15. Install snap ring to A/T assembly harness connector.
16. Install magnets in oil pan.
17. Install oil p

Page 442 of 4462

INFINITI FX35 2006 Service Manual AT-358
ASSEMBLY
Revision: 2006 December 2006 FX35/FX45
19. Install torque converter.
a. Pour ATF into torque converter.
Approximately 2 liter (2-1/8 US qt, 1-3/4 Imp qt) of ATF is
required for a ne

Page 443 of 4462

INFINITI FX35 2006 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) AT-359
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 December 2006 FX35/FX45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsNCS001IZ

SERVICE DATA AND SPECIFICATIONS (SDS) AT-359
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 December 2006 FX35/FX45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsNCS001IZ
*1: Refer to MA-12, "Fluids and Lubricants" .
Vehicle Speed at Which Gear Shifting OccursNCS001J0
2WD MODELS
At half throttle, the accelerator opening is 4/8 of the full opening.
AWD MODELS
At half throttle, the accelerator opening is 4/8 of the full opening.
At half throttle, the accelerator opening is 4/8 of the full opening.
Applied model
VQ35DE engine VK45DE engine
2WD AWD
Automatic transmission model RE5R05A
Transmission model code number 90X4B 91X0C 90X4C 91X0D 95X2B 95X8C
Stall torque ratio 2.0 : 1 1.85 : 1
Transmission gear
ratio 1st 3.540 3.827
2nd 2.264 2.368
3rd 1.471 1.520
4th 1.000 1.000
5th 0.834 0.834
Reverse 2.370 2.613
Recommended fluid Genuine NISSAN Matic J ATF*1
Fluid capacity 10.3 liter (10-7/8 US qt, 9-1/8 Imp qt)
CAUTION:
Use only Genuine NISSAN Matic J ATF. Do not mix with other ATF.
Using ATF other than Genuine NISSAN Matic J ATF will deteriorate in driveability and A/T durability, and may damage the
A/T, which is not covered by the warranty.
Engine model VQ35DE
Throttle position Vehicle speed km/h (MPH)
D
1 → D2D2 → D3D3 → D4D4 → D5D5 → D4D4 → D3D3 → D2D2 → D1
Full throttle 68 - 72
(42 - 45) 106 - 114
(66 - 71) 164 - 174
(102 - 108) 235 - 245
(146 - 152) 231 - 241
(144 - 150) 154 - 164
(96 - 102) 89 - 97
(55 - 60) 38 - 42
(23 - 27)
Half throttle 54 - 58
(34 - 36) 83 - 91
(52 - 57) 126 - 136
(78 - 85) 158 - 168
(98 - 104) 103 - 113
(64 - 70) 74 - 84
(46 - 52) 34 - 42
(21 - 26) 11 - 1 5
(7 - 9)
Engine model VQ35DE
Throttle position Vehicle speed km/h (MPH)
D
1 → D2D2 → D3D3 → D4D4 → D5D5 → D4D4 → D3D3 → D2D2 → D1
Full throttle 62 - 66
(39 - 41) 96 - 104
(60 - 65) 149 - 159
(93 - 99) 213 - 223
(132 - 139) 209 - 219
(130 - 136) 121 - 131
(75 - 81) 81 - 89
(50 - 55) 39 - 43
(24 - 27)
Half throttle 49 - 53
(30 - 33) 75 - 83
(47 - 52) 114 - 124
(71 - 77) 141 - 151
(88 - 94) 94 - 104
(58 - 65) 66 - 76
(41 - 47) 31 - 39
(19 - 24) 11 - 1 5
(7 - 9)
Engine model VK45DE
Throttle position Vehicle speed km/h (MPH)
D
1 → D2D2 → D3D3 → D4D4 → D5D5 → D4D4 → D3D3 → D2D2 → D1
Full throttle 59 - 63
(37 - 39) 95 - 103
(59 - 64) 147 - 157
(92 - 98) 219 - 229
(137 - 143) 215 - 225
(134 - 141) 130 - 140
(81 - 88) 82 - 90
(51 - 56) 35 - 39
(22 - 24)
Half throttle 48 - 52
(30 - 33) 77 - 85
(48 - 53) 121 - 131
(76 - 82) 153 - 163
(96 - 102) 121 - 131
(76 - 82) 67 - 77
(42 - 48) 39 - 47
(24 - 29) 9 - 13
(6 - 8)
