2005 SEQUOIA (RM1146U)
REGISTRATION
NOTICE:
The Vehicle Identification Number (VIN) must be input into the replacement ECM.
HINT:
The VIN is in the form of a 17±digit alphanumeric vehicle identification number. A hand±held tester is re-
quired to register the VIN.
1. DESCRIPTION
This registration section consists of three parts, Input Instructions, Read VIN and Write VIN.
(a) Input Instructions: Explains the general VIN input instructions using a hand±held tester.
(b) Read VIN: Explains the VIN reading process in a flowchart. This process allows the VIN stored in the
ECM to be read, in order to confirm that the two VINs, provided with the vehicle and stored in the ve-
hicle's ECM, are the same.
(c) Write VIN: Explains the VIN writing process in a flowchart. This process allows the VIN to be input into
the ECM. If the ECM is changed, or the VIN and VIN do not match, the VIN can be registered, or over-
written in the ECM by following this procedure.
2. INPUT INSTRUCTIONS
(a) Hand±held tester
The arrow buttons (UP, DOWN, RIGHT and LEFT) and numerical buttons (0 to 9) are used, in order
to input the VIN.
(b) Cursor Operation
To move the cursor around the tester screen, press the RIGHT and LEFT buttons.
(c) Alphabetical Character Input
(1) Press the UP and DOWN buttons to select the desired alphabetical character.
(2) After selection, the cursor should move.
(d) Numeric Character Input
(1) Press the numerical button corresponding to the number that you want to input.
(2) Select or input the correct character using the UP/DOWN buttons, or the numerical buttons.
HINT:
Numerical characters can be selected by using the UP and DOWN buttons.
(e) Correction
(1) After input, the cursor should move.
(2) When correcting the input character(s), put the cursor onto the character using the RIGHT or
LEFT buttons.
(f) Finishing Input Operation
(1) Make sure that the input VIN matches the vehicle VIN after input.
(2) Press the ENTER button on the tester.

05_SEQUOIA_U (L/O 0408)
71
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
This system can memorize the position
of the driver's seat and outside rear
view mirrors, and recall them at the
touch of a button.
Buttons ª1º and ª2º can memorize two
separate positions.
SETTING THE DRIVING POSITION
The key must be in the ªONº position and
the shift lever is in the ªPº position.
1. Adjust the driver 's seat and outside
rear view mirrors to the desired
position.
2. While pushing the ªSETº button,
push button ª1º or ª2º until a beep
is heard.
The system can memorize up to 2 posi-
tions by repeating the above steps. If step
2 is performed when both buttons ª1º and
ª2º are memorized, the previous position
will be erased and a new position will be
set.To make only slight changes to an already
memorized position, the easiest way is to
first activate the memorized position, then
make the desired changes and perform
step 2 above.
Driving position memory
system

05_SEQUOIA_U (L/O 0408)
83
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
To connect the extender to the seat
belt, insert the tab into the seat belt
buckle so that the ªPRESSº signs on
the buckle release buttons of the ex-
tender and the seat belt are both facing
outward as shown.
You will hear a click when the tab locks
into the buckle.
When releasing the seat belt, press on
the buckle release button on the extender,
not on the seat belt. This helps prevent
damage to the vehicle interior and extend-
er itself.As far as the seat belt extender on the
front passenger side is concerned, do not
fail to disconnect the extender from the
seat belt after the above operation in or-
der to activate the front passenger airbag
correctly when getting into the vehicle
next time.
When not in use, remove the extender
and store in the vehicle for future use.
CAUTION

After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt and the seat belt extend-
er are not twisted.

Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and
buckle.

