ON BOARD REFUELING VAPOR RECOVERY (ORVR) EC-49
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
7. CHECK REFUELING EVAP VAPOR CUT VALVE
Refer to EC-49, "
Component Inspection" .
OK or NG
OK >> GO TO 8.
NG >> Replace refueling EVAP vapor cut valve with fuel tank.
8. CHECK FUEL FILLER TUBE
Check filler neck tube and hose connected to the fuel tank for clogging, dents and cracks.
OK or NG
OK >> GO TO 9.
NG >> Replace fuel filler tube.
9. CHECK ONE-WAY FUEL VALVE-I
Check one-way valve for clogging.
OK or NG
OK >> GO TO 10.
NG >> Repair or replace one-way fuel valve with fuel tank.
10. CHECK ONE-WAY FUEL VALVE-II
1. Make sure that fuel is drained from the tank.
2. Remove fuel filler tube and hose.
3. Check one-way fuel valve for operation as follows. When a stick is inserted, the valve should open, when removing
stick it should close.
Do not drop any material into the tank.
OK or NG
OK >> INSPECTION END
NG >> Replace fuel filler tube or replace one-way fuel valve with fuel tank.
Component InspectionNBS003LG
REFUELING EVAP VAPOR CUT VALVE
With CONSULT-II
1. Remove fuel tank. Refer to FL-10, "FUEL TANK" .
2. Drain fuel from the tank as follows:
a. Remove fuel feed hose located on the fuel gauge retainer.
b. Connect a spare fuel hose, one side to fuel gauge retainer where the hose was removed and the other side to a fuel container.
c. Drain fuel using “FUEL PUMP RELAY” in “ACTIVE TEST” mode with CONSULT-II.
3. Check refueling EVAP vapor cut valve for being stuck to close as follows. Blow air into the refueling EVAP vapor cut valve (from the end of EVAP/ORVR line hose), and check that
the air flows freely into the tank.
4. Check refueling EVAP vapor cut valve for being stuck to open as follows.
a. Connect vacuum pump to hose end.
b. Remove fuel gauge retainer with fuel gauge unit. Always replace O-ring with new one.
c. Put fuel tank upside down.
SEF665U
Page 1434 of 4462
![INFINITI FX35 2006 Service Manual EC-50
[VQ35DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
Revision: 2006 December 2006 FX35/FX45
d. Apply vacuum pressure to hose end [ −13.3 kPa ( −100 mmHg, −3.94 inHg)] with fuel gauge retaine INFINITI FX35 2006 Service Manual EC-50
[VQ35DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
Revision: 2006 December 2006 FX35/FX45
d. Apply vacuum pressure to hose end [ −13.3 kPa ( −100 mmHg, −3.94 inHg)] with fuel gauge retaine](/manual-img/42/57019/w960_57019-1433.png)
EC-50
[VQ35DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
Revision: 2006 December 2006 FX35/FX45
d. Apply vacuum pressure to hose end [ −13.3 kPa ( −100 mmHg, −3.94 inHg)] with fuel gauge retainer
remaining open and check that the pressure is applicable.
Without CONSULT-II
1. Remove fuel tank. Refer to FL-10, "FUEL TANK" .
2. Drain fuel from the tank as follows:
a. Remove fuel gauge retainer.
b. Drain fuel from the tank using a handy pump into a fuel container.
3. Check refueling EVAP vapor cut valve for being stuck to close as follows. Blow air into the refueling EVAP vapor cut valve (from the end of EVAP/ORVR line hose), and check that
the air flows freely into the tank.
4. Check refueling EVAP vapor cut valve for being stuck to open as follows.
a. Connect vacuum pump to hose end.
b. Remove fuel gauge retainer with fuel gauge unit. Always replace O-ring with new one.
c. Put fuel tank upside down.
d. Apply vacuum pressure to hose end [ −13.3 kPa ( −100 mmHg, −3.94 inHg)] with fuel gauge retainer
remaining open and check that the pressure is applicable.
PBIB1035E
PBIB1035E
Page 1435 of 4462
![INFINITI FX35 2006 Service Manual POSITIVE CRANKCASE VENTILATION EC-51
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
POSITIVE CRANKCASE VENTILATIONPFP:11810
DescriptionNBS003LH
SYSTEM DESCRIPTI INFINITI FX35 2006 Service Manual POSITIVE CRANKCASE VENTILATION EC-51
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
POSITIVE CRANKCASE VENTILATIONPFP:11810
DescriptionNBS003LH
SYSTEM DESCRIPTI](/manual-img/42/57019/w960_57019-1434.png)
POSITIVE CRANKCASE VENTILATION EC-51
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
POSITIVE CRANKCASE VENTILATIONPFP:11810
DescriptionNBS003LH
SYSTEM DESCRIPTION
This system returns blow-by gas to the intake manifold.
