FRONT WIPER AND WASHER SYSTEM WW-31
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
After Front Wiper Operate for 10 Seconds, They Stop for 20 Seconds, and After
Repeating the Operations Five Times, They Become Inoperative
NKS0032Q
CAUTION:
When auto-stop signal has not varied for 10 seconds or longer while IPDM E/R is operating front
wipers, IPDM E/R considers that front wipers are locked, and stops wiper output. That causes this
symptom.
This status can be checked by “DATA MONITOR” of “IPDM E/R” on which “WIPER PROTECTION”
item shows “BLOCK”.
1. CHECK WIPER MOTOR SIGNAL
With CONSULT-ll
Select “IPDM E/R” by CONSULT-II. With “DATA MONITOR”, make
sure that “WIP AUTO STOP” turns “ACT P” - “STOP P” linked with
wiper operation.
Without CONSULT-ll
GO TO 2.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 2.
2. CHECK WIPER AUTO STOP CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector and front wiper motor connec- tor.
3. Check continuity between IPDM E/R harness connector E7 ter- minal 32 and front wiper motor harness connector E57 terminal
5.
4. Check continuity between IPDM E/R harness connector E7 ter- minal 32 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3. CHECK FRONT WIPER MOTOR
1. Connect IPDM E/R connector and front wiper connector.
2. Turn ignition switch ON.
3. Check voltage between IPDM E/R harness connector E7 termi- nal 32 and ground while front wiper motor is stopped and while it
is operating.
OK or NG
OK >> Replace IPDM E/R.
NG >> Replace front wiper motor.
PKIA7614E
32 – 5 : Continuity should exist.
32 – Ground : Continuity should not exist.
PKIA5195E
(+) (-) Condition Voltage
IPDM E/R connector Terminal
E7 32 Ground Wiper stopped Approx. 0 V
Wiper operating Battery voltage
PKIA5196E
Page 4434 of 4462
WW-32
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 December 2006 FX35/FX45
Front Wiper Does Not StopNKS0032R
1. CHECK CIRCUIT BETWEEN COMBINATION SWITCH AND BCM
With CONSULT-ll
1. Select “BCM” on CONSULT-II, and select “WIPER” on “SELECT TEST ITEM” screen.
2. Select “DATA MONITOR” on “SELECT DIAG MODE” screen. Make sure that “FR WIPER INT”, “FR WIPER LOW”, “FR
WIPER HI”, and “FR WASHER SW” turn ON-OFF according to
front wiper switch operation.
Without CONSULT-ll
Refer to LT- 1 2 0 , "
Combination Switch Inspection" .
OK or NG
OK >> Replace IPDM E/R.
NG >> Check combination switch (wiper switch). Refer to LT-
120, "Combination Switch Inspection" .
PKIB0110E
Page 4435 of 4462

FRONT WIPER AND WASHER SYSTEM WW-33
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
Removal and Installation of Front Wiper Arms, Adjustment of Wiper Arms Stop
Location
NKS0032S
REMOVAL
1. Operate wiper motor, and stop it at the auto stop position.
2. Remove washer tube from washer tube joint.
3. Remove wiper arm mounting nuts and wiper arm from vehicle.
INSTALLATION
1. Clean up the pivot area as illustrated. This will reduce possibility of wiper arm looseness.
2. Prior to wiper arm installation, turn on wiper switch to operate wiper motor and then turn it “OFF” (auto stop).
3. Push wiper arm onto pivot shaft, paying attention to blind spline.
4. Attach washer tube to washer tube joint.
5. Lift the blade up and then set it down onto glass surface to set the blade center to clearance “A” & “B” immediately before tight-
ening nut.
6. Eject washer fluid. Turn on wiper switch to operate wiper motor and then turn it “OFF”.
7. Ensure that wiper blades stop within clearance “A” & “B”.
Tighten wiper arm nuts to specified torque.
ADJUSTMENT
Refer to WW-33, "INSTALLATION" .
Removal and Installation of Front Wiper Drive Assembly NKS0032T
REMOVAL
1. Prior to front wiper drive assembly removal, turn ON wiper switch to operate wiper motor and then turn it
“OFF” (auto stop).
2. Remove wiper arm. Refer to WW-33, "
REMOVAL" .
3. Remove cowl top cover. Refer to EI-23, "
COWL TOP" .
4. Remove washer tube.
5. Disconnect wiper motor connector.
6. Remove front wiper drive assembly mounting bolts, and remove front wiper drive assembly.
INSTALLATION
1. Install front wiper drive assembly to the vehicle.
SEL024J
Clearance “A” : 44.4 – 54.4 mm (1.75 – 2.14 in)
Clearance “B” : 38 – 48 mm (1.50 – 1.89 in)
Front wiper arm nuts : 23.6 N·m (2.4 kg-m, 17 ft-lb)
PKIB3556E
SKIA5070E
Page 4436 of 4462

