CH/PROG)
button. The radio will tune in the next
preset station up or down the band. The
station frequency will appear on the dis-
play.
Cassette tape player
Push the ª
º or ªº (DISC/CH/PROG)
button to select the other side of a cas-
sette tape. The display indicates which
side is currently selected. (ª
º indicates
t he top si de, ª
º indicates the bottom
side.)
Auto±reverse feature: After the cassette
player reaches the end of a tape side, it
automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding.Compact disc player with changer
Use these buttons to select a disc you
want to listen to.
Push the ª
º or ªº (DISC/CH/PROG)
button until the number of the disc you
want to listen appears on the display.
2. ª
º and ªº (TUNE/TRACK) buttons
Radio
Push the ª
º or ªº (TUNE/TRACK) but-
ton to tune or seek.
Tuning:
Quickly push and release the ª
º or ªº
(TUNE/TRACK) button. Each time you
push the button, the radio will step up or
down to another frequency. If you push
and hold the button, and the radio will go
into the seek mode.
Seeking:
Push and hold the ª
º or ªº (TUNE/
TRACK) button. The radio will seek up or
down for a station of the nearest frequen-
cy and will stop on reception. Each time
you push the button, the stations will be
searched one after another.

05_SEQUOIA_U (L/O 0408)
245
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
When you select a mode, the screen indi-
cates which is selected.
Radio
AM mode:
When you select the AM mode, ªAMº will
appear on the screen.
FM mode:
When you select the FM mode, ªFM1º or
ªFM2º will appear on the screen.
Tape mode
ªTAPEº appears on the screen while this
mode is selected.
Compact disc mode
ªCDº appears on the screen while this
mode is selected.
The screen shows the track, or track and
disc number currently being played.
OPERATING FRONT AUDIO SYSTEM
To operate the front audio system, use
the following switches.
1. ª
º and ªº (DISC/CH/PROG) but-
tons
Radio
You can scan only the preset stations for
the band of the front audio system. (For
instructions, see ªÐControls and featuresº
on page 211 in this Section.)
To scan the preset stations:
Push the ª
º or ªº (DISC/CH/PROG)
button. The radio will tune in the next
preset station up or down the band. The
station frequency will appear on the
screen.Cassette tape player
Push the ª
º or ªº (DISC/CH/PROG)
button to select the other side of a cas-
sette tape. The screen indicates which
side is currently selected. (ª
º indicates
t he top si de, ª
º indicates the bottom
side.)
Auto±reverse feature: After the cassette
player reaches the end of a tape side, it
automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding.
Compact disc player with changer
Use these buttons to select a disc you
want to listen to.
Push the ª
º or ªº (DISC/CH/PROG)
button until the number of the disc you
want to listen appears on the display.
