PRECAUTIONS EM-7
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
3. Attach liquid gasket tube to the tube presser [SST: WS39930000 (—)].
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-48, "
RECOMMENDED CHEMICAL PRODUCTS AND
SEALANTS" .
4. Apply liquid gasket without breaks to the specified location with the specified dimensions.
If there is a groove for liquid gasket application, apply liquid
gasket to the groove.
As for bolt holes, normally apply liquid gasket inside the
holes. Occasionally, it should be applied outside the holes.
Make sure to read the text of this manual.
Within five minutes of liquid gasket application, install the mat-
ing component.
If liquid gasket protrudes, wipe it off immediately.
Do not retighten mounting bolts or nuts after the installation.
After 30 minutes or more have passed from the installation, fill
engine oil and engine coolant.
CAUTION:
If there are specific instructions in this manual, observe
them.
EMA0622D
SEM159F
Page 2802 of 4462
EM-8
[VQ35DE]
PREPARATION
Revision: 2006 December 2006 FX35/FX45
PREPARATIONPFP:00002
Special Service ToolsNBS003FV
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here. Tool number
(Kent-Moore No.)
Tool name Description
ST0501S000
(—)
Engine stand assembly
1. ST05011000
(—)
Engine stand
2. ST05012000
(—)
Base Disassembling and assembling the engine
KV10106500
(—)
Engine stand shaft
KV10117000
(J41262)
Engine sub-attachment KV10117000 has been replaced with
KV10117001 (KV10117000 is no longer in
production, but it is usable).
KV10117001
(—)
Engine sub-attachment Installing on cylinder block
KV10116200
(J26336-A)
Valve spring compressor
1. KV10115900
(J26336-20)
Attachment
2.KV10109220
(—)
Adapter Disassembling valve mechanism
Part (1) is a component of KV10116200
(J26336-A), but Part (2) is not so.
KV10107902
(J38959)
Valve oil seal puller Replacing valve oil seal
NT042
NT028
NT373
NT372
PBIC1650E
NT011
Page 2803 of 4462
PREPARATION EM-9
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45KV10115600
(J-38958)
Valve oil seal drift Installing valve oil seal
Use side A.
a: 20 (0.79) dia. d: 8 (0.31) dia.
b: 13 (0.51) dia. e: 10.7 (0.421)
c: 10.3 (0.406) dia. f: 5 (0.20)
Unit: mm (in)
EM03470000
(J8037)
Piston ring compressor Installing piston assembly into cylinder bore
ST16610001
(J23907)
Pilot bushing puller Removing pilot converter
KV10111100
(J37228)
Seal cutter Removing oil pan (lower and upper), front
and rear timing chain case, etc.
WS39930000
(—)
Tube presser Pressing the tube of liquid gasket
KV10112100
(BT8653-A)
Angle wrench Tightening bolts for connecting rod bearing
cap, cylinder head, etc. in angle
KV10117100
(J3647-A)
Heated oxygen sensor wrench Loosening or tightening heated oxygen
sensor 2
For 22 mm (0.87 in) width hexagon nut
Tool number
(Kent-Moore No.)
Tool name Description
S-NT603
NT044
NT045
NT046
NT052
NT014
NT379
Page 2804 of 4462
EM-10
[VQ35DE]
PREPARATION
Revision: 2006 December 2006 FX35/FX45
Commercial Service ToolsNBS003FW
KV10114400
(J38365)
Heated oxygen sensor wrench Loosening or tightening air fuel ratio sensor 1
a: 22 mm (0.87 in)
KV10117700
(J44716)
Ring gear stopper Removing and installing crankshaft pulley
10006 31U00
(—)
Engine rear slinger Removing and installing oil pan (upper) for on
vehicle service
—
(J-45488)
Quick connector release Removing fuel tube quick connectors in
engine room
Tool number
(Kent-Moore No.)
Tool name Description
NT636
NT822
SBIA0530E
PBIC0198E
(Kent-Moore No.)
Tool name Description
(—)
Power tool Loosening nuts and bolts
(BT3373-F)
Belt tension gauge Checking drive belt tension
PBIC0190E
AMA126
Page 2805 of 4462
PREPARATION EM-11
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
(—)
TORX socket Removing and installing flywheel
Size: T55
(—)
Manual lift table caddy Removing and installing engine
(J24239-01)
Cylinder head bolt wrench Loosening and tightening cylinder head bolt,
and used with the angle wrench [SST:
KV10112100 (BT8653-A)]
a: 13 (0.51) dia.
b: 12 (0.47)
c: 10 (0.39)
Unit: mm (in)
(—)
1.Compression tester
2.Adapter Checking compression pressure
(—)
Spark plug wrench Removing and installing spark plug
(—)
Valve seat cutter set Finishing valve seat dimensions
(—)
Piston ring expander Removing and installing piston ring
(Kent-Moore No.)
