INFINITI FX35 2006 Service Manual TROUBLE DIAGNOSIS BRC-29
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2006 December 2006 FX35/FX45
Data MonitorNFS000OJ
OPERATION PROCEDURE
1. After turning ignition switch OFF, per

TROUBLE DIAGNOSIS BRC-29
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2006 December 2006 FX35/FX45
Data MonitorNFS000OJ
OPERATION PROCEDURE
1. After turning ignition switch OFF, perform “CONSULT-II Starting Procedure”. Refer to GI-38, "CONSULT-II
Start Procedure" .
2. Turn ignition switch ON.
3. Touch “ABS”, “DATA MONITOR” in order on the CONSULT-II screen. CAUTION:
When “START (NISSAN BASED VHCL)” is touched immediately after starting engine or turning on
ignition switch, “ABS” might not be displayed in the “SYSTEM SELECTION” screen. In this case,
repeat the operation from step 1.
4. Return to the Monitor Item Selection screen, and touch “ECU INPUT SIGNALS”, “MAIN SIGNALS” or “SELECTION FROM MENU”. Refer to the following information.
5. When “START” is touched, the data monitor screen is displayed.
DISPLAY ITEM LIST
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
GEAR ××× Gear position judged by PNP switch signal is displayed.
SLCT LVR POSI ××× Shift position judged by PNP switch signal.
FR RH SENSOR
(km/h) ××× Wheel speed calculated by front RH wheel sensor signal is
displayed.
FR LH SENSOR
(km/h) ××× Wheel speed calculated by front LH wheel sensor signal is
displayed.
RR RH SENSOR
(km/h) ×××
Wheel speed calculated by rear RH wheel sensor signal is
displayed.
RR LH SENSOR
(km/h) ××× Wheel speed calculated by rear LH wheel sensor signal is
displayed.
BATTERY VOLT
(V) ××× Voltage supplied to ABS actuator and electric unit (control
unit) is displayed.
ENGINE SPEED
(rpm) ×××
Engine speed judged by CAN communication signal is dis-
played.
DECEL G-SEN
(G) (AWD models) ××× Longitudinal acceleration detected by decel G sensor is dis-
played.
OFF SW
(ON/OFF)
×× × VDC OFF switch (ON/OFF) status is displayed.
STOP LAMP SW
(ON/OFF) ×××
Stop lamp switch (ON/OFF) status is displayed.
YAW RATE SEN
(d/s) ××
– Yaw rate detected by yaw rate sensor is displayed.
ACCEL POS SIG
(%) ×
–– Throttle valve open/close status judged by CAN communica-
tion signal is displayed.
STR ANGLE SIG
(deg) ×
–– Steering angle detected by steering angle sensor is dis-
played.
SIDE G-SENSOR
(m/s
2 ) ×
– – Lateral acceleration detected by side G sensor is displayed.
PRESS SENSOR
(bar) ×
–– Brake fluid pressure detected by pressure sensor is dis-
played.
FLUID LEV SW
(ON/OFF) ×
– – Brake fluid level switch (ON/OFF) status is displayed.
ABS WARN LAMP
(ON/OFF) –
×× ABS warning lamp (ON/OFF) status is displayed.
SLIP LAMP
(ON/OFF) –
×× SLIP indicator lamp (ON/OFF) status is displayed.

Page 1162 of 4462

INFINITI FX35 2006 Service Manual BRC-30
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2006 December 2006 FX35/FX45
FR LH IN SOL
(ON/OFF) –
×× Front LH IN ABS solenoid (ON/OFF) status is displayed.
FR LH OUT SOL
(ON/OFF) –
×

BRC-30
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2006 December 2006 FX35/FX45
FR LH IN SOL
(ON/OFF) –
×× Front LH IN ABS solenoid (ON/OFF) status is displayed.
FR LH OUT SOL
(ON/OFF) –
×× Front LH OUT ABS solenoid (ON/OFF) status is displayed.
RR RH IN SOL
(ON/OFF) –
×× Rear RH IN ABS solenoid (ON/OFF) status is displayed.
RR RH OUT SOL
(ON/OFF) –
×× Rear RH OUT ABS solenoid (ON/OFF) status is displayed.
FR RH IN SOL
(ON/OFF) –
×× Front RH IN ABS solenoid (ON/OFF) status is displayed.
FR RH OUT SOL
(ON/OFF) –
×× Front RH OUT ABS solenoid (ON/OFF) status is displayed.
RR LH IN SOL
(ON/OFF) –
×× Rear LH IN ABS solenoid (ON/OFF) status is displayed.
RR LH OUT SOL
(ON/OFF) –
×× Rear LH OUT ABS solenoid (ON/OFF) status is displayed.
OFF LAMP
(ON/OFF) –
×× OFF Lamp (ON/OFF) status is displayed.
MOTOR RELAY
(ON/OFF) –
×× ABS motor relay signal (ON/OFF) status is displayed.
ACTUATOR RLY
(ON/OFF) –
×× ABS actuator relay signal (ON/OFF) status is displayed.
CV1
(ON/OFF) ––
× Primary side switch-over solenoid valve 1 (cut valve 1) (ON/
OFF) status is displayed.
CV2
(ON/OFF) ––
× Secondary side switch-over solenoid valve 2 (cut-valve 2)
(ON/OFF) status is displayed.
SV1
(ON/OFF) ––
× Primary side switch-over solenoid valve 1 (suction valve 1)
(ON/OFF) status is displayed.
SV2
(ON/OFF) ––
× Secondary side switch-over solenoid valve 2 (suction valve 2)
(ON/OFF) status is displayed.
VDC FAIL SIG
(ON/OFF) ––
×VDC fail signal (ON/OFF) status is displayed.
TCS FAIL SIG
(ON/OFF) ––
×TCS fail signal (ON/OFF) status is displayed.
ABS FAIL SIG
(ON/OFF) ––
×ABS fail signal (ON/OFF) status is displayed.
EBD FAIL SIG
(ON/OFF) ––
×EBD fail signal (ON/OFF) status is displayed.
EBD SIGNAL
(ON/OFF) ––
×EBD operation (ON/OFF) status is displayed.
ABS SIGNAL
(ON/OFF) ––
×ABS operation (ON/OFF) status is displayed.
TCS SIGNAL
(ON/OFF) ––
×TCS operation (ON/OFF) status is displayed.
VDC SIGNAL
(ON/OFF) ––
×VDC operation (ON/OFF) status is displayed.
EBD WARN LAMP
(ON/OFF) ––
×Brake warning lamp (ON/OFF) status is displayed. (Note)
CRANKING SIG
(ON/OFF) ––
×Cranking condition (ON/OFF) status is displayed.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU

Page 1163 of 4462

INFINITI FX35 2006 Service Manual TROUBLE DIAGNOSIS BRC-31
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2006 December 2006 FX35/FX45
× :Applicable
–:Not applicable
Note: Serves as EBD warning lamp.
Active TestN
