Page 2769 of 4323

SF133±08
B07312
B16540
(a)
(b)
Throttle Body Cover Bracket
(c)
B07045ClampClamp
Clamp
± SFIINJECTOR
SF±27
2761 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. DISCHARGE FUEL SYSTEM PRESSURE
(See page SF±1)
2. REMOVE THROTTLE BODY COVER
3. REMOVE INTAKE AIR CONNECTOR
4. REMOVE FUEL PRESSURE PULSATION DAMPER
Remove the pulsation damper, upper gasket, fuel main hose
and lower gasket.
NOTICE:
Put a shop rag under the delivery pipe.
Slowly loosen the pulsation damper.
5. DISCONNECT PCV HOSE FROM PCV VALVE
6. DISCONNECT VSV FOR EVAP
(a) Disconnect the VSV connector for EVAP.
(b) Disconnect the EVAP hose.
(c) Remove the VSV for EVAP from the intake manifold.
7. REMOVE THROTTLE BODY COVER BRACKET
Remove the bolt and throttle body cover bracket.
8. DISCONNECT ENGINE WIRES
(a) Disconnect the engine wire clamps from the No.1 engine
hanger and engine wire bracket.
(b) Disconnect the 2 wire clamps on the engine wire from the
brackets on the RH delivery pipe.
9. REMOVE DELIVERY PIPES AND INJECTORS
NOTICE:
Be careful not to drop the injectors when removing
the delivery pipes.
Do not apply any load to the injector in horizontal
direction.
Page 2770 of 4323
B17461
Fuel Return Pipe
SF±28
± SFIINJECTOR
2762 Author: Date:
2005 SEQUOIA (RM1146U)
(a) Remove the bolt holding the clamp on the fuel return pipe
to the LH delivery pipe.
(b) Remove the bolt, 2 union bolts, 4 gaskets and front fuel
pipe.
(c) Disconnect the 8 injector connectors.
(d) Remove the 4 nuts holding the delivery pipes to the lower
intake manifold.
(e) Remove the 2 delivery pipes, 8 injectors, and 8 insulators.
(f) Remove the O±ring and grommet from each injector.
Page 2771 of 4323

SF134±04
B07326
SST
InjectorSST
SST
SST
Pressure Regulator
B04988
Pressure Regulator
SST (Hose)
SST (Union)
Fuel Return Hose
B00884
SST
(Adaptor)
SST
(Hose)
SST
(Clamp)
Vinyl
HoseO±Ring
D13872
Hand±Held Tester
DLC3
CAN VIM
± SFIINJECTOR
SF±29
2763 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. INSPECT INJECTOR INJECTION
CAUTION:
Keep the injector clean of sparks during the test.
(a) Disconnect the fuel inlet hose (fuel tube connector) from
the fuel filter.
(b) Connect SST (attachment and hose) to the fuel tube.
SST 09268±41047 (09268±52011)
(c) Remove the pressure regulator from the delivery pipe.
(d) Install the O±ring to the fuel inlet of the pressure regulator.
(e) Connect SST (hose) to the fuel inlet of the pressure regu-
lator with SST (union) and the 2 bolts.
SST 09268±41047 (09268±41091)
Torque: 7.5 N´m (76 kgf´cm, 66 in.´lbf)
(f) Connect the fuel return hose to the fuel outlet of the pres-
sure regulator.
(g) Install the O±ring to the injector.
(h) Connect SST (adaptor and hose) to the injector, and hold
the injector and union with SST (clamp).
SST 09268±41047 (09268±41110, 09268±41300)
(i) Put the injector into the graduated cylinder.
CAUTION:
Install a suitable vinyl hose onto the injector to prevent
gasoline from splashing out.
(j) Connect a hand±held tester to the Controller Area Net-
work Vehicle Interface Module (CAN VIM). Then connect
the CAN VIM to the Date Link Connector 3 (DLC3).
(k) Connect the battery negative (±) cable to the battery.
(l) Turn the ignition switch ON, and push the hand±held tes-
ter main switch ON.
NOTICE:
Do not start the engine.
(m) Enter the following menus: DIAGNOSIS / ENHANCED
OBDII / ACTIVE TEST / FUEL PUMP / SPD
(n) Please refer to the hand±held tester operator's manual
for further details.
Page 2772 of 4323
B00883
ConnectSST
(Wire)
A01293
SF±30
± SFIINJECTOR
2764 Author: Date:
2005 SEQUOIA (RM1146U)
(o) Connect SST (wire) to the injector and battery for 15 se-
conds, and measure the injection volume with a gra-
duated cylinder. Test each injector 2 or 3 times.
SST 09842±30070
Volume: 56 to 69 cm
3 (3.4 to 4.2 cu in.) per 15 seconds
Difference between each injector:
13 cm
3 (0.8 cu in.) or less
If the injection volume is not as specified, replace the injector.
2. INSPECT LEAKAGE
(a) Under the above conditions, disconnect the tester probes
of SST (wire) from the battery and check fuel leakage
from the injector.
SST 09842±30070
Fuel drop: 1 drop or less per 12 minutes
(b) Turn the ignition switch off.
(c) Disconnect the negative (±) terminal cable from the bat-
tery.
(d) Remove the SST and fuel tube connector.
SST 09268±41047, 09842±30070
(e) Disconnect the hand±held tester and CAN VIM from the
DLC3.
(f) Reconnect the fuel inlet pipe to the fuel tube.
Page 2773 of 4323