If the seat belt does not function
normally, immediately contact your
Toyota dealer. Do not use the seat
until the seat belt is fixed, because
it cannot protect an adult occupant
or your child from injury.
The driver and front passenger seat
belt pretensioners are designed to be
activated in response to a severe fron-
tal impact.
When the sensor detects a severe frontal
impact, the front seat belts are quickly
drawn back by the retractors so that the
belts snugly restrain the occupants.
ÐSeat belt pretensioners

05_SEQUOIA_U (L/O 0408)
211
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Details of specific buttons, controls, and
features are described in the alphabetical
list that follows.
ÐControls and features

Ty p e 1

05_SEQUOIA_U (L/O 0408)
212
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
1 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and
tune in radio stations.
To preset a station to a button: Tune in
the desired station. (See ªTUNEº or
ªSEEK/TRACKº.) Push and hold down the
button until you hear a beepÐthis will set
the station to the button. The button num-
ber will appear on the display.
To recall a preset station: Push the button
for the station you want. The button num-
ber and station frequency will appear on
the display.
These systems can store one AM and two
FM stations for each button. (The display
will show ªAMº, ªFM1º or ªFM2º when you
push ªAMº or ªFMº button.)
(Eject button)
Push the cassette tape eject button to
eject a cassette. Push the compact disc
eject button to eject a compact disc.
(Program)
Push ª
º (preset button 4) to select
the other side of a cassette tape. The
display indicates which side is currently
selected (ª
º indicates the top side, ªº
indicates the bottom side).
Auto±reverse feature: After the cassette
player reaches the end of a tape side, it
automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding.
(Reverse/Fast forward button)
Cassette player
Push ª
º (preset button 6) to fast for-
ward a cassette tape. ªFFº will appear on
the display. Push ª
º (preset button 5)
to rewind a tape. ªREWº will appear on
the display.
To stop the tape while it is fast forward-
ing, push ª
º or ªTAPEº button. To stop
the tape while it is rewinding, push ª
º
or ªTAPEº button.
If a tape rewinds completely, the cassette
player will stop and then play that same
side. If a tape fast forwards completely,
the cassette will play the other side of the
tape using the auto±reverse feature.Compact disc player
Push and hold ª
º (preset button 6) or
ª
º (preset button 5) to fast forward or
reverse within a compact disc. When you
release the button, the compact disc play-
er will resume playing.
AM
Push the ªAMº button to turn on the radio
and select the AM band. ªAMº will appear
on the display.
AUDIO CONTROL (Tone and sound bal-
ance adjustment function)
Each time you push the ªAUDIO
CONTROLº knob, the mode changes. To
adjust the tone and balance, turn the
knob.
BAS: Adjusts low±pitched tones. The dis-
play ranges from ±5 to 5.
MID (on some models): Adjusts mid±
pitched tones. The display ranges from ±5
to 5.
TRE: Adjusts high±pitched tones. The dis-
play ranges from ±5 to 5.
FAD: Adjusts the sound balance between
the front and rear speakers. The display
ranges from F7 to R7.

05_SEQUOIA_U (L/O 0408)
216
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Details of specific buttons, controls, and
features are described in the alphabetical
list that follows.
Ty p e 2

