IN0DY±04
B04771
JACK POSITION
Center of rear axle housing
SUPPORT POSITION
Safety stand Front
Center of cross member Front
Rear CAUTION: Do not use the swing arm type lift and plate type lift.
CAUTION: When jacking±up the front and rear, make sure the vehicle is
not carrying any extra weight. IN±8
± INTRODUCTIONREPAIR INSTRUCTIONS
8 Author: Date:
2005 SEQUOIA (RM1146U)
VEHICLE LIFT AND SUPPORT LOCATIONS

IN04Q±33
IN±40
± INTRODUCTIONTERMS
40 Author: Date:
2005 SEQUOIA (RM1146U)
TERMS
ABBREVIATIONS USED IN THIS MANUAL
AbbreviationsMeaning
ABSAnti±Lock Brake System
A/CAir Conditioner
ACAlternating Current
ACCAccessory
ACISAcoustic Control Induction System
ACMActive Control Engine Mount
ACSDAutomatic Cold Start Device
A.D.D.Automatic Disconnecting Differential
A/FAir±Fuel Ratio
AHCActive Height Control Suspension
ALRAutomatic Locking Retractor
ALTAlternator
AMPAmplifier
ANTAntenna
APPROX.Approximately
ASSYAssembly
A/T, ATMAutomatic Transmission (Transaxle)
AT FAutomatic Transmission Fluid
AUTOAutomatic
AUXAuxiliary
AV GAverage
AV SAdaptive Variable Suspension
B+Battery Voltage
BABrake Assist
BACSBoost Altitude Compensation System
BATBattery
BDCBottom Dead Center
B/LBi±Level
B/SBore±Stroke Ratio
BTDCBefore Top Dead Center
BVSVBimetallic Vacuum Switching Valve
CBCircuit Breaker
CCoCatalytic Converter For Oxidation
CCVCanister Closed Valve
CDCompact Disc
CFCornering Force
CGCenter Of Gravity
CHChannel
CKDComplete Knock Down
COMB.Combination
CPECoupe
CPSCombustion Pressure Sensor
CPUCentral Processing Unit
CRSChild Restraint System
CTRCenter
C/VCheck Valve
CVControl Valve
CWCurb Weight

DI±188
± DIAGNOSTICSENGINE
382 Author: Date:
2005 SEQUOIA (RM1146U)
Misfire monitor ± All cylinders
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$A1$0BMultiply by 1
(time)Exponential Weighted Moving Average
misfire counts for last 10 driving cycles
± total
065535
$A1$0CMultiply by 1
(time)Misfire counts for last and current driv-
ing cycles ± total065535
Misfire monitor ± Cylinder 1
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$A2$0BMultiply by 1
(time)Exponential Weighted Moving Average
misfire counts for last 10 driving cycles
± total
065535
$A2$0CMultiply by 1
(time)Misfire counts for last and current driv-
ing cycles ± total065535
Misfire monitor ± Cylinder 2
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$A3$0BMultiply by 1
(time)Exponential Weighted Moving Average
misfire counts for last 10 driving cycles
± total
065535
$A3$0CMultiply by 1
(time)Misfire counts for last and current driv-
ing cycles ± total065535
Misfire monitor ± Cylinder 3
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$A4$0BMultiply by 1
(time)Exponential Weighted Moving Average
misfire counts for last 10 driving cycles
± total
065535
$A4$0CMultiply by 1
(time)Misfire counts for last and current driv-
ing cycles ± total065535
Misfire monitor ± Cylinder 4
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$A5$0BMultiply by 1
(time)Exponential Weighted Moving Average
misfire counts for last 10 driving cycles
± total
065535
$A5$0CMultiply by 1
(time)Misfire counts for last and current driv-
ing cycles ± total065535
Misfire monitor ± Cylinder 5
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$A6$0BMultiply by 1
(time)Exponential Weighted Moving Average
misfire counts for last 10 driving cycles
± total
065535
$A6$0CMultiply by 1
(time)Misfire counts for last and current driv-
ing cycles ± total065535
Misfire monitor ± Cylinder 6
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$A7$0BMultiply by 1
(time)Exponential Weighted Moving Average
misfire counts for last 10 driving cycles
± total
065535
$A7$0CMultiply by 1
(time)Misfire counts for last and current driv-
ing cycles ± total065535

± DIAGNOSTICSENGINE
DI±189
383 Author: Date:
2005 SEQUOIA (RM1146U)
Misfire monitor ± Cylinder 7
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$A8$0BMultiply by 1
(time)Exponential Weighted Moving Average
misfire counts for last 10 driving cycles
± total
065535
$A8$0CMultiply by 1
(time)Misfire counts for last and current driv-
ing cycles ± total065535
Misfire monitor ± Cylinder 8
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$A9$0BMultiply by 1
(time)Exponential Weighted Moving Average
misfire counts for last 10 driving cycles
± total
065535
$A9$0CMultiply by 1
(time)Misfire counts for last and current driv-
ing cycles ± total065535

