INFINITI FX35 2006 Service Manual TROUBLE DIAGNOSIS FOR SYSTEM LAN-201
[CAN]
C
D E
F
G H
I
J
L
M A
B
LAN
Revision: 2006 December 2006 FX35/FX45
4. ECM AND IPDM E/R INTERNAL CIRCUIT INSPECTION
1. Remove ECM and IPDM E/R fr

TROUBLE DIAGNOSIS FOR SYSTEM LAN-201
[CAN]
C
D E
F
G H
I
J
L
M A
B
LAN
Revision: 2006 December 2006 FX35/FX45
4. ECM AND IPDM E/R INTERNAL CIRCUIT INSPECTION
1. Remove ECM and IPDM E/R from vehicle.
2. Check resistance between ECM terminals.
3. Check resistance between IPDM E/R terminals.
OK or NG
OK >> GO TO 5.
NG >> Replace ECM and/or IPDM E/R.
5. CHECK SYMPTOM
1. Fill in described symptoms on the column “Symptom” in the check sheet.
2. Connect all connectors, and then make sure that the symptom is reproduced.
Check results
Reproduced>>GO TO 6.
Not reproduced>>Refer to LAN-14, "
Example of Filling in Check Sheet When Initial Conditions Are Not
Reproduced" .
6. CHECK UNIT REPRODUCIBILITY
Performs the following procedure for each unit on the CAN network, and then perform reproducibility test.
1. Turn ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect the unit connector.
4. Connect the battery cable to the negative terminal.
5. Make sure that the symptom filled in the “Symptom” of the check sheet is reproduced. NOTE:
Malfunction (related to a unit that the connector is disconnected) is reproduced. Do not confuse the mal-
function with the symptom filled in the column of “Symptom” on the check sheet.
Inspection results
Reproduced>>Connect the disconnected connector. Check other units applying the above procedure.
Not reproduced>>Replace the unit that the connector is disconnected.
IPDM E/R Ignition Relay Circuit InspectionNKS0039D
Check the following. If no malfunction is found, replace the IPDM E/R.
IPDM E/R power supply circuit. Refer to PG-26, "IPDM E/R Power/Ground Circuit Inspection" .
Ignition power supply circuit. Refer to PG-12, "IGNITION POWER SUPPLY — IGNITION SW. IN “ON”
AND/OR “START”" .
ECM connector Terminals Resistance
(Approx.)
M90 94 86 108 – 132 Ω
IPDM E/R connec- tor Te r m i n a l s Resistance
(Approx.)
E9 48 49 108 – 132 Ω
LKIA0037E