The positive crankcase ventilation (PCV) valve is provided to conduct crankcase blow-by gas to the intake
manifold. During partial throttle operation of the engine, the intake manifold sucks the blow-by gas through the
PCV valve. Normally, the capacity of the valve is sufficient to handle any blow-by and a small amount of venti-
lating air. The ventilating air is then drawn from the air inlet tubes into the crankcase. In this process the air
passes through the hose connecting air inlet tubes to rocker cover. Under full-throttle condition, the manifold
vacuum is insufficient to draw the blow-by flow through the valve. The flow goes through the hose connection
in the reverse direction.
On vehicles with an excessively high blow-by, the valve does not
meet the requirement. This is because some of the flow will go
through the hose connection to the air inlet tubes under all condi-
tions.
Component InspectionNBS003LI
PCV (POSITIVE CRANKCASE VENTILATION) VALVE
With engine running at idle, remove PCV valve from rocker cover. A
properly working valve makes a hissing noise as air passes through
it. A strong vacuum should be felt immediately when a finger is
placed over valve inlet.
SEC921C
PBIB1588E
PBIB1589E
Page 1436 of 4462
EC-52
[VQ35DE]
POSITIVE CRANKCASE VENTILATION
Revision: 2006 December 2006 FX35/FX45
PCV VALVE VENTILATION HOSE
1. Check hoses and hose connections for leaks.
2. Disconnect all hoses and clean with compressed air. If any hose cannot be freed of obstructions, replace.
S-ET277
Page 1437 of 4462
![INFINITI FX35 2006 Service Manual IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS) EC-53
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)PFP:28591
De INFINITI FX35 2006 Service Manual IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS) EC-53
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)PFP:28591
De](/manual-img/42/57019/w960_57019-1436.png)
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS) EC-53
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)PFP:28591
DescriptionNBS003LJ
If the security indicator lights up with the ignition switch in
the ON position or “NATS MALFUNCTION” is displayed on
“SELF-DIAG RESULTS” screen, perform self-diagnostic
results mode with CONSULT-II using NATS program card.
Refer to BL-205, "
IVIS (INFINITI VEHICLE IMMOBILIZER
SYSTEM-NATS)" .
Confirm no self-diagnostic results of IVIS (NATS) is dis-
played before touching “ERASE” in “SELF-DIAG RESULTS”
mode with CONSULT-II.
When replacing ECM, initialization of IVIS (NATS) system
and registration of all IVIS (NATS) ignition key IDs must be
carried out with CONSULT-II using NATS program card.
Therefore, be sure to receive all keys from vehicle owner. Regarding the procedures of IVIS (NATS)
initialization and all IVIS (NATS) ignition key ID registration, refer to CONSULT-II Operation Manual,
IVIS/NVIS.
SEF543X
Page 1438 of 4462
![INFINITI FX35 2006 Service Manual EC-54
[VQ35DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 December 2006 FX35/FX45
ON BOARD DIAGNOSTIC (OBD) SYSTEMPFP:00028
IntroductionNBS003LK
The ECM has an on board diagnostic system, which d INFINITI FX35 2006 Service Manual EC-54
[VQ35DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 December 2006 FX35/FX45
ON BOARD DIAGNOSTIC (OBD) SYSTEMPFP:00028
IntroductionNBS003LK
The ECM has an on board diagnostic system, which d](/manual-img/42/57019/w960_57019-1437.png)
EC-54
[VQ35DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 December 2006 FX35/FX45
ON BOARD DIAGNOSTIC (OBD) SYSTEMPFP:00028
IntroductionNBS003LK
The ECM has an on board diagnostic system, which detects malfunctions related to engine sensors or actua-
tors. The ECM also records various emission-related diagnostic information including:
The above information can be checked using procedures listed in the table below.
× : Applicable —: Not applicable
*: When DTC and 1st trip DTC simultaneously appear on the display, they cannot be clearly distinguished from each other.
The malfunction indicator lamp (MIL) on the instrument panel lights up when the same malfunction is detected
in two consecutive trips (Two trip detection logic), or when the ECM enters fail-safe mode. (Refer to EC-96,
"Fail-Safe Chart" .)
Two Trip Detection LogicNBS003LL
When a malfunction is detected for the 1st time, 1st trip DTC and 1st trip Freeze Frame data are stored in the
ECM memory. The MIL will not light up at this stage. <1st trip>
If the same malfunction is detected again during the next drive, the DTC and Freeze Frame data are stored in
the ECM memory, and the MIL lights up. The MIL lights up at the same time when the DTC is stored. <2nd
trip> The “trip” in the “Two Trip Detection Logic” means a driving mode in which self-diagnosis is performed
during vehicle operation. Specific on board diagnostic items will cause the ECM to light up or blink the MIL,
and store DTC and Freeze Frame data, even in the 1st trip, as shown below.
