27 Correctly reinstall or replace fuel tank cap.
HINT:
When reinstalling the fuel tank cap, tighten it until a few click sounds are heard.
When replacing the fuel tank cap, use a fuel tank cap that meets OEM specifications, and install it until
a few click sounds are heard.
NEXT Go to step 37.
28 Replace fuel tank cap.
HINT:
When installing the fuel tank cap, tighten it until a few click sounds are heard.
NEXT Go to step 37.
29 Repair EVAP leak part.
(a) Prepare a rubber hose with a 15 to 18.5 mm inside diame-
ter.
(b) Reinstall the fuel tank cap.
(c) Disconnect the atmospheric side hose of the pump mod-
ule.
(d) Connect the rubber tube to the pump module.
(e) Using SST, pinch the rubber tube to close the canister
passage to air.
SST 00002±6872A
(f) Connect a pressure gauge (SST) to the service port
(green cap near the air cleaner box).
(g) Pressurize the EVAP system to 3.2 to 3.7 kPa (24 to 28
mmHg).
(h) Apply soapy water to the piping and connecting parts of
the EVAP system. Look for areas where bubbles appear.
This indicates leaking points.
(i) Repair or replace leaking point.
HINT:
If the system has leaks, a whistling sound will be heard.
Disconnect the hose between the canister and the fuel
tank from the canister. Close the canister hose connected
to the fuel tank, and conduct an inspection. In this way, the
fuel tank can be excluded as an area suspected of caus-
ing fuel leaks.
NEXT Go to step 36.
Page 690 of 4323
DI±488
± DIAGNOSTICSENGINE
682 Author: Date:
2005 SEQUOIA (RM1146U)
30 Replace charcoal canister.
NEXT Go to step 37.
31 Replace EVAP VSV (See page EC±8).
(a) Disconnect the connector and the hoses from the purge VSV.
(b) Remove the purge VSV.
(c) Install a new purge VSV.
(d) Reconnect the connector and hoses.
NEXT Go to step 37.
32 Repair or replace wire harness or connector.
NEXT Go to step 37.
33 Replace EVAP hose between EVAP VSV and throttle body.
NEXT Go to step 37.
34 Inspect throttle body.
(a) Remove the throttle body (see page SF±42).
(b) Check that the EVAP purge port of the throttle body is not clogged. If necessary, replace the throttle
body.
NEXT Go to step 37.
35 Replace ECM (See page SF±80)
NEXT Go to step 37.
Page 691 of 4323

± DIAGNOSTICSENGINE
DI±489
683 Author: Date:
2005 SEQUOIA (RM1146U)
36 Repair or replace parts and components indicated by output DTCs.
(a) Repair the malfunctioning areas indicated by the DTCs that had been confirmed when the vehicle was
brought in.
NEXT Go to step 37.
37 Perform EVAP system auto operation check.
NOTICE:
In the EVAP SYSTEM CHECK (AUTO OPERATION), the series of 4 EVAP SYSTEM CHECK steps
is performed automatically. It takes a maximum of approximately 15 minutes.
Do not perform the EVAP SYSTEM CHECK when the fuel tank is more than 90 % full because
the cut±off valve may be closed and making the leak check of the fuel tank unavailable.
Do not run the engine in this step.
When the temperature of the fuel is 35C (95F) or more, a large amount of vapor forms and any
check results become inaccurate. When performing an EVAP SYSTEM CHECK, keep the tem-
perature below 35C
(95F).
(a) Clear DTCs (see page DI±43).
(b) On the hand±held tester, select the following menu items: DIAGNOSIS / ENHANCED OBD II / SYS-
TEM CHECK / EVAP SYS CHECK / AUTO OPERATION.
(c) After the SYSTEM CHECK is completed, check for pending DTCs by selecting the following menu
items: DIAGNOSIS / ENHANCED OBD II / DTC INFO / PENDING CODES.
HINT:
If no pending DTC is found, the repair has been successfully completed.
NEXT
Completed
Monitor Confirmation
HINT:
After a repair, check Monitor Status by performing the Key±Off Monitor Confirmation and Purge Flow Monitor
Confirmation described below.
