INFINITI FX35 2006 Service Manual SERVICE DATA WT-39
C
D
F
G H
I
J
K L
M A
B
WT
Revision: 2006 December 2006 FX35/FX45
SERVICE DATAPFP:00030
Road WheelNES000HB
TireNES000HC
Unit: kPa (kg/cm2 , psi)
Kind of wheel Aluminum

Page 4402 of 4462

INFINITI FX35 2006 Service Manual WT-40
SERVICE DATA
Revision: 2006 December 2006 FX35/FX45

Page 4403 of 4462

INFINITI FX35 2006 Service Manual WW-1
WIPER, WASHER & HORN
K ELECTRICAL
CONTENTS
C
D E
F
G H
I
J
L
M
SECTION WW
A
B
WW
Revision: 2006 December 2006 FX35/FX45
WIPER, WASHER & HORN
PRECAUTION ...............................

WW-1
WIPER, WASHER & HORN
K ELECTRICAL
CONTENTS
C
D E
F
G H
I
J
L
M
SECTION WW
A
B
WW
Revision: 2006 December 2006 FX35/FX45
WIPER, WASHER & HORN
PRECAUTION ....................................................... ..... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 3
FRONT WIPER AND WASHER SYSTEM ............. ..... 4
Components Parts and Harness Connector Loca-
tion ...................................................................... ..... 4
System Description ............................................. ..... 4
OUT LINE ......................................................... ..... 4
LOW SPEED WIPER OPERATION ................. ..... 5
HI SPEED WIPER OPERATION ...................... ..... 5
INTERMITTENT OPERATION ......................... ..... 5
AUTO STOP OPERATION ............................... ..... 6
WASHER OPERATION .................................... ..... 6
MIST OPERATION ........................................... ..... 6
FAIL-SAFE FUNCTION .................................... ..... 7
COMBINATION SWITCH READING FUNCTION ..... 8
CAN Communication System Description ........... ... 10
CAN Communication Unit ................................... ... 10
Schematic ........................................................... .... 11
Wiring Diagram — WIPER — ............................. ... 12
Terminals and Reference Values for BCM .......... ... 15
Terminals and Reference Values for IPDM E/R .. ... 18
How to Proceed With Trouble Diagnosis ............. ... 19
Preliminary Check ............................................... ... 19
CHECK POWER SUPPLY AND GROUND CIR-
CUIT ................................................................. ... 19
CONSULT-II Functions (BCM) ............................ ... 20
CONSULT-II BASIC OPERATION .................... ... 20
WORK SUPPORT ............................................ ... 20
DATA MONITOR .............................................. ... 20
ACTIVE TEST .................................................. ... 21
CONSULT-II Functions (IPDM E/R) .................... ... 22
CONSULT-II BASIC OPERATION .................... ... 22
DATA MONITOR .............................................. ... 22
ACTIVE TEST .................................................. ... 22
Front Wiper Does Not Operate ........................... ... 23
Front Wiper Does Not Return to Stop Position .... ... 25
Only Front Wiper Low Does Not Operate ........... ... 26
Only Front Wiper Hi Does Not Operate ............... ... 28 Only Front Wiper Intermittent Does Not Operate ... 29
Front Wiper Interval Time Is Not Controlled by Vehi-
cle Speed ............................................................. ... 29
Front Wiper Intermittent Operation Switch Position
Cannot Be Adjusted ............................................. ... 30
Wiper Does Not Wipe When Front Washer Operates ... 30
After Front Wiper Operate for 10 Seconds, They
Stop for 20 Seconds, and After Repeating the Oper-
ations Five Times, They Become Inoperative ..... ... 31
Front Wiper Does Not Stop .................................. ... 32
Removal and Installation of Front Wiper Arms,
Adjustment of Wiper Arms Stop Location ............ ... 33
REMOVAL ........................................................ ... 33
INSTALLATION ................................................ ... 33
ADJUSTMENT ................................................. ... 33
Removal and Installation of Front Wiper Drive
Assembly ............................................................. ... 33
REMOVAL ........................................................ ... 33
INSTALLATION ................................................ ... 33
Disassembly and Assembly of Front Wiper Drive
Assembly ............................................................. ... 34
DISASSEMBLY ................................................ ... 34
ASSEMBLY ...................................................... ... 34
Washer Nozzle Adjustment ................................. ... 34
Washer Tube Layout ........................................... ... 36
Removal and Installation of Front Washer Nozzle ... 36
Removal and Installation of Front Washer Tube
Joint ..................................................................... ... 36
REMOVAL ........................................................ ... 36
INSTALLATION ................................................ ... 36
Inspection of Washer Nozzle ............................... ... 36
CHECK VALVE ................................................. ... 36
Removal and Installation of Front Wiper and Washer
Switch .................................................................. ... 37
REMOVAL ........................................................ ... 37
INSTALLATION ................................................ ... 37
Removal and Installation of Washer Tank ........... ... 37
REMOVAL ........................................................ ... 37

Page 4404 of 4462

INFINITI FX35 2006 Service Manual WW-2Revision: 2006 December 2006 FX35/FX45 INSTALLATION .................................................
... 38
Removal and Installation of Washer Pump .......... ... 38
REMOVAL .................