± DIAGNOSTICSENGINE
DI±463
657 Author: Date:
2005 SEQUOIA (RM1146U)Components
Operations
CanisterContains activated charcoal to absorb EVAP (Evaporative Emissions) generated in fuel tank.
Cut±off valveLocated in fuel tank. Valve floats and closes when fuel tank is 100 % full.
Purge VSV (Vacuum
Switching Valve)Opens or closes line between canister and intake manifold. ECM uses purge VSV to control EVAP purge flow. In order
to discharge EVAP absorbed by canister to intake manifold, ECM opens purge VSV. EVAP discharge volume to intake
manifold controlled by purge VSV duty cycle ratio (current±carrying time). (Open: ON, Close: OFF)
Refueling valve
Controls EVAP pressure from fuel tank to canister. Valve consists of diaphragm, spring and restrictor (diameter: 0.08
inch). When fuel vapor and pressure inside fuel tank increase, valve opens. While EVAP purged, valve closes and re-
strictor prevents large amount of vacuum from affecting pressure in fuel tank. Valve opened while refueling. When valve
open, adding fuel into fuel tank possible.
Roll±over valveLocated in fuel tank. Valve closes by its own weight when vehicle overturns to prevent fuel from spilling out.
Service portUsed for connecting vacuum gauge for inspecting EVAP system.
Soak timerBuilt into ECM. To ensure accurate EVAP monitor, measures 5 hours* after ignition switch turned to OFF. This allows
fuel to cool down, stabilizing Fuel Tank Pressure (FTP). When approx. 5 hours
* elapsed, ECM activates.
Pump moduleConsists of (a) to (d) below. Pump module cannot be disassembled.
(a) Vent valve
Vents and closes EVAP system. When ECM turns valve ON, EVAP system closed. When, ECM turns valve OFF, EVAP
system vented. Negative pressure (vacuum) created in EVAP system to check for EVAP leaks by closing purge VSV,
turning on vent valve (closed) and operating vacuum pump (refer to fig. 1).
(b) Pressure sensorIndicates pressure as voltages. ECM supplies regulated 5 V to pressure sensor, and uses feedback from sensor to
monitor EVAP system pressure (refer to fig 2).
(c) Vacuum pumpCreates negative pressure (vacuum) in EVAP system for leak check.
(d) 0.02 inch orificeHas opening with 0.02 inch diameter. Vacuum produced through orifice by closing purge VSV, turning off vent valve and
operating vacuum pump, to monitor 0.02 inch leak pressure. 0.02 inch leak pressure indicates small leak of EVAP.
HINT:
*:If the engine coolant temperature is not below 35C after 5 hours after the ignition switch is turned off, the
monitor check starts 2 hours later. If it is still not below 35C 7 hours after the ignition switch is turned off,
the monitor check starts 2.5 hours later.

H23981
Occupant
Classification Sensor
Occupant
Classification ECU
Occupant Load
A
A ± A Cross Section
Occupant
Classification Sensor
Occupant
Classification Sensor
A
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1125
1319 Author: Date:
2005 SEQUOIA (RM1146U)
3. DESCRIPTION OF OCCUPANT CLASSIFICATION SYSTEM
(a) GENERAL DESCRIPTION.
(1) In the occupant classification system, the occupant classification ECU calculates the weight of
the occupant based on a signal from the occupant classification sensor. This system recognizes
the occupant to be a child if it detects a weight of less than 36 kg (79.37 lb), and disables the
front and side airbags.
(2) This system is mainly comprised of 4 occupant classification sensors that detect the load on the
front passenger seat. The occupant classification ECU controls the system, and the passenger
airbag ON/OFF indicator indicates the ON/OFF condition of the front passenger airbag assembly
and side airbag assembly (passenger side).
(b) OCCUPANT CLASSIFICATION SENSOR.
The occupant classification sensors are installed on 4 brackets connecting the seat rail and seat frame.
Accordingly, when load is applied to the passenger seat by an occupant sitting in it, the occupant classi-
fication sensors register a distortion.

± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1129
1323 Author: Date:
2005 SEQUOIA (RM1146U)
(5) Perform the sensitivity check by following the
prompts on the tester screen shown in 2 pages lat-
er.
(6) Confirm that the beginning sensor reading is within
the standard value.
OK:
Standard value: ±3.2 to 3.2 kg (±7 to 7 lb)
(7) Place a 30 kg (66.14 lb) weight (eg. a 30 kg (66.14
lb) of lead mass) onto the passenger seat.
(8) Confirm that the sensitivity is within the standard
value.
OK:
Standard value: 27 to 33 kg (59.52 to 72.75 lb)
HINT:

When performing the sensitivity check, use a solid metal
weight (the check result may not appear properly if the
weight made from liquid is used).

When the sensitivity deviates from the standard value, re-
tighten the bolts of the passenger seat taking care not to
deform the seat rail. After performing this procedure, if the
sensitivity is not within the standard value, replace the
front seat assembly RH.

When zero point calibration has not finished normally, re-
place the front seat assembly RH.

SENSITIVITY CHECK PROCEDURE
º1: DIAGNOSISº ± º1: OBD/MOBDº ± ºMODEL YEARº ± ºMODEL SELECTION = SEQUOIAº ±
Select the option parts ± º9: OCCUPANT DETECTº ± Refer to the following screen flow.
DIAGNOSTIC MENU
OCCUPANT DETECT
1: DATA LIST
2: DTC INFO
5: ZERO CALIBRATION
6: SENSITIVITY CHK 4: SNAPSHOT
NOTICE
Please confirm
that nothing is
placed on the
passenger seat.
PRESS [ENTER] or [EXIT]SENSITIVITY CHECK
Beginning sensor
reading should be
±3.2 to 3.2 kg.
PRESS [ENTER]
SENSITIVITY CHECK
PRESS [ENTER]
(±7 to 7 lbs)
Sensor reading
0.00 kg
Place 30 kg (66 lbs)
weight on passenger
seat. Sensor reading
should be 27 to 33 kg.
(59 to 73 lbs)
Sensor reading
0.00 kg*1: kg @ lb
Unit can be changed based on unit conversion setting.
[System Selection Screen]
º1: DIAGNOSISº ± º9: SETUPº ± º4: UNIT CONVERSIONº
± ºWEIGHTº (kg @ lbs) (*1)
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1131
1325 Author: Date:
2005 SEQUOIA (RM1146U)