SF135±06
A01296
New Grommet
New O±Ring
B04439
OutwardTurn
Push
Connector
B17461
Fuel Return Pipe
B04438
Rotate
Outward
Connector
± SFIINJECTOR
SF±31
2765 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
1. INSTALL INJECTORS AND DELIVERY PIPES
NOTICE:
Be careful not to drop the injectors when installing
the delivery pipes.
Do not apply any load to the injector on horizontal
direction.
(a) Install a new grommet to each injector.
(b) Apply a light coat of gasoline to a new O±ring and install
it to each injector.
(c) While turning the injector clockwise and counterclock-
wise, push it to the delivery pipes. Install the 8 injectors.
(d) Position the injector connector outward.
(e) Place the 8 new insulators on the intake manifold.
(f) Place the 2 delivery pipes and injectors assemblies on the
lower intake manifold.
(g) Temporarily install the 4 nuts.
(h) Install the front fuel pipe with the bolt, 4 new gaskets and
2 union bolts.
Torque:
39 N´m (400 kgf´cm, 29 ft´lbf) for union bolts
7.5 N´m (76 kgf´cm, 66 in.´lbf) for bolt
(i) Install the bolt holding the clamp on the fuel return pipe to
the LH delivery pipe.
Torque: 7.5 N´m (76 kgf´cm, 66 in.´lbf)
(j) Check that the injectors rotate smoothly.
HINT:
If the injectors do not rotate smoothly, the probable cause is in-
correct installation of O±rings. Replace the O±ring of the injec-
tor that does not rotate smoothly.
(k) Position injector connector outward.
(l) Tighten the 4 nuts holding the delivery pipes to the lower
intake manifold.
Torque: 21 N´m (214 kgf´cm, 15 ft´lbf)
Page 2774 of 4323
B07534
Clamp
Clamp
B16540
(a)(c)
(b)
Throttle Body Cover Bracket
SF±32
± SFIINJECTOR
2766 Author: Date:
2005 SEQUOIA (RM1146U)
(m) Connect the 8 injector connectors.
2. INSTALL ENGINE WIRES
(a) Install the 2 wire clamps on the engine wire to the brackets
on the RH delivery pipe.
(b) Connect the engine wire clamps to the No.1 engine hang-
er and engine wire bracket.
(c) Install the engine wire protector with the 2 bolts.
3. CONNECT PCV HOSE TO PCV VALVE
4. CONNECT VSV FOR EVAP TO UPPER INTAKE MAN-
IFOLD
(a) Install the VSV for the EVAP to the upper intake manifold.
(b) Connect the EVAP hose.
(c) Connect the VSV connector for the EVAP.
5. INSTALL THROTTLE BODY COVER BRACKET
Install the throttle body cover bracket with the bolt.
6. INSTALL FUEL PRESSURE PULSATION DAMPER
(See page SF±1)
7. INSTALL INTAKE AIR CONNECTOR
8. INSTALL THROTTLE BODY COVER
Page 2775 of 4323
SF0OZ±17
B17462
Fuel Inlet Pipe
Shield
No.1 Fuel Tank Band
N´m (kgf´cm, ft´lbf): Specified torque
Non±reusable part
GasketFuel Pump and
Sender Gauge
Assembly
Fuel TankVent Hose
No.2 Fuel Tank Band
Fuel Inlet Pipe
Fuel Tank Band Pin
62 (632, 45)
Fuel Tank
Protector
Fuel Tank Band Pin
Fuel Return Tube
62 (632, 45)
Fuel Tank
Band Pin
Fuel Tank Band Pin
Recirculation
Tube
Fuel Main Tube
Fuel Pump ConnectorFuel Pump Gauge
Retainer
Fuel Pump Suction
Support
± SFIFUEL TANK AND LINE
SF±33
2767 Author: Date:
2005 SEQUOIA (RM1146U)
FUEL TANK AND LINE
COMPONENTS
CAUTION:
Always use new gaskets when replacing the fuel tank or component parts.
Apply the proper torque to all parts tightened
Page 2776 of 4323
SF1XH±01
B17581
B17582
B17583
SF±34
± SFIFUEL TANK AND LINE
2768 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. DISCHARGE FUEL SYSTEM PRESSURE
(See page SF±1)
2. REMOVE SPARE TIRE
3. DISCONNECT FUEL PUMP CONNECTOR
4. REMOVE FUEL TANK PROTECTOR
Remove the 2 bolts, 2 nuts and fuel tank protector.
5. DISCONNECT FUEL MAIN TUBE AND RETURN TUBE
(See page SF±1)
6. DISCONNECT FUEL TANK VENT HOSE
(a) Push the connector deep into the charcoal canister to re-
lease the locking tab.
(b) Pinch portion A.
(c) Pull out the connector.
7. DISCONNECT INLET HOSE AND BREATHER HOSE
(a) Loosen the hose clamp bolt and disconnect the fuel inlet
hose from the fuel filler pipe.
(b) Disconnect the breather tube. (See page SF±1)
8. REMOVE FUEL TANK ASSEMBLY
(a) Set up a transmission jack under the fuel tank.
(b) Remove the 2 bolts and disconnect the 2 fuel tank bands
from the fuel tank.
(c) Operate the transmission jack and remove the fuel tank.
9. REMOVE FUEL PUMP ASSEMBLY
(See page SF±11)