WW-2Revision: 2006 December 2006 FX35/FX45 INSTALLATION .................................................
... 38
Removal and Installation of Washer Pump .......... ... 38
REMOVAL ........................................................ ... 38
INSTALLATION ................................................. ... 38
REAR WIPER AND WASHER SYSTEM ............... ... 39
Component Parts and Harness Connector Location ... 39
System Description .............................................. ... 39
REAR WIPER OPERATION ............................. ... 39
INTERMITTENT OPERATION ......................... ... 40
AUTO STOP OPERATION ............................... ... 40
WASHER OPERATION .................................... ... 40
BCM WIPER SWITCH READING FUNCTION . ... 40
Wiring Diagram — WIP/ R — .............................. ... 41
Terminals and Reference Values for BCM ........... ... 43
How to Proceed With Trouble Diagnosis ............. ... 45
Preliminary Check ............................................... ... 45
CHECK POWER SUPPLY AND GROUND CIR-
CUIT ................................................................. ... 45
CONSULT-II Functions (BCM) ............................. ... 46
CONSULT-II BASIC OPERATION .................... ... 46
DATA MONITOR ............................................... ... 46
ACTIVE TEST .................................................. ... 46
Rear Wiper Does Not Operate ............................ ... 47
Rear Wiper Does Not Return to Stop Position ..... ... 48
Only Rear Wiper ON Does Not Operate .............. ... 49
Only Rear Wiper INT Does Not Operate ............. ... 49
Wiper Does Not Wipe When Rear Washer Operates ... 49
Rear Wipers Do Not Stop .................................... ... 50
Removal and Installation of Rear Wiper Arm, Adjust-
ment of Wiper Arms Stop Location ...................... ... 51
REMOVAL ........................................................ ... 51
INSTALLATION ................................................. ... 51
Removal and Installation of Rear Wiper Motor .... ... 51
REMOVAL ........................................................ ... 52 INSTALLATION .................................................
... 52
Removal and Installation of Rear Wiper Blade .... ... 52
REMOVAL ......................................................... ... 52
INSTALLATION ................................................. ... 52
Washer Nozzle Adjustment .................................. ... 53
Removal and Installation of Washer Nozzle ........ ... 53
REMOVAL ......................................................... ... 53
INSTALLATION ................................................. ... 53
Washer Tube Layout ............................................ ... 54
Check Valve ......................................................... ... 54
Removal and Installation of Rear Wiper and Washer
Switch .................................................................. ... 54
Removal and Installation of Washer Tank ............ ... 54
Removal and Installation of Washer pump .......... ... 54
POWER SOCKET .................................................. ... 55
Wiring Diagram — P/SCKT — ............................. ... 55
Removal and Installation of Front Power Socket – 1 ... 56
REMOVAL ......................................................... ... 56
INSTALLATION ................................................. ... 56
Removal and Installation of Front Power Socket – 2 ... 56
REMOVAL ......................................................... ... 56
INSTALLATION ................................................. ... 56
Removal and Installation of Rear Power Socket .. ... 56
REMOVAL ......................................................... ... 56
INSTALLATION ................................................. ... 56
Removal and Installation of Luggage Room Power
Socket .................................................................. ... 57
REMOVAL ......................................................... ... 57
INSTALLATION ................................................. ... 57
HORN ..................................................................... ... 58
Wiring Diagram — HORN — ............................... ... 58
Removal and Installation ...................................... ... 59
REMOVAL ......................................................... ... 59
INSTALLATION ................................................. ... 59

Page 4405 of 4462

INFINITI FX35 2006 Service Manual PRECAUTION WW-3
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
PRECAUTIONPFP:00011
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT P

Page 4406 of 4462

INFINITI FX35 2006 Service Manual WW-4
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 December 2006 FX35/FX45
FRONT WIPER AND WASHER SYSTEMPFP:28810
Components Parts and Harness Connector LocationNKS00326
System DescriptionNKS00327
All

Page 4407 of 4462

INFINITI FX35 2006 Service Manual FRONT WIPER AND WASHER SYSTEM WW-5
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
to front wiper relay, located in IPDM E/R
to front wiper high relay, located in IPDM