1. KEY±OFF MONITOR CONFIRMATION
(a) Preconditions
The monitor will not run unless:
The vehicle has been driven for 10 minutes or more (in a city area or on a free way)
The fuel tank is less than 90 % full
The altitude is less than 8,000 ft (2,400 m)
The Engine Coolant Temperature (ECT) is between 4.4C and 35C (40F and 95F)
The Intake Air Temperature (IAT) is between 4.4C and 35C (40F and 95F)
The vehicle remains stationary (the vehicle speed is 0 mph [0 km/h])
Page 692 of 4323

DI±490
± DIAGNOSTICSENGINE
684 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Monitor Conditions
(1) Allow the engine to idle for at least 5 minutes.
(2) Turn the ignition switch to OFF and wait for 6 hours (8 or 10.5 hours).
HINT:
Do not start the engine until checking MONITOR STATUS. If the engine is started, the steps described above
must be repeated.
(c) Monitor Status
(1) Connect a hand±held tester to the DLC3.
(2) Turn the ignition switch to ON and turn the tester ON.
(3) On the tester, select the following menu items: DIAGNOSIS / ENHANCED OBD II / MONITOR
STATUS.
(4) Check the Monitor Status displayed on the tester.
HINT:
If INCMP is displayed, the monitor is not completed. Make sure that the preconditions have been met, and
perform the Monitor Conditions again.
2. PURGE FLOW MONITOR CONFIRMATION (P0441)
HINT:
Perform this monitor confirmation after the Key±Off Monitor Confirmation shows COMPL (complete).
(a) Preconditions
The monitor will not run unless:
The vehicle has been driven for 10 minutes or more (in a city area or on a free way)
The ECT is between 4.4C and 35C (40F and 95F)
The IAT is between 4.4C and 35C (40F and 95F)
(b) Monitor Conditions
(1) Release the pressure from the fuel tank by removing and reinstalling the fuel tank cap.
(2) Warm the engine up until the ECT reaches more than 75C (167F).
(3) Increase the engine speed to 3,000 rpm once.
(4) Allow the engine to idle and turn A/C ON for 1 minute.
(c) Monitor Status
(1) Turn the ignition switch to OFF (where ON or the engine is running).
(2) Connect a hand±held tester to the DLC3.
(3) Turn the ignition switch to ON and turn the tester ON.
(4) On the tester, select the following menu items: DIAGNOSIS / ENHANCED OBD II / MONITOR
STATUS.
(5) Check the Monitor Status displayed on the tester.
HINT:
If INCMP is displayed, the monitor is not completed. Make sure that the preconditions have been met, and
perform the Monitor Conditions again.
Page 693 of 4323

± DIAGNOSTICSENGINE
DI±491
685 Author: Date:
2005 SEQUOIA (RM1146U)
MONITOR RESULT
Refer to page DI±26 for detailed information.
The test value and test limit information are described as shown in the following table. Check the monitor
result and test values after performing the monitor drive pattern (refer to ºConfirmation Monitorº).
MID (Monitor Identification Data) is assigned to each emissions±related component.
TID (Test Identification Data) is assigned to each test value.
Scaling is used to calculate the test value indicated on generic OBD ll scan tools.
