Page 409 of 4462

INFINITI FX35 2006 Service Manual REPAIR FOR COMPONENT PARTS AT-325 D E F G H I J K L M A B AT Revision: 2006 December 2006 FX35/FX45 a. Remove needle bearing from high and low reverse clutch hub. 4. Remove rear sun gear a

Page 410 of 4462

INFINITI FX35 2006 Service Manual AT-326 REPAIR FOR COMPONENT PARTS Revision: 2006 December 2006 FX35/FX45 INSPECTION High and Low Reverse Clutch Hub Snap Ring, Rear Sun Gear Snap Ring Check for deformation, fatigue or damage. CAUT

Page 411 of 4462

INFINITI FX35 2006 Service Manual REPAIR FOR COMPONENT PARTS AT-327 D E F G H I J K L M A B AT Revision: 2006 December 2006 FX35/FX45 3. Using a flat-bladed screwdriver, install snap ring to rear sun gear. 4. Install rear

Page 412 of 4462

INFINITI FX35 2006 Service Manual AT-328 REPAIR FOR COMPONENT PARTS Revision: 2006 December 2006 FX35/FX45 8. Check operation of 1st one-way clutch. a. Hold mid sun gear and turn rear sun gear. b. Check 1st one-way clutch for correct

Page 413 of 4462

INFINITI FX35 2006 Service Manual REPAIR FOR COMPONENT PARTS AT-329 D E F G H I J K L M A B AT Revision: 2006 December 2006 FX35/FX45 High and Low Reverse ClutchNCS001IU COMPONENTS VQ35DE models VK45DE models SCIA5223E 1.

Page 414 of 4462

INFINITI FX35 2006 Service Manual AT-330 REPAIR FOR COMPONENT PARTS Revision: 2006 December 2006 FX35/FX45 DISASSEMBLY 1. Remove bearing race from high and low reverse clutch drum. 2. Using a flat-bladed screwdriver, remove snap ring

Page 415 of 4462

INFINITI FX35 2006 Service Manual REPAIR FOR COMPONENT PARTS AT-331 D E F G H I J K L M A B AT Revision: 2006 December 2006 FX35/FX45 3. Install bearing race to high and low reverse clutch drum. CAUTION: Apply petroleum j

Page 416 of 4462

INFINITI FX35 2006 Service Manual AT-332 REPAIR FOR COMPONENT PARTS Revision: 2006 December 2006 FX35/FX45 Direct ClutchNCS001IV COMPONENTS VQ35DE models VK45DE models SCIA7128E 1. Direct clutch drum 2. Driven plate 3. Retaining plate
