2006 INFINITI FX35 Service Manual

warning lights mileage navigation system catalytic converter oil change climate settings

Load previous 8 pages

Page 3993 of 4462

INFINITI FX35 2006 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) PS-45
C
D E
F
H I
J
K L
M A
B
PS
Revision: 2006 December 2006 FX35/FX45
Steering GearNGS000CI
Oil PumpNGS000CJ
Steering FluidNGS000CK
Tie-rod length �

Page 3994 of 4462

INFINITI FX35 2006 Service Manual PS-46
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 December 2006 FX35/FX45

Page 3995 of 4462

INFINITI FX35 2006 Service Manual RAX-1
REAR AXLE
D DRIVELINE/AXLE
CONTENTS
C E F
G H
I
J
K L
M
SECTION RAX
A
B
RAX
Revision: 2006 December 2006 FX35/FX45
REAR AXLE
PRECAUTIONS ..............................................

RAX-1
REAR AXLE
D DRIVELINE/AXLE
CONTENTS
C E F
G H
I
J
K L
M
SECTION RAX
A
B
RAX
Revision: 2006 December 2006 FX35/FX45
REAR AXLE
PRECAUTIONS ..................................................... ..... 2
Caution ................................................................ ..... 2
PREPARATION ...................................................... ..... 3
Special Service Tools (SST) ................................ ..... 3
Commercial Service Tools ................................... ..... 3
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ........................................... ..... 4
NVH Troubleshooting Chart ................................ ..... 4
REAR WHEEL HUB AND KNUCKLE ................... ..... 5
On-Vehicle Inspection ......................................... ..... 5
WHEEL BEARING INSPECTION .................... ..... 5
Removal and Installation ..................................... ..... 5
COMPONENTS ............................................... ..... 5
REMOVAL ........................................................ ..... 5
INSPECTION AFTER REMOVAL .................... ..... 6 INSTALLATION ................................................
..... 6
Disassembly and Assembly ................................. ..... 7
DISASSEMBLY ................................................ ..... 7
INSPECTION AFTER DISASSEMBLY ............. ..... 7
ASSEMBLY ...................................................... ..... 8
INSPECTION AFTER ASSEMBLY ................... ..... 8
REAR DRIVE SHAFT ............................................ ..... 9
Removal and Installation ..................................... ..... 9
COMPONENTS ................................................ ..... 9
REMOVAL ........................................................ ..... 9
INSPECTION AFTER REMOVAL .................... ..... 9
INSTALLATION ................................................ ..... 9
Disassembly and Assembly ................................. ... 10
COMPONENTS ................................................ ... 10
DISASSEMBLY ................................................ ... 10
INSPECTION AFTER DISASSEMBLY ............. ... 11
ASSEMBLY ...................................................... ... 12
SERVICE DATA AND SPECIFICATIONS (SDS) ... ... 15
Wheel Bearing ..................................................... ... 15
Drive Shaft ........................................................... ... 15

Page 3996 of 4462

INFINITI FX35 2006 Service Manual RAX-2
PRECAUTIONS
Revision: 2006 December 2006 FX35/FX45
PRECAUTIONSPFP:00001
CautionNDS000CD
Observe the following precautions when disassembling and servicing drive shaft.
Perform work in a locatio

Page 3997 of 4462

INFINITI FX35 2006 Service Manual PREPARATION RAX-3
C E F
G H
I
J
K L
M A
B
RAX
Revision: 2006 December 2006 FX35/FX45
PREPARATIONPFP:00002
Special Service Tools (SST)NDS000CE
The actual shapes of Kent-Moore tools may diffe

Page 3998 of 4462

INFINITI FX35 2006 Service Manual RAX-4
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
Revision: 2006 December 2006 FX35/FX45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartNDS000CG
Use ch

Page 3999 of 4462

INFINITI FX35 2006 Service Manual REAR WHEEL HUB AND KNUCKLE RAX-5
C E F
G H
I
J
K L
M A
B
RAX
Revision: 2006 December 2006 FX35/FX45
REAR WHEEL HUB AND KNUCKLEPFP:40202
On-Vehicle Inspection NDS000D1
Make sure the mounting

Page 4000 of 4462

INFINITI FX35 2006 Service Manual RAX-6
REAR WHEEL HUB AND KNUCKLE
Revision: 2006 December 2006 FX35/FX45
9. Remove parking brake cable and parking brake shoe from back plate. Refer to PB-6, "PARKING BRAKE
SHOE" and PB-4, "PARKING B

RAX-6
REAR WHEEL HUB AND KNUCKLE
Revision: 2006 December 2006 FX35/FX45
9. Remove parking brake cable and parking brake shoe from back plate. Refer to PB-6, "PARKING BRAKE
SHOE" and PB-4, "PARKING BRAKE CONTROL" .
10. Remove fixing nuts of anchor block with power tool, then remove anchor block and back plate from axle.
11. Loosen fixing bolts and nuts of front lower link, radius rod, and rear lower link in side of suspension mem- ber.
12. Set jack under rear lower link. Then remove fixing bolt in front lower link side of shock absorber with power tool.
13. Remove bolt and nut in axle side of rear lower link with power tool. Then remove coil spring. Refer to RSU-15, "
REAR LOWER LINK & COIL SPRING" .
14. Remove fixing bolts and nuts in axle side of front lower link, radius rod with power tool.
15. Remove suspension arm and cotter pin at axle, then loosen mounting nut.
16. Use a ball joint remover (suitable tool) to remove suspension arm from axle. Be careful not to damage ball joint boot.
CAUTION:
Tighten temporarily mounting nut to prevent damage to threads and to prevent ball joint remover
(suitable tool) from coming off.
17. Remove axle from vehicle.
INSPECTION AFTER REMOVAL
Check for deformity, cracks and damage on each parts, replace if necessary.
Ball Joint Inspection
Check for boot breakage, axial looseness, and torque of suspension arm ball joint. Refer to RSU-11,
"INSPECTION AFTER REMOVAL" .
INSTALLATION
Refer to RAX-5, "Removal and Installation" for tightening torque. Install in the reverse order of removal.
NOTE:
Refer to component parts location and do not reuse non-reusable parts.
Perform final tightening of installation position of suspension links (rubber bushing) under unladen condi-
tions with tires on level ground, Check wheel alignment. Refer to RSU-5, "
Wheel Alignment Inspection" .
After adjusting wheel alignment, adjust neutral position of steering angle sensor. Refer to BRC-6, "Adjust-
ment of Steering Angle Sensor Neutral Position" .