WW-34
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 December 2006 FX35/FX45
2. Connect wiper motor assembly to the connector. Turn wiper switch ON to operate wiper motor, then turn wiper switch OFF (auto stop).
3. Attach washer tube to washer tube joint.
4. Install cowl top cover. Refer to EI-23, "
COWL TOP" .
5. Install wiper arms. Refer to WW-33, "
Removal and Installation of Front Wiper Arms, Adjustment of Wiper
Arms Stop Location" .
6. Attach wiper arm washer tube.
CAUTION:
Never drop the wiper motor or cause it to contact other parts.
Check grease conditions of the motor arm and wiper link joint (at retainer). Apply grease if nec-
essary.
Disassembly and Assembly of Front Wiper Drive AssemblyNKS0032U
DISASSEMBLY
1. Remove wiper link 1 and 2 from wiper motor mounting frame and wiper motor arm.
2. Remove wiper motor mounting bolts, and remove wiper motor from wiper motor mounting frame.
ASSEMBLY
Assembly is the reverse order of disassembly.
Washer Nozzle AdjustmentNKS0032V
1. When wiper blade position is in auto stop condition, remove wiper motor connector to ensure wiper arms do not move.
2. Adjust each nozzle position (A, B, E, G, H, and K) so that spray positions are in the range of shaded parts. CAUTION:
Only washer nozzles (A, B, E, G, H, and K) can be adjusted. Washer nozzles (C, D, F, I, J, and L)
cannot be adjusted because of fixed nozzles. Front wiper drive assembly
mounting bolt : 4.5 N·m (0.46 kg-m, 40 in-lb)
1. Wiper link 2 2. Wiper link 1 3. Wiper motor frame mounting bolt
4. Wiper motor mounting frame 5. Wiper motor 6. Wiper motor mounting bolt
N·m (kg-m, in-lb)
PKIC9716E
Page 4437 of 4462
FRONT WIPER AND WASHER SYSTEM WW-35
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
PKIB3558E
SKIA5073E
Page 4438 of 4462
WW-36
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 December 2006 FX35/FX45
Washer Tube LayoutNKS0032W
Removal and Installation of Front Washer NozzleNKS0032X
Replace wiper arm assembly. Refer to WW-33, "Removal and Installation of Front Wiper Arms, Adjustment of
Wiper Arms Stop Location" .
CAUTION:
Removal/installation of the washer nozzle as a unit must not be done.
Removal and Installation of Front Washer Tube JointNKS0032Y
REMOVAL
1. Remove upwards while pressing the pawls on reverse side.
2. Remove washer tube.
INSTALLATION
Installation is the reverse order of removal.
Inspection of Washer NozzleNKS0032Z
CHECK VALVE
Blow air in the injection direction, and make sure air flows only one
way. Make sure that the reverse direction (inhale) is not possible.
PKIC9704E
PKIA1159E
PKIA3131E
Page 4439 of 4462

FRONT WIPER AND WASHER SYSTEM WW-37
C
D E
F
G H
I
J
L
M A
B
WW
Revision: 2006 December 2006 FX35/FX45
Removal and Installation of Front Wiper and Washer SwitchNKS00330
REMOVAL
1. Remove steering column upper cover. Refer to IP-10, "INSTRU-
MENT PANEL ASSEMBLY" .
2. Disconnect wiper and washer switch connector.
3. Pull wiper and washer switch toward the passenger door while pressing pawls in direction shown by the arrow in the figure, and
remove it from the base.
INSTALLATION
Installation is the reverse order of removal.
Removal and Installation of Washer TankNKS00331
REMOVAL
1. Remove bolt and pull out washer tank inlet.
2. Remove fillet molding (RH). Refer to EI-14, "
FRONT BUMPER" .
3. Remove fender protector (RH). Refer to EI-24, "
FENDER PRO-
TECTOR" .
4. Remove bumper fascia assembly. Refer to EI-14, "
FRONT
BUMPER" .
5. Disconnect washer pump connector and wash fluid level sensor connector.
6. Remove washer tank mounting bolt and nuts.
7. Remove washer tube, and remove washer tank from the vehicle.
PKIB6026E
SKIA5076E
PKIC9705E
PKIC9707E
Page 4440 of 4462
WW-38
FRONT WIPER AND WASHER SYSTEM
Revision: 2006 December 2006 FX35/FX45
INSTALLATION
Installation is the reverse order of removal.
NOTE:
After installation, add water up to the upper level of the washer tank inlet, and check for water leaks.
Removal and Installation of Washer PumpNKS00332
REMOVAL
1. Remove fillet molding (RH). Refer to EI-14, "FRONT BUMPER" .
2. Remove fender protector (RH). Refer to EI-24, "
FENDER PROTECTOR" .
3. Remove bumper fascia assembly. Refer to EI-14, "
FRONT BUMPER" .
4. Disconnect washer pump connector and tube.
5. Pull out washer pump in direction shown by the arrow in the fig- ure. Remove washer pump from washer tank.
INSTALLATION
Installation is the reverse order of removal.
NOTE:
When installing washer pump, there should be no packing twists, etc. Washer tank mounting bolt : 5.7 N·m (0.58 kg-m, 50 in-lb)
Washer tank mounting nut : 5.7 N·m (0.58 kg-m, 50 in-lb)
Washer tank inlet mounting bolt : 6.8 N·m (0.69 kg-m, 60 in-lb)
PKIC9706E
