CYLINDER BLOCK EM-127
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
10. Remove pilot converter using the pilot bushing puller (SST) as necessary.
11. Remove rear oil seal retainer.
Remove by inserting a screwdriver between main bearing cap and rear oil seal retainer.
CAUTION:
If rear oil seal retainer is removed, replace it with new one.
NOTE:
Regard both rear oil seal and retainer as an assembly.
12. Remove baffle plate from main bearing beam (2WD models).
13. Remove piston and connecting rod assembly with the following procedure:
Before removing piston and connecting rod assembly, check the connecting rod side clearance. Refer
to EM-141, "
CONNECTING ROD SIDE CLEARANCE" .
CAUTION:
Be careful not to drop connecting rod bearing, and to scratch the surface.
a. Position crankshaft pin corresponding to connecting rod to be removed onto the bottom dead center.
b. Remove connecting rod bearing cap.
c. Using a hammer handle or similar tool, push piston and connect- ing rod assembly out to the cylinder head side.
CAUTION:
Be careful not to damage the cylinder wall and crankshaft
pin, resulting from an interference of the connecting rod big
end.
14. Remove connecting rod bearings from connecting rod and connecting rod bearing cap. CAUTION:
Be careful not to drop connecting rod bearing, and to scratch the surface.
Identify installation positions, and store them without mixing them up.
15. Remove piston rings form piston.
Before removing piston rings, check the piston ring side clearance. Refer to EM-142, "PISTON RING
SIDE CLEARANCE" .
Use a piston ring expander (commercial service tool).
CAUTION:
When removing piston rings, be careful not to damage
piston.
Be careful not to damage piston rings by expanding them
excessively.
SEM005G
EMQ0191D
PBIC0087E
Page 2922 of 4462
EM-128
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 December 2006 FX35/FX45
16. Remove piston from connecting rod as follows:
a. Using a snap ring pliers, remove snap rings.
b. Heat piston to 60 to 70 °C (140 to 158 °F) with an industrial use
drier or equivalent.
c. Push out piston pin with stick of outer diameter approximately 20 mm (0.79 in).
17. Remove main bearing cap bolts. NOTE:
Use TORX socket (size E14).
Before loosening main bearing cap bolts, measure the crankshaft end play. Refer to EM-141, "CRANK-
SHAFT END PLAY" .
Loosen main bearing cap bolts in the reverse order shown in
the figure in several different steps.
PBIC1638E
PBIC1639E
PBIC0262E
PBIC1800E
Page 2923 of 4462
![INFINITI FX35 2006 Service Manual CYLINDER BLOCK EM-129
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
18. Remove main bearing beam.
19. Remove main bearing caps. CAUTION:
Be careful not to d INFINITI FX35 2006 Service Manual CYLINDER BLOCK EM-129
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
18. Remove main bearing beam.
19. Remove main bearing caps. CAUTION:
Be careful not to d](/manual-img/42/57019/w960_57019-2922.png)
CYLINDER BLOCK EM-129
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
18. Remove main bearing beam.
19. Remove main bearing caps. CAUTION:
Be careful not to drop main bearing, and to scratch the sur-
face.
Using main bearing cap bolts, remove main bearing cap while
shaking it back-and-forth.
20. Remove crankshaft.
21. Remove main bearings and thrust bearings from cylinder block and main bearing caps. CAUTION:
Be careful not to drop main bearing, and to scratch the surface.
Identify installation positions, and store them without mixing them up.
22. Remove oil jet.
ASSEMBLY
1. Fully air-blow engine coolant and engine oil passages in cylinder block, cylinder bore and crankcase to remove any foreign material.
CAUTION:
Use a goggles to protect your eye.
2. Install each plug to cylinder block as shown in the figure.
Apply sealant to the thread of water drain plugs “A”, “B” and
“C”.
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-48, "
RECOMMENDED CHEMICAL PRODUCTS AND
SEALANTS" .
Apply sealant to the thread of plugs “D” and “E”.
Use Genuine High Strength Thread Locking Sealant or
equivalent. Refer to GI-48, "
RECOMMENDED CHEMICAL
PRODUCTS AND SEALANTS" .
Apply sealant to the thread of plug “F”.
Use Anaerobic Liquid Gasket or equivalent. Refer to GI-
48, "RECOMMENDED CHEMICAL PRODUCTS AND SEAL-
ANTS" .
NOTE:
For Canada, “F” in the figure is not plug but block heater.
Refer to EM-123, "
Components" .
Replace washers with new one.
PBIC0881E
EMQ0195D
PBIC2610E
Page 2924 of 4462
![INFINITI FX35 2006 Service Manual EM-130
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 December 2006 FX35/FX45
Tighten each plug as specified below.
3. Install oil jet.
Insert oil jet dowel pin into cylinder block dowel pin hole, and
tig INFINITI FX35 2006 Service Manual EM-130
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 December 2006 FX35/FX45
Tighten each plug as specified below.
