INFINITI FX35 2006 Service Manual PARKING, LICENSE PLATE AND TAIL LAMPS LT-151
C
D E
F
G H
I
J
L
M A
B
LT
Revision: 2006 December 2006 FX35/FX45
Tail Lamp Does Not OperateNKS003HC
1. CHECK STOP LAMP AND TURN SIGNAL LAMP
M

Page 3714 of 4462

INFINITI FX35 2006 Service Manual LT-152
PARKING, LICENSE PLATE AND TAIL LAMPS
Revision: 2006 December 2006 FX35/FX45
5. CHECK REAR COMBINATION LAMPS CIRCUIT
1. Disconnect rear combination lamp RH and LH connectors.
2. Check continu

Page 3715 of 4462

INFINITI FX35 2006 Service Manual PARKING, LICENSE PLATE AND TAIL LAMPS LT-153
C
D E
F
G H
I
J
L
M A
B
LT
Revision: 2006 December 2006 FX35/FX45
3. Insert a flat head or suitable tool and remove housing.
4. Remove bulb fr

Page 3716 of 4462

INFINITI FX35 2006 Service Manual LT-154
REAR COMBINATION LAMP
Revision: 2006 December 2006 FX35/FX45
REAR COMBINATION LAMPPFP:26554
Bulb ReplacementNKS003HK
REAR FENDER SIDE (REAR SIDE MARKER LAMP BULB)
1. Remove rear combination lam

Page 3717 of 4462

INFINITI FX35 2006 Service Manual REAR COMBINATION LAMP LT-155
C
D E
F
G H
I
J
L
M A
B
LT
Revision: 2006 December 2006 FX35/FX45
Trunk Lid Side
1. Remove back door finisher. Refer to EI-46, "Removal and Instal-
lation" .

Page 3718 of 4462

INFINITI FX35 2006 Service Manual LT-156
INTERIOR ROOM LAMP
Revision: 2006 December 2006 FX35/FX45
INTERIOR ROOM LAMPPFP:26410
Component Parts and Harness Connector LocationNKS002YM
System DescriptionNKS002YN
When the room lamp and pe

Page 3719 of 4462

INFINITI FX35 2006 Service Manual INTERIOR ROOM LAMP LT-157
C
D E
F
G H
I
J
L
M A
B
LT
Revision: 2006 December 2006 FX35/FX45
When the room lamp and personal lamp turns ON, there is a gradual brightening over 1 second. Whe

INTERIOR ROOM LAMP LT-157
C
D E
F
G H
I
J
L
M A
B
LT
Revision: 2006 December 2006 FX35/FX45
When the room lamp and personal lamp turns ON, there is a gradual brightening over 1 second. When room
lamp and personal lamp turns OFF, there is a gradual dimming over 1 second.
The room lamp and personal lamp timer is controlled by the BCM (body control module).
Room lamp and personal lamp timer control settings can be changed with CONSULT-II.
Ignition keyhole illumination turns ON at time when driver door is opened (door switch ON) or removed keyfob
from key cylinder. Illumination turns OFF when driver door is closed (door switch OFF).
Step lamp turns ON at time when driver door or passenger door is opened (door switch ON). Lamp turns OFF
when the driver, passenger doors are closed (all door switches OFF).
POWER SUPPLY AND GROUND
Power is supplied at all times (without Intelligent Key system)
through 15A fuse [No. 22, located in fuse block (J/B)]
to key switch terminal 2 and
to BCM terminal 42,
through 50A fusible link (letter M, located in fuse, fusible link and relay box)
to BCM terminal 55,
through 10A fuse [No. 19, located in fuse block (J/B)]
to combination meter terminal 8.
Power is supplied at all times (with Intelligent Key system)
through 10A fuse (No.38, located in fuse, fusible link and relay box)
to key switch and ignition knob switch terminal 1,
through 15A fuse [No.22, located in fuse block (J/B)]
to BCM terminal 42 and
to key switch and ignition knob switch terminal 3,
through 50A fusible link (letter M, located in fuse, fusible link and relay box)
to BCM terminal 55,
through 10A fuse [No. 19, located in fuse block (J/B)]
to combination meter terminal 8.
When key plate inserted to key switch, power is supplied (without Intelligent Key system)
through key switch terminal 1
to BCM terminal 37.
When inserted key plate to key switch, power is supplied (with Intelligent Key system)
through key switch and ignition knob switch terminal 4
to BCM terminal 37.
When moved ignition knob switch, power is supplied (with Intelligent Key system)
through ignition knob switch terminal 2
to intelligent key unit terminal 27.
With ignition switch in the ON or START position, power is supplied
through 15A fuse [No. 1, located in fuse block (J/B)]
to BCM terminal 38.
Ground is supplied
to BCM terminals 49 and 52
through grounds terminals M35, M45 and M85.
When driver side door is opened, ground is supplied
through case ground of front door switch (driver side)
through front door switch (driver side) terminal 1
to BCM terminal 62.
When passenger side door is opened, ground is supplied
through case ground of front door switch (passenger side)
through front door switch (passenger side) terminal 1
to BCM terminal 12.

