Page 657 of 4462

INFINITI FX35 2006 Service Manual ANTENNA AV-51 C D E F G H I J L M A B AV Revision: 2006 December 2006 FX35/FX45 Location of AntennaNKS003LT RADIO ANTENNA AND GPS ANTENNA SATELLITE RADIO ANTENNA PKIB5079E SKIB8640E

Page 658 of 4462

INFINITI FX35 2006 Service Manual AV-52 ANTENNA Revision: 2006 December 2006 FX35/FX45 Window Antenna RepairNKS003LU CHECK ELEMENT 1. Attach probe circuit tester (ohm setting) to antenna terminal on each side. When measuring continui

Page 659 of 4462

INFINITI FX35 2006 Service Manual ANTENNA AV-53 C D E F G H I J L M A B AV Revision: 2006 December 2006 FX35/FX45 3. To locate a break, move probe along element. Tester needle will swing abruptly when probe passes the bro

Page 660 of 4462

INFINITI FX35 2006 Service Manual AV-54 INTEGRATED DISPLAY SYSTEM Revision: 2006 December 2006 FX35/FX45 INTEGRATED DISPLAY SYSTEMPFP:28090 System DescriptionNKS003IZ For system operation information, refer to Owners Manual. INTEGRAT

Page 661 of 4462

INFINITI FX35 2006 Service Manual INTEGRATED DISPLAY SYSTEM AV-55 C D E F G H I J L M A B AV Revision: 2006 December 2006 FX35/FX45 Component DescriptionNKS003J0 DISPLAY CONTROL UNIT Display control unit draws a status of

Page 662 of 4462

INFINITI FX35 2006 Service Manual AV-56 INTEGRATED DISPLAY SYSTEM Revision: 2006 December 2006 FX35/FX45 Schematic — INF/D —NKS003J3 TKWM4411E

Page 663 of 4462

INFINITI FX35 2006 Service Manual INTEGRATED DISPLAY SYSTEM AV-57 C D E F G H I J L M A B AV Revision: 2006 December 2006 FX35/FX45 Wiring Diagram — INF/D — NKS003J4 TKWM4412E

Page 664 of 4462

INFINITI FX35 2006 Service Manual AV-58 INTEGRATED DISPLAY SYSTEM Revision: 2006 December 2006 FX35/FX45 TKWM4413E