× : Applicable —: Not applicable
When there is an open circuit on MIL circuit, the ECM cannot warn the driver by lighting up MIL when there is
malfunction on engine control system.
Emission-related diagnostic information Diagnostic service
Diagnostic Trouble Code (DTC) Service $03 of SAE J1979
Freeze Frame data Service $02 of SAE J1979
System Readiness Test (SRT) code Service $01 of SAE J1979
1st Trip Diagnostic Trouble Code (1st Trip DTC) Service $07 of SAE J1979
1st Trip Freeze Frame data
Test values and Test limits Service $06 of SAE J1979
Calibration ID Service $09 of SAE J1979
DTC 1st trip DTC Freeze
Frame data 1st trip Freeze
Frame data SRT code SRT status Test value
CONSULT-II ×× × × × × —
GST ×× × —×××
ECM ××*— — — ×—
Items MIL DTC 1st trip DTC
1st trip 2nd trip 1st trip
displaying 2nd trip
displaying 1st trip
displaying 2nd trip
display- ing
Blinking Lighting
up Blinking
Lighting
up
Misfire (Possible three way cata-
lyst damage) — DTC: P0300 -
P0306 is being detected ×
———— — ×—
Misfire (Possible three way cata-
lyst damage) — DTC: P0300 -
P0306 is being detected ——
×—— ×——
One trip detection diagnoses
(Refer to EC-55, "
EMISSION-
RELATED DIAGNOSTIC INFOR-
MATION ITEMS" .) —
×—— ×———
Except above — — — ×— ×× —
Page 1439 of 4462
![INFINITI FX35 2006 Service Manual ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-55
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
Therefore, when electrical controlled throttle and part of ECM related dia INFINITI FX35 2006 Service Manual ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-55
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
Therefore, when electrical controlled throttle and part of ECM related dia](/manual-img/42/57019/w960_57019-1438.png)
ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-55
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
Therefore, when electrical controlled throttle and part of ECM related diagnoses are continuously detected as
NG for 5 trips, ECM warns the driver that engine control system malfunctions and MIL circuit is open by means
of operating fail-safe function.
The fail-safe function also operates when above diagnoses except MIL circuit are detected and demands the
driver to repair the malfunction.
Emission-Related Diagnostic InformationNBS003LM
EMISSION-RELATED DIAGNOSTIC INFORMATION ITEMS
× : Applicable —: Not applicable
Engine operating condition in fail-safe mode Engine speed will not rise more than 2,500 rpm due to the fuel cut
Items
(CONSULT-II screen terms) DTC*
1
SRT code
Test value/
Test limit
(GST only) Trip
Reference
page
CONSULT-II
GST*
2ECM*3
CAN COMM CIRCUIT U1000 1000*5—— 1 ×EC-156
CAN COMM CIRCUIT U1001
1001*5—— 2 — EC-156
CONTROL UNIT (CAN) U1010 1010 — — 1 ×EC-159
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED. P0000 0000
———
Flashing*8—
INT/V TIM CONT-B1 P0011 0011 — — 2 ×EC-161
INT/V TIM CONT-B2 P0021 0021 — — 2 ×EC-161
A/F SEN1 HTR (B1) P0031 0031 — ×2 ×EC-165
A/F SEN1 HTR (B1) P0032 0032 — ×2 ×EC-165
HO2S2 HTR (B1) P0037 0037 — ×2 ×EC-173
HO2S2 HTR (B1) P0038 0038 — ×2 ×EC-173
A/F SEN1 HTR (B2) P0051 0051 — ×2 ×EC-165
A/F SEN1 HTR (B2) P0052 0052 — ×2 ×EC-165
HO2S2 HTR (B2) P0057 0057 — ×2 ×EC-173