Page 3720 of 4462

INFINITI FX35 2006 Service Manual LT-158
INTERIOR ROOM LAMP
Revision: 2006 December 2006 FX35/FX45
When rear door LH is opened, ground is supplied
through case ground of rear door switch LH
through rear door switch LH terminal 1
to

LT-158
INTERIOR ROOM LAMP
Revision: 2006 December 2006 FX35/FX45
When rear door LH is opened, ground is supplied
through case ground of rear door switch LH
through rear door switch LH terminal 1
to BCM terminal 63, and
to personal lamp LH terminal 1.
When rear door RH is opened, ground is supplied
through case ground of rear door switch RH
through rear door switch RH terminal 1
to BCM terminal 13, and
to personal lamp RH terminal 1.
When driver side door is unlocked by door lock and unlock switch, BCM receives a ground signal
through grounds terminals M35, M45 and M85
to power window main switch (door lock and unlock switch) terminal 17 or front power window switch
(passenger side) (door lock and unlock switch) terminal 11
from power window main switch (door lock and unlock switch) terminal 14 or front power window switch
(passenger side) (door lock and unlock switch) terminal 16
to BCM terminal 22.
When front driver side door is unlocked by driver side door lock assembly (key cylinder switch), BCM receives
a ground signal
through grounds M35, M45 and M85
to front door lock assembly (driver side) (key cylinder switch) terminal 5
from front door lock assembly (driver side) (key cylinder switch) terminal 6
to power window main switch (door lock and unlock switch) terminal 6
from power window main switch (door lock and unlock switch) terminal 14
to BCM terminal 22.
When a signal, or combination of signals is received by BCM, ground is supplied
to interior room lamp terminal 1 (without DVD player),
to map lamp terminal 2,
to front door inside handle illumination terminal 2, and
to rear door inside handle illumination terminal 2
through BCM terminal 48.
With power and supplied, interior lamp illuminates.
SWITCH OPERATION
When driver door switch is ON (door is opened), ground is supplied
through BCM terminal 1
to ignition keyhole illumination terminal 2.
And power is supplied
from BCM terminal 41
to ignition keyhole illumination terminal 1.
When any door switch is ON (door is opened), ground is supplied
through BCM terminal 47
to front step lamp (driver side and passenger side) and rear step lamp (LH and RH) terminals 2
through rear door switch (LH or RH) terminal 1
to personal lamp (LH or RH) terminals 1.
And power is supplied
from BCM terminal 41
to front step lamp (driver side and passenger side) and rear step lamp (LH and RH) terminals 1, and
to personal lamp (LH and RH) terminals 2
When map lamp switch is ON, ground is supplied