EVAP±Key±off monitor
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$3D$C9Multiply by 0.01
(kPa)Test value for small leak (P0456):
Refer to pressure D*.Minimum test limit for small
leakMaximum test limit for small
leak
$3D$CAMultiply by 0.01
(kPa)Test value for gross leak (P0455):
Refer to pressure E*.Minimum test limit for gross
leakMaximum test limit for gross
leak
$3D$CBMultiply by 0.01
(kPa)Test value for vacuum pump stuck OFF
(P2401):
Refer to pressure A*.Minimum test limit for vacuum
pump stuck OFFMaximum test limit for vacuum
pump stuck OFF
$3D$CDMultiply by 0.01
(kPa)Test value for vacuum pump stuck ON
(P2402):
Refer to pressure A*.Minimum test limit for vacuum
pump stuck ONMaximum test limit for vacuum
pump stuck ON
$3D$CEMultiply by 0.01
(kPa)Test value for vent valve stuck OFF
(vent) (P2420):
Refer to pressure C*.Minimum test limit for vent
valve stuck ONMaximum test limit for vent
valve stuck ON
$3D$CFMultiply by 0.01
(kPa)Test value for vent valve stuck ON
(closed) (P2419):
Refer to pressure A*.Minimum test limit for vent
valve stuck OFFMaximum test limit for vent
valve stuck OFF
$3D$D0Multiply by 0.01
(kPa)Test value for 0.02 inch orifice low flow
(P043E):
Refer to pressure B*.Minimum test limit for 0.02
inch orifice low flowMaximum test limit for 0.02
inch orifice low flow
$3D$D1Multiply by 0.01
(kPa)Test value for 0.02 inch orifice high flow
(P043F):
Refer to pressure A*.Minimum test limit for 0.02
inch orifice high flowMaximum test limit for 0.02
inch orifice high flow
$3D$D4Multiply by 0.01
(kPa)Test value for purge VSV stuck close
(P0441):
Refer to pressure F*.Minimum test limit for purge
VSV stuck closeMaximum test limit for purge
VSV stuck close
$3D$D5Multiply by 0.01
(kPa)Test value for purge VSV stuck open
(P0441):
Refer to pressure E*.Minimum test limit for purge
VSV stuck openMaximum test limit for purge
VSV stuck open
$3D$D7Multiply by 0.01
(kPa)Test value for purge flow (P0441):
Refer to pressure G*.Minimum test limit for purge
flowMaximum test limit for purge
flow
* Pressure A to G are indicated as shown in the diagram below.
Page 694 of 4323
A23517
Key±off Monitor
Purge VSV
Vent Valve
Atmosphere (0 kPa)
Criterion 1 (±1.2 kPa)
Criterion 5 (±4.3 kPa)
Elapsed Time (Seconds)
104EVAP Pressure
(Reference) PumpMonitor Start
ON (Open)
ON (Close)
ON
A
BC
60D
GWithin 720 Criterion 2 (Criterion 4 x 0.2)
Criterion 3 (0.3 kPa)
Criterion 4EF
Criterion 6 (0.3 kPa)
1060
Purge Flow Monitor
Sequence
Purge VSV
Vent Valve
Criterion 7 (0.1 kPa)
EVAP Pressure
(Reference)
Criterion 8 (1kPa)If pressure change in sequence 1 is
greater than criterion 7, purge flow moni-
tor is completed (functioning normally). ON (Close) 12
ON (Open)
If pressure change in sequence 1 is
smaller than criterion 7, sequence 2 is
run.
If pressure change in sequence 2 is
smaller than criterion 8, purge flow is in-
sufficient.
DI±492
± DIAGNOSTICSENGINE
686 Author: Date:
2005 SEQUOIA (RM1146U)
Page 695 of 4323
± DIAGNOSTICSENGINE
DI±493
687 Author: Date:
2005 SEQUOIA (RM1146U)
ECM Power Source Circuit
CIRCUIT DESCRIPTION
When the ignition switch is turned ON, battery positive voltage is applied to terminal IGSW of the ECM and
the EFI relay control circuit in the ECM sends a signal to terminal MREL of the ECM switching on the EFI
relay.
This signal causes current to flow to the coil, closing the contacts of the EFI relay and supplying power to
terminal +B of the ECM.
DID8K±01
Page 696 of 4323
A23555
F10
Fusible
Link
Block9
+B
BatteryE1 1
8
1 E4
E6
BR 4D
B±R
67 I18 Ignition SW 2
W±R 1C 1E
1C2
13
BIG2
IA4
B±WECM
Engine Room J/B
EFI Relay
1DIGSW
MREL E4E4 17 IGN1
4E
Instrument Panel J/BSub J/B No. 4
5
AM2 Instrument Panel J/B
1
16 AM21J
2D
2F2C
2H 5
32
IA4J/C
5 4
B14 12 2
J16
A
EB EDD
J5
J/C W±B2H
2B±R
B±WB±R B±R EFI No. 1W±RB±O
B±O DI±494
± DIAGNOSTICSENGINE
688 Author: Date:
2005 SEQUOIA (RM1146U)
WIRING DIAGRAM