HO2S2 HTR (B2) P0058 0058 — ×2 ×EC-173
INT/V TIM V/CIR-B1 P0075 0075 — — 2 ×EC-181
INT/V TIM V/CIR-B2 P0081 0081 — — 2 ×EC-181
MAF SEN/CIRCUIT P0101 0101 — — 2 ×EC-188
MAF SEN/CIRCUIT P0102 0102 — — 1 ×EC-197
MAF SEN/CIRCUIT P0103 0103 — — 1 ×EC-197
IAT SEN/CIRCUIT P0112 0112 — — 2 ×EC-205
IAT SEN/CIRCUIT P0113 0113 — — 2 ×EC-205
ECT SEN/CIRC P0117 0117 — — 1 ×EC-210
ECT SEN/CIRC P0118 0118 — — 1 ×EC-210
TP SEN 2/CIRC P0122 0122 — — 1 ×EC-215
TP SEN 2/CIRC P0123 0123 — — 1 ×EC-215
ECT SENSOR P0125 0125 — — 2 ×EC-222
IAT SENSOR P0127 0127 — — 2 ×EC-225
THERMSTAT FNCTN P0128 0128 — — 2 ×EC-228
A/F SENSOR1 (B1) P0130 0130 — ×2 ×EC-230
A/F SENSOR1 (B1) P0131 0131 — ×2 ×EC-240
A/F SENSOR1 (B1) P0132 0132 — ×2 ×EC-249
A/F SENSOR1 (B1) P0133 0133 ××2×EC-258
HO2S2 (B1) P0137 0137 ××2×EC-270
Page 1440 of 4462
![INFINITI FX35 2006 Service Manual EC-56
[VQ35DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 December 2006 FX35/FX45
HO2S2 (B1) P0138 0138 ××2×EC-281
HO2S2 (B1) P0139 0139 ××2×EC-294
A/F SENSOR1 (B2) P0150 0150 — ×2 ×EC- INFINITI FX35 2006 Service Manual EC-56
[VQ35DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 December 2006 FX35/FX45
HO2S2 (B1) P0138 0138 ××2×EC-281
HO2S2 (B1) P0139 0139 ××2×EC-294
A/F SENSOR1 (B2) P0150 0150 — ×2 ×EC-](/manual-img/42/57019/w960_57019-1439.png)
EC-56
[VQ35DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 December 2006 FX35/FX45
HO2S2 (B1) P0138 0138 ××2×EC-281
HO2S2 (B1) P0139 0139 ××2×EC-294
A/F SENSOR1 (B2) P0150 0150 — ×2 ×EC-230
A/F SENSOR1 (B2) P0151 0151 — ×2 ×EC-240
A/F SENSOR1 (B2) P0152 0152 — ×2 ×EC-249
A/F SENSOR1 (B2) P0153 0153 ××2×EC-258
HO2S2 (B2) P0157 0157 ××2×EC-270
HO2S2 (B2) P0158 0158 ××2×EC-281
HO2S2 (B2) P0159 0159 ××2×EC-294
FUEL SYS-LEAN-B1 P0171 0171 — — 2 ×EC-305
FUEL SYS-RICH-B1 P0172 0172 — — 2 ×EC-317
FUEL SYS-LEAN-B2 P0174 0174 — — 2 ×EC-305
FUEL SYS-RICH-B2 P0175 0175 — — 2 ×EC-317
FTT SENSOR P0181 0181 — — 2 ×EC-328
FTT SEN/CIRCUIT P0182 0182 — — 2 ×EC-334
FTT SEN/CIRCUIT P0183 0183 — — 2 ×EC-334
TP SEN 1/CIRC P0222 0222 — — 1 ×EC-339
TP SEN 1/CIRC P0223 0223 — — 1 ×EC-339
MULTI CYL MISFIRE P0300 0300 — — 2 ×EC-346
CYL 1 MISFIRE P0301 0301 — — 2 ×EC-346
CYL 2 MISFIRE P0302 0302 — — 2 ×EC-346
CYL 3 MISFIRE P0303 0303 — — 2 ×EC-346
CYL 4 MISFIRE P0304 0304 — — 2 ×EC-346
CYL 5 MISFIRE P0305 0305 — — 2 ×EC-346
CYL 6 MISFIRE P0306 0306 — — 2 ×EC-346
KNOCK SEN/CIRC-B1 P0327 0327 — — 2 — EC-356
KNOCK SEN/CIRC-B1 P0328 0328 — — 2 —EC-356
CKP SEN/CIRCUIT P0335 0335 — — 2×EC-361
CMP SEN/CIRC-B1 P0340 0340 — — 2 ×EC-368
CMP SEN/CIRC-B2 P0345 0345 — — 2 ×EC-368
TW CATALYST SYS-B1 P0420 0420 ××2×EC-377
TW CATALYST SYS-B2 P0430 0430 ××2×EC-377
EVAP PURG FLOW/MON P0441 0441 ××2×EC-383
EVAP SMALL LEAK P0442 0442 ××2×EC-388
PURG VOLUME CONT/V P0443 0443 — — 2 ×EC-397
PURG VOLUME CONT/V P0444 0444 — — 2 ×EC-405
PURG VOLUME CONT/V P0445 0445 — — 2 ×EC-405
VENT CONTROL VALVE P0447 0447 — — 2 ×EC-412
VENT CONTROL VALVE P0448 0448 — — 2 ×EC-419
EVAP SYS PRES SEN P0451 0451 — — 2 ×EC-425
EVAP SYS PRES SEN P0452 0452 — — 2 ×EC-428
EVAP SYS PRES SEN P0453 0453 — — 2 ×EC-434
Items
(CONSULT-II screen terms) DTC*
1
SRT code
Test value/
Test limit
(GST only) Trip
Reference
page
CONSULT-II
GST*
2ECM*3
