2001 TOYOTA SEQUOIA Service Repair Manual

wheelbase jacking height checking oil brakes radio controls

Load previous 8 pages

Page 3209 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR0TB±07
F13313
F13314
BR±34
± BRAKEREAR BRAKE PAD
3201 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
1. REMOVE REAR WHEEL
2. INSPECT PAD LINING THICKNESS
Check the pad thickness through the

Page 3210 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F13315
± BRAKEREAR BRAKE PAD
BR±35
3202 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Press in the pistons with a hammer handle or an equiva-
lent.
HINT:
If the piston is difficult to push in, loosen

Page 3211 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR0JR±16
F13303
Brake Caliper
Anti±squeal Shim Inner Pad
Pad Support
PlatePad Support Plate
Outer Pad Anti±squeal Shim
N´m (kgf´cm, ft´lbf): Specified torque
Lithium soap base glycol grease Non�

Page 3212 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR0JS±14
F13316
± BRAKEREAR BRAKE CALIPER
BR±37
3204 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE REAR WHEEL
Torque: 110 N´m (1,122 kgf´cm, 81 ft´lbf)
2. DISCONNECT FLEXIBLE HOSE
R

Page 3213 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR0TC±06
F13317
F13318
F13319
BR±38
± BRAKEREAR BRAKE CALIPER
3205 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
1. REMOVE CYLINDER BOOTS
Using a screwdriver, remove the cylinder boot from t

Page 3214 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR0JU±14
F13320
F13321
F13322
± BRAKEREAR BRAKE CALIPER
BR±39
3206 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. MEASURE PAD LINING THICKNESS
Using a ruler, measure the pad lining thicknes

BR0JU±14
F13320
F13321
F13322
± BRAKEREAR BRAKE CALIPER
BR±39
3206 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. MEASURE PAD LINING THICKNESS
Using a ruler, measure the pad lining thickness.
Standard thickness: 10.0 mm (0.39 in.)
Minimum thickness: 1.0 mm (0.039 in.)
Replace the pad if the pad's thickness is at the minimum or if
it shows signs of uneven wear.
2. MEASURE DISC THICKNESS
(a) Temporarily fasten the disc with the 3 hub nuts.
(b) Using a micrometer, measure the disc thickness.
Standard thickness: 18.0 mm (0.709 in.)
Minimum thickness: 16.0 mm (0.611 in.)
Replace the disc if the thickness of the disc is at the minimum
thickness or less. Replace the disc or grind it on a lathe if it is
scored or is worn unevenly.
3. MEASURE DISC RUNOUT
Using a dial indicator, measure the disc runout at a position 10
mm (0.39 in.) from the outside edge.
Maximum disc runout: 0.1 mm (0.0039 in.)
If the disc's runout is at the maximum value or greater, check the
bearing play is in the axial direction and check the axle hub run-
out (See page SA±95). If the bearing play and axle hub runout
are not abnormal, adjust the disc runout or grind it on an ºOn±
Carº brake lathe.
4. IF NECESSARY, ADJUST DISC RUNOUT
(a) Remove the 2 bolts and torque plate from the backing
plate.
(b) Remove the hub nuts and the disc. Reinstall the disc ro-
tating 1/6 of a turn from its original position on the hub.
Install and torque the hub nuts.
Torque: 110 N´m (1,122 kgf´cm, 81 ft´lbf)
Remeasure the disc runout. Make a note of the runout
and the disc's position on the hub.
(c) Repeat (b) until the disc has been installed on the 4 re-
maining hub positions.
(d) If the minimum runout recorded in (b) and (c) is less than
0.1 mm (0.0039 in.), install the disc in that position.
(e) If the minimum runout recorded in (b) and (c) is greater
than 0.1 mm (0.0039 in.), replace the disc and repeat step
3.
(f) Install the torque plate and tighten the 2 bolts.
Torque: 105 N´m (1,070 kgf´cm, 77 ft´lbf)

Page 3215 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR0JV±09
BR±40
± BRAKEREAR BRAKE CALIPER
3207 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BR±38).
HINT:
Apply lithium soap base

Page 3216 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR0JW±10
± BRAKEREAR BRAKE CALIPER
BR±41
3208 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page BR±37).
HINT:
After installation, fil