Tool name Description
PBIC1113E
ZZA1210D
NT583
ZZA0008D
NT047
NT048
NT030
Page 2806 of 4462
![INFINITI FX35 2006 Service Manual EM-12
[VQ35DE]
PREPARATION
Revision: 2006 December 2006 FX35/FX45
(—)
Valve guide drift Removing and installing valve guide
Intake and Exhaust:
a: 9.5 mm (0.374 in) dia.
b: 5.5 mm (0.217 in) di INFINITI FX35 2006 Service Manual EM-12
[VQ35DE]
PREPARATION
Revision: 2006 December 2006 FX35/FX45
(—)
Valve guide drift Removing and installing valve guide
Intake and Exhaust:
a: 9.5 mm (0.374 in) dia.
b: 5.5 mm (0.217 in) di](/manual-img/42/57019/w960_57019-2805.png)
EM-12
[VQ35DE]
PREPARATION
Revision: 2006 December 2006 FX35/FX45
(—)
Valve guide drift Removing and installing valve guide
Intake and Exhaust:
a: 9.5 mm (0.374 in) dia.
b: 5.5 mm (0.217 in) dia.
(—)
Valve guide reamer (1): Reaming valve guide inner hole
(2): Reaming hole for oversize valve guide
Intake and Exhaust:
d
1 : 6.0 mm (0.236 in) dia.
d
2 : 10.2 mm (0.402 in) dia.
(J-43897-18)
(J-43897-12)
Oxygen sensor thread cleaner Reconditioning the exhaust system threads
before installing a new air fuel ratio sensor
and heated oxygen sensor (Use with anti-
seize lubricant shown below.)
a: J-43897-18 [18 mm (0.71 in) dia.] for
zirconia heated oxygen sensor and air fuel
ratio sensor
b: J-43897-12 [12 mm (0.47 in) dia.] for
titania heated oxygen sensor
(—)
Anti-seize lubricant (Permatex 133AR
or equivalent meeting MIL
specification MIL-A-907) Lubricating oxygen sensor thread cleaning
tool when reconditioning exhaust system
threads
(Kent-Moore No.)
Tool name Description
NT015
NT016
AEM488
AEM489
Page 2807 of 4462
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING EM-13
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting — Engine NoiseNBS003FX
PBIC2039E
Page 2808 of 4462
![INFINITI FX35 2006 Service Manual EM-14
[VQ35DE]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
Revision: 2006 December 2006 FX35/FX45
Use the Chart Below to Help You Find the Cause of the Symptom.NBS003FY
1. Locate the area whe INFINITI FX35 2006 Service Manual EM-14
[VQ35DE]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
Revision: 2006 December 2006 FX35/FX45
Use the Chart Below to Help You Find the Cause of the Symptom.NBS003FY
1. Locate the area whe](/manual-img/42/57019/w960_57019-2807.png)
EM-14
[VQ35DE]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
Revision: 2006 December 2006 FX35/FX45
Use the Chart Below to Help You Find the Cause of the Symptom.NBS003FY
1. Locate the area where noise occurs.
2. Confirm the type of noise.
3. Specify the operating condition of the engine.
4. Check specified noise source.
If necessary, repair or replace these parts.
A: Closely related B: Related C: Sometimes related —: Not related Location
of noise Type of
noise Operating condition of engine
Source of noise Check item Refer-
ence page
Before
warm- up After
warm- up When
start- ing When
idling When
racing While
driving
Top of
engine
Rocker
cover
Cylinder
head Ticking or
clicking CA—AB— Tappet
noise Valve clearance
EM-93
Rattle C A — A B C Camshaft
bearing
noise Camshaft runout
Camshaft journal oil
clearance EM-85EM-86
Crank-
shaft pul-
ley
Cylinder
block
(Side of
engine)
Oil pan Slap or
knock —A—B B— Piston pin
noise Piston to piston pin oil
clearance
Connecting rod bush-
ing oil clearance EM-141
EM-143
Slap or
rap A——B B A Piston
slap noise Piston to cylinder bore
clearance
Piston ring side clear-
ance
Piston ring end gap
Connecting rod bend
and torsion EM-145EM-142
EM-142
EM-143
Knock A B C B B B
Connect-
ing rod
bearing
noise Connecting rod bush-
ing oil clearance
Connecting rod bear-
ing oil clearance EM-143EM-147
Knock A B — A B C
Main
bearing
noise Main bearing oil clear-
ance
Crankshaft runout EM-148
EM-147
Front of
engine
Timing
chain
case Tapping or
ticking AA—BBB Timing
chain and
timing
chain ten-
sioner
noise Timing chain cracks
and wear
Timing chain tensioner
operation EM-72
EM-64
Front of
engine Squeak-
ing or fizz-
ing AB—B—C Drive belts
(Sticking
or slip-
ping) Drive belts deflection
EM-15
CreakingABABAB Drive belts
(Slipping) Idler pulley bearing
operation
Squall
Creak AB—BAB Water
pump
noise Water pump operation CO-22,
"WATER
PUMP"