FRONT WIPER AND WASHER SYSTEM WW-5
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
to front wiper relay, located in IPDM E/R
to front wiper high relay, located in IPDM E/R and
to CPU located in IPDM E/R,
through 10 A fuse (No. 84, located in IPDM E/R)
through IPDM E/R terminal 44
to combination switch terminal 14.
Ground is supplied
to BCM terminals 49 and 52
through grounds M35, M45 and M85,
to IPDM E/R terminals 38 and 60
through grounds E21, E50 and E51,
to combination switch terminal 12
through grounds M35, M45 and M85.
LOW SPEED WIPER OPERATION
When wiper switch is in LOW position, BCM detects low speed wiper ON signal by BCM wiper switch reading
function.
BCM sends front wiper request signal (LO) with CAN communication line
from BCM terminals 39 and 40
to IPDM E/R terminals 48 and 49.
When IPDM E/R receives front wiper request signal (LO), it turns ON front wiper relay located in IPDM E/R,
power is supplied
to front wiper motor terminal 1
through IPDM E/R terminal 21 and front wiper relay and front wiper high relay.
Ground is supplied
to front wiper motor terminal 2
through grounds E21, E50 and E51.
With power and ground supplied, the front wiper motor operates at low speed.
HI SPEED WIPER OPERATION
When wiper switch is in HI position, BCM detects high speed wiper ON signal by BCM wiper switch reading
function.
BCM sends front wiper request signal (HI) with CAN communication line
from BCM terminals 39 and 40
to IPDM E/R terminals 48 and 49.
When IPDM E/R receives front wiper request signal (HI), it turns ON front wiper relay (located in IPDM E/R),
power is supplied
to front wiper motor terminal 4
through IPDM E/R terminal 31 and front wiper relay and front wiper high relay.
Ground is supplied
to front wiper motor terminal 2
through grounds E21, E50 and E51.
With power and ground supplied, the front wiper motor operates at high speed.
INTERMITTENT OPERATION
Front wiper intermittent operation delay interval is determined from a combination of 3 switches (intermittent
operation dial position 1, 2, and 3) and vehicle speed signal.
Speed dependent wiper controlled mode can be changed by the function setting of CONSULT-ll or display.
During each intermittent operation delay interval, BCM sends front wiper request signal to IPDM E/R.

Page 4408 of 4462

INFINITI FX35 2006 Service Manual WW-6
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 December 2006 FX35/FX45
Wiper Dial Position Setting
Example: For wiper intermittent dial position 1
Using combination switch reading function, BCM de

WW-6
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 December 2006 FX35/FX45
Wiper Dial Position Setting
Example: For wiper intermittent dial position 1
Using combination switch reading function, BCM detects ON/OFF status of INT VOLUME 1, 2, and 3.
When combination switch status is as listed below, BCM determines that it is wiper intermittent dial position 1.
INT VOLUME 1: ON (Continuity exists between combination switch output 3 and input 1.)
INT VOLUME 2: ON (Continuity exists between combination switch output 5 and input 1.)
INT VOLUME 3: ON (Continuity exists between combination switch output 4 and input 2.)
BCM determines front wiper intermittent operation delay interval from wiper intermittent dial position 1 and
vehicle speed, and sends wiper request signal (INT) to IPDM E/R.
AUTO STOP OPERATION
With wiper switch turned OFF, wiper motor will continue to operate until wiper arms reach windshield base.
When wiper arms are not located at base of windshield with wiper switch OFF, ground is provided
from IPDM E/R terminal 21
to front wiper motor terminal 1, in order to continue wiper motor operation at low speed.
When wiper arms reach base of windshield, front wiper motor terminals 5 and 2 are connected,
and Ground is supplied
to IPDM E/R terminal 32
through front wiper motor terminals 5 and 2
through grounds E21, E50 and E51.
Then the IPDM E/R sends auto stop operation signal to BCM with CAN communication line.
When the BCM receives auto-stop operation signal, BCM sends wiper stop signal to IPDM E/R with CAN com-
munication line.
IPDM E/R stops wiper motor. Wiper motor will then stop wiper arms at the STOP position.
WASHER OPERATION
When wiper switch is in front wiper washer position with ignition switch on, BCM detects front wiper switch is
on the washer position by BCM wiper switch reading function (Refer to WW-8, "
COMBINATION SWITCH
READING FUNCTION" ), combination switch (wiper switch) ground is supplied
to combination switch terminal 13
through front and rear washer pump terminal 1
to front and rear washer pump terminal 2
through combination switch terminal 11
to combination switch terminal 12
through grounds M35, M45 and M85.
With ground supplied, front and rear washer pump is operated.
When BCM detects that front and rear washer pump has operated for 0.4 seconds or linger, BCM operates
front wiper motor for low speed.
When BCM detects washer switch is OFF, low speed operation cycles approximately 2 times and stops.
MIST OPERATION
When wiper switch is turned to MIST position, wiper low speed operation cycles once and then stops.
For additional information about wiper operation under this condition, Refer to WW-5, "
LOW SPEED WIPER
OPERATION" .
Wiper intermittent dial position Intermittent operation
interval Combination switch
INT VOLUME 1 INT VOLUME 2 INT VOLUME 3
1 Short
↑
↓
Long ON ON ON
2ONONOFF
3ONOFFOFF
4 OFF OFF OFF
5OFFOFFON
6 OFF ON ON
7 OFF ON OFF
