± INTRODUCTIONTERMS
40 Author: Date:
2005 SEQUOIA (RM1146U)
TERMS
ABBREVIATIONS USED IN THIS MANUAL
AbbreviationsMeaning
ABSAnti±Lock Brake System
A/CAir Conditioner
ACAlternating Current
ACCAccessory
ACISAcoustic Control Induction System
ACMActive Control Engine Mount
ACSDAutomatic Cold Start Device
A.D.D.Automatic Disconnecting Differential
A/FAir±Fuel Ratio
AHCActive Height Control Suspension
ALRAutomatic Locking Retractor
ALTAlternator
AMPAmplifier
ANTAntenna
APPROX.Approximately
ASSYAssembly
A/T, ATMAutomatic Transmission (Transaxle)
AT FAutomatic Transmission Fluid
AUTOAutomatic
AUXAuxiliary
AV GAverage
AV SAdaptive Variable Suspension
B+Battery Voltage
BABrake Assist
BACSBoost Altitude Compensation System
BATBattery
BDCBottom Dead Center
B/LBi±Level
B/SBore±Stroke Ratio
BTDCBefore Top Dead Center
BVSVBimetallic Vacuum Switching Valve
CBCircuit Breaker
CCoCatalytic Converter For Oxidation
CCVCanister Closed Valve
CDCompact Disc
CFCornering Force
CGCenter Of Gravity
CHChannel
CKDComplete Knock Down
COMB.Combination
CPECoupe
CPSCombustion Pressure Sensor
CPUCentral Processing Unit
CRSChild Restraint System
CTRCenter
C/VCheck Valve
CVControl Valve
CWCurb Weight

DI1AM±35
DI±1578
± DIAGNOSTICSENGINE IMMOBILISER SYSTEM
1772 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
ECM DIAGNOSTIC TROUBLE CODE CHART (MIL)
DTC No.
(See page)Detection ItemTrouble Area
99
(DI±1580)Engine immobiliser system malfunction

Transponder key ECU

ECM

Wire harness
TRANSPONDER KEY ECU DIAGNOSTIC TROUBLE CODE CHART (SECURITY INDICATOR LIGHT)
DTC No.
(See page)Detection ItemTrouble Area
11
(DI±1582)Code 11 is not output

Unlock warning switch

Transponder key ECU

Wire harness
12
(DI±1585)Code 12 is not output

Driver door courtesy lamp switch

Transponder key ECU

Body ECU

Wire harness
13
(DI±1587)Code 13 is not output

Ignition switch

Transponder key ECU

Wire harness
21, 22
(DI±1589)Code 21 or 22 is not output

Key

Transponder key ECU

Transponder key amplifier with key coil

Wire harness
31, 35, 36, 37
(DI±1592)Code 31, 35, 36 or 37 is outputKey
32, 33
(DI±1593)Code 32 or 33 is output

Key

Transponder key ECU

Wire harness
34Code 34 is outputTransponder key ECU has no memory space to register anoth-
er key code
HINT:

DTCs 11, 12, 13, 21 and 22 are normal codes.

As for the normal codes, if the corresponding DTC is not output while operating any of the components
listed under ºTrouble Areaº, perform the inspection described in the reference pages.

DTCs 31, 32, 33, 34, 35, 36, 37 and 99 are abnormal codes.

DI3DP±10
I28395
ECM Transponder Key Coil
Transponder Key Amplifier Instrument
Panel J/B

IGN Fuse
Engine Room J/B

ECU±B Fuse

EFI No. 1 Fuse
Transponder Key ECU
Combination Meter

Security Indicator Light

MIL
DLC3
(Located behind the combination meter)
± DIAGNOSTICSENGINE IMMOBILISER SYSTEM
DI±1579
1773 Author: Date:
2005 SEQUOIA (RM1146U)
PARTS LOCATION

I03114
T6
Transponder Key
Amplifier
13
T16Transponder Key ECU
CODE RXCKTXCT
6
5
45
T16
4
T16 Y±G
LG
R±Y RXCK
CODE TXCT
± DIAGNOSTICSENGINE IMMOBILISER SYSTEM
DI±1589
1783 Author: Date:
2005 SEQUOIA (RM1146U)
Code 21 or 22 is not output
CIRCUIT DESCRIPTION
The transponder key ECU outputs DTC 21 while the immobilizer system is deactivated by use of the master
key, and outputs DTC 22 while it is deactivated by use of the sub key.
HINT:
DTCs 21 and 22 are normal codes.
DTC No.
(See Page)DTC Detecting ConditionTrouble Area
21, 22Communication is normal.

Key

Transponder key ECU

Transponder key amplifier with key coil

Wire harness
WIRING DIAGRAM
DIABG±04

DI±1590
± DIAGNOSTICSENGINE IMMOBILISER SYSTEM
1784 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
1 Check whether the engine can be started with the master key and sub±key for
another vehicle of the same type.
RESULT:
AAll keys start the engine.
BA specific key does not start the engine. In this case, DTC
21 or 22 is not stored in memory.
CAll keys do not start the engine. In this case, DTC 21 and 22
are not stored in memory.
A No problem at this time.
HINT:
If the result is ºAº, confirm whether or not the customer has ever
inserted the key (without a transponder chip) of another vehicle
into the ignition key cylinder.
B The transponder chip of a specific key is defec-
tive. Replace the key.
C
2 Check transponder key coil (See page BE±143).
NG Replace transponder key coil.
OK
3 Check harness and connector between transponder key ECU and transponder
key amplifier (See page IN±35).
NG Repair or replace harness or connector.
OK

DID9K±01
I27726
Radio Receiver Assy
Rear Door Speaker Tweeter
Rear Door Speaker Front Door Speaker (*1)
Front Door Speaker and
Woofer (*2)Steering Pad
Switch
Instrument Panel J/B

RAD NO. 2 Fuse

ECU±B Fuse

AM1 FuseEngine Room J/B

RAD NO. 1 Fuse

RAD NO. 3 Fuse
Ignition Switch
Disc Player
Controller
(*3)
Stereo
Component
AmplifierMulti±display
Controller (*3)
VTR
Terminal
(*3)Headphone
Terminal
(*3, *4)
Television Display Assy (*3)
Rear Seat Audio
Controller Assy (*4)
Radio Sub
Antenna*1: Built±in Type Amplifier
*2: Separate Type Amplifier
*3: w/ RSE System
*4: w/ RSA System Radio Main Antenna
DI±1956
± DIAGNOSTICSAUDIO SYSTEM
2150 Author: Date:
2005 SEQUOIA (RM1146U)
LOCATION

DID9L±01
I28760
Built±in Type Amplifier:
Radio
Receiver
Assy
Steering Pad SwitchSpeakers Sound Signal Operation
Signal
Sound Signal
± DIAGNOSTICSAUDIO SYSTEM
DI±1957
2151 Author: Date:
2005 SEQUOIA (RM1146U)
SYSTEM DIAGRAM

I28735
Separate Type Amplifier:
Steering Pad Switch
AVC±LAN Speakers
Sound SignalOperation
Signal
Radio
Receiver
Assy Stereo
Component
Amplifier
Assy
Multi±display
Controller
Assy (*1)
Rear Seat Audio
Controller (*2)
*1: w/ Rear Seat Entertainment System
*2: w/Rear Seat Audio System
Display Signal DI±1958