05_SEQUOIA_U (L/O 0408)
217
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
1 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and
tune in radio stations.
To preset a station to a button: Tune in
the desired station. (See ªTUNEº or
ªSEEK/TRACKº.) Push and hold down the
button until you hear a beepÐthis will set
the station to the button. The preset but-
ton number will appear on the display.
RDS stations will be preset to the buttons
when you turn on the RDS (see ªRDSº
button).
To recall a preset station: Push the button
for the station you want. The preset but-
ton number and station frequency will ap-
pear on the display.
This radio can store one AM, two FM and
RDS stations for each button. (The display
will show ªAMº, ªFM1º, ªFM2º or ªFM
TYPEº when you push ªAMº or ªFMº but-
ton.) (Eject button)
Cassette player
This button is used to eject a cassette.
Compact disc player
This button is used to eject one or all
compact discs.
To eject the current compact disc, push
and release the compact disc eject button.
To eject a specific disc, push ªº (preset
button 3) or ª
º (preset button 4) until the
number of the disc you want to eject is
displayed. Push and release the eject but-
ton.
To eject all discs at a time, press and
hold the eject button until you hear a
beep. The last compact disc played before
pushing the button will be ejected first. If
the ejected disc is not removed for a long
time, the eject function will be cancelled. (Program)
Push ª
º (preset button 4) to select
the other side of a cassette tape. The
display indicates which side is currently
selected (ª
º indicates the top side, ªº
indicates the bottom side).
Auto±reverse feature: After the cassette
player reaches the end of a tape side, it
automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding.
(Reverse/Fast forward button)
Cassette player
Push ª
º (preset button 6) to fast for-
ward a cassette tape. ªFFº will appear on
the display. Push ª
º (preset button 5)
to rewind a tape. ªREWº will appear on
the display.
To stop the tape while it is fast forward-
ing, push ª
º or ªTAPEº button. To stop
the tape while it is rewinding, push ª
º
or ªTAPEº button.
If a tape rewinds completely, the cassette
player will stop and then play that same
side. If a tape fast forwards completely,
the cassette will play the other side of the
tape using the auto±reverse feature.

05_SEQUOIA_U (L/O 0408)
218
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Compact disc player
Push and hold ª
º (preset button 6) or
ª
º (preset button 5) to fast forward or
reverse within a compact disc. When you
release the button, the compact disc play-
er will resume playing.
AM
Push the ªAMº button to turn on the radio
and select the AM band. ªAMº will appear
on the display.
AUDIO CONTROL (Tone and sound bal-
ance adjustment function)
Each time you push the ªAUDIO
CONTROLº knob, the mode changes. To
adjust the tone and balance, turn the
knob.
BAS: Adjusts low±pitched tones. The dis-
play ranges from ±5 to 5.
MID: Adjusts mid±pitched tones. The dis-
play ranges from ±5 to 5.
TRE: Adjusts high±pitched tones. The dis-
play ranges from ±5 to 5.
FAD: Adjusts the sound balance between
the front and rear speakers. The display
ranges from F7 to R7.BAL: Adjusts the sound balance between
the right and left speakers. The display
ranges from L7 to R7.
DISC (Compact disc)
Push the ªDISCº button to play a compact
disc.
When the audio system is set into com-
pact disc operation, the display shows the
track, or track and disc number currently
being played.
Vehicles with rear seat entertainment sys-
temÐ
The ªDISCº button may also be used to
operate a DVD player when a disc is
loaded in the DVD player. Pressing the
ªDISCº button changes between the CD
player and DVD player. When the DVD
player is in operation, ªAUXº appears on
the display.
Error messages
If the player malfunctions, your audio sys-
tem will display one of the four following
error messages.
ªWAITº: The compact disc player unit
may be too hot. Allow the player to cool
down.
ªERROR 1º: The disc may be dirty, dam-
aged or inserted incorrectly (up±side
down). Clean the disc and re±insert it.ªERROR 3º: There is a problem inside
the system. Eject the disc or magazine.
Set the disc or magazine again.
ªERROR 4º: Over±current. Ask your
Toyota dealer to inspect.
If the malfunction still exists, take your
vehicle to your Toyota dealer.
 DISC

Use these buttons to select a disc you
want to listen to.
Push ªº (preset button 3) or ª
º (preset
button 4) until the number of the disc you
want to listen appears on the display.
Dolby
B NR*
If you are listening to a tape that was
recorded with Dolby B Noise Reduction,
push ª
º (preset button 3). ªº will
appear on the display. Push the button
again to turn off Dolby B NR.
The Dolby NR mode reduces tape noise
by about 10 dB. For best sound reproduc-
tion, play your tapes with this button on
or off according to the mode used to re-
cord the tape.
*: Dolby noise reduction manufactured under license from
Dolby Laboratories Licensing Corporation. ªDOLBYº and the
double D symbol
are trademarks of Dolby Laboratories
Licensing Corporation.
