FAX-1
FRONT AXLE
D DRIVELINE/AXLE
CONTENTS
C E F
G H
I
J
K L
M
SECTION FA X
A
B
FA X
Revision: 2006 December 2006 FX35/FX45
FRONT AXLE
2WD
PREPARATION ...................................................... ..... 2
Special Service Tools (SST) ................................ ..... 2
Commercial Service Tools ................................... ..... 2
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ........................................... ..... 3
NVH Troubleshooting Chart ................................ ..... 3
FRONT WHEEL HUB AND KNUCKLE ................. ..... 4
On-Vehicle Inspection ......................................... ..... 4
WHEEL BEARING INSPECTION .................... ..... 4
Removal and Installation ..................................... ..... 4
COMPONENTS ............................................... ..... 4
REMOVAL ........................................................ ..... 4
INSPECTION AFTER REMOVAL .................... ..... 5
INSTALLATION ................................................ ..... 5
SERVICE DATA AND SPECIFICATIONS (SDS) ... ..... 6
Wheel Bearing ..................................................... ..... 6
AWD
PRECAUTIONS ..................................................... ..... 7
Caution ................................................................ ..... 7
PREPARATION ...................................................... ..... 8
Special Service Tools (SST) ................................ ..... 8
Commercial Service Tools ................................... ..... 8
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ........................................... ..... 9
NVH Troubleshooting Chart ................................ ..... 9
FRONT WHEEL HUB AND KNUCKLE ................. ... 10
On-Vehicle Inspection ......................................... ... 10 WHEEL BEARING INSPECTION ....................
... 10
Removal and Installation ..................................... ... 10
COMPONENTS ................................................ ... 10
REMOVAL ........................................................ ... 10
INSPECTION AFTER REMOVAL .................... ... 11
INSTALLATION ................................................ ... 11
FRONT DRIVE SHAFT .......................................... ... 12
Removal and Installation (Left Side) .................... ... 12
COMPONENTS ................................................ ... 12
REMOVAL ........................................................ ... 12
INSPECTION AFTER REMOVAL .................... ... 12
INSTALLATION ................................................ ... 12
Removal and Installation (Right Side) ................. ... 13
COMPONENTS ................................................ ... 13
REMOVAL ........................................................ ... 13
INSPECTION AFTER REMOVAL .................... ... 13
INSTALLATION ................................................ ... 14
Disassembly and Assembly (Left Side) ............... ... 14
COMPONENTS ................................................ ... 14
DISASSEMBLY ................................................ ... 15
INSPECTION AFTER DISASSEMBLY ............. ... 15
ASSEMBLY ...................................................... ... 16
Disassembly and Assembly (Right Side) ............. ... 19
COMPONENTS ................................................ ... 19
DISASSEMBLY ................................................ ... 20
INSPECTION AFTER DISASSEMBLY ............. ... 20
ASSEMBLY ...................................................... ... 21
SERVICE DATA AND SPECIFICATIONS (SDS) ... ... 25
Wheel Bearing ..................................................... ... 25
Drive Shaft ........................................................... ... 25
Page 3090 of 4462
FAX-2
[2WD]
PREPARATION
Revision: 2006 December 2006 FX35/FX45
[2WD]PREPARATIONPFP:00002
Special Service Tools (SST)NDS000BU
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsNDS000BV
Tool number
(Kent-Moore No.)
Tool name Description
HT72520000
(J −25730-A)
Ball joint remover
a: 33 mm (1.30 in)
b: 50 mm (1.97 in)
r: 11.5 mm (0.453 in)
Removing steering outer socket
Removing transverse link
NT546
Tool name Description
Power tool
Removing wheel nuts
Removing brake caliper assembly
Removing strut lower side
Removing wheel hub and bearing
assembly
PBIC0190E
Page 3091 of 4462
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING FAX-3
[2WD]
C E F
G H
I
J
K L
M A
B
FA X
Revision: 2006 December 2006 FX35/FX45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartNDS000BW
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
× : Applicable
Reference page
FA X -4—
FA X -4
NVH in WT section
NVH in WT section
NVH in PS section
Possible cause and SUSPECTED PARTS
Improper installation, looseness
Parts interference
Wheel bearing damage
TIRES
ROAD WHEEL
STEERING
Symptom FRONT AXLE Noise
×× ×××
Shake ×× ×××
Vibration ×× × ×
Shimmy ×× ×××
Judder × ×××
Poor quality ride or handling ×××××
Page 3092 of 4462
![INFINITI FX35 2006 Service Manual FAX-4
[2WD]
FRONT WHEEL HUB AND KNUCKLE
Revision: 2006 December 2006 FX35/FX45
FRONT WHEEL HUB AND KNUCKLEPFP:40202
On-Vehicle Inspection NDS000BX
Make sure the mounting conditions (looseness, back la INFINITI FX35 2006 Service Manual FAX-4
[2WD]
FRONT WHEEL HUB AND KNUCKLE
Revision: 2006 December 2006 FX35/FX45
FRONT WHEEL HUB AND KNUCKLEPFP:40202
On-Vehicle Inspection NDS000BX
Make sure the mounting conditions (looseness, back la](/manual-img/42/57019/w960_57019-3091.png)
FAX-4
[2WD]
FRONT WHEEL HUB AND KNUCKLE
Revision: 2006 December 2006 FX35/FX45
FRONT WHEEL HUB AND KNUCKLEPFP:40202
On-Vehicle Inspection NDS000BX
Make sure the mounting conditions (looseness, back lash) of each component and component status (wear,
damage) are normal.
WHEEL BEARING INSPECTION
Move wheel hub in the axial direction by hand. Check that there is no looseness of front wheel bearing.
Rotate wheel hub and make sure there is no unusual noise or other irregular conditions. If there are any
irregular conditions, replace wheel hub and bearing assembly.
Removal and InstallationNDS000BY
COMPONENTS
REMOVAL
1. Remove tires from vehicle with power tool.
2. Remove brake caliper with power tool. Hang it in a place where it will not interfere with work. Refer to BR-
19, "FRONT DISC BRAKE" .
NOTE:
Avoid depressing brake pedal while brake caliper is removed.
3. Put alignment marks on disc rotor and wheel hub and bearing assembly, then remove disc rotor.
4. Remove wheel sensor from wheel hub and bearing assembly. Refer to BRC-55, "
WHEEL SENSORS" .
CAUTION:
Do not pull on wheel sensor harness.
5. Remove cotter pin at steering outer socket, then loosen mount- ing nut. Axial end play : 0.05 mm (0.002 in) or less
1. Disc rotor 2. Wheel hub and bearing assembly 3. Splash guard
4. Steering knuckle 5. Cotter pin
Refer to GI-11, "
Components" , for the symbols in the figure.
PDIA1216E
SDIA1480E