3. Install oil jet.
Insert oil jet dowel pin into cylinder block dowel pin hole, and
tig](/manual-img/42/57019/w960_57019-2923.png)
EM-130
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 December 2006 FX35/FX45
Tighten each plug as specified below.
3. Install oil jet.
Insert oil jet dowel pin into cylinder block dowel pin hole, and
tighten mounting bolts.
4. Install main bearings and thrust bearings as follows: CAUTION:
Be careful not to drop main bearing, and to scratch the surface.
a. Remove dust, dirt, and engine oil on bearing mating surfaces of cylinder block and main bearing caps.
b. Install thrust bearings to the both sides of the No. 3 journal hous- ing on cylinder block and main bearing cap.
Install thrust bearings with the oil groove facing crankshaft
arm (outside).
Install thrust bearing with a protrusion on one end on cylinder
block, and thrust bearing with a protrusion at center on main
bearing cap. Align each protrusion with mating notch.
c. Install main bearings paying attention to the direction.
Main bearing with oil hole and groove goes on cylinder block.
The one without them goes on main bearing cap.
Before installing main bearings, apply engine oil to the bear-
ing surface (inside). Do not apply engine oil to the back sur-
face, but thoroughly clean it.
When installing, align main bearing stopper protrusion to cut-
out of cylinder block and main bearing caps.
Ensure the oil holes on cylinder block and those on the corre-
sponding bearing are aligned.
5. Install crankshaft to cylinder block.
While turning crankshaft by hand, check that it turns smoothly.
6. Install main bearing cap.
Part Washer Tightening torque
A No 9.8 N·m (1.0 kg-m, 87 in-lb)
B No 19.6 N·m (2.0 kg-m, 14 ft-lb)
C No 19.6 N·m (2.0 kg-m, 14 ft-lb)
D Yes 12.3 N·m (1.3 kg-m, 9 ft-lb) E Yes 62 N·m (6.3 kg-m, 46 ft-lb) F Yes 62 N·m (6.3 kg-m, 46 ft-lb)
PBIC0898E
PBIC0807E
PBIC2489E
Page 2925 of 4462
![INFINITI FX35 2006 Service Manual CYLINDER BLOCK EM-131
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
Main bearing caps are identified by identification mark cast on
them. For installation, f INFINITI FX35 2006 Service Manual CYLINDER BLOCK EM-131
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
Main bearing caps are identified by identification mark cast on
them. For installation, f](/manual-img/42/57019/w960_57019-2924.png)
CYLINDER BLOCK EM-131
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
Main bearing caps are identified by identification mark cast on
them. For installation, face front mark to front side.
NOTE:
Main bearing cap cannot be replaced as a single part, because it
is machined together with cylinder block.
7. Install main bearing beam.
Install main bearing beam with front mark facing downward (oil pan side).
Install main bearing beam with front mark facing front of the
engine.
8. Install main bearing cap bolts in numerical order as shown in the figure as follows:
a. Inspect the outer diameter of main bearing cap bolt. Refer to EM-149, "
MAIN BEARING CAP BOLT OUTER DIAMETER" .
b. Apply new engine oil to threads and seat surfaces of main bear- ing cap bolts.
c. Tighten main bearing cap bolts in several different steps.
d. Turn all main bearing cap bolts 90 degrees clockwise (Angle tightening).
CAUTION:
Use the angle wrench [SST: KV10112100 (BT8653-A)] to
check tightening angle. Do not make judgment by visual
inspection.
After installing main bearing cap bolts, make sure that crank-
shaft can be rotated smoothly by hand.
Check the crankshaft end play. Refer to EM-141, "CRANK-
SHAFT END PLAY" .
9. Install piston to connecting rod as follows:
a. Using a snap ring pliers, install new snap ring to the groove of piston rear side.
Insert it fully into groove to install.
b. Install piston to connecting rod.
Using an industrial use drier or similar tool, heat piston until piston pin can be pushed in by hand without
excess force [approx. 60 to 70 °C (140 to 158 °F)]. From the front to the rear, insert piston pin into piston
and connecting rod.
SEM456G
PBIC0881E
: 35.3 N·m (3.6 kg-m, 26 ft-lb)
PBIC1800E
PBIC0921E
Page 2926 of 4462
![INFINITI FX35 2006 Service Manual EM-132
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 December 2006 FX35/FX45
Assemble so that the front mark on the piston head and the
cylinder number on connecting rod are positioned as shown in
the figu INFINITI FX35 2006 Service Manual EM-132
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 December 2006 FX35/FX45
Assemble so that the front mark on the piston head and the
cylinder number on connecting rod are positioned as shown in
the figu](/manual-img/42/57019/w960_57019-2925.png)
EM-132
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 December 2006 FX35/FX45
Assemble so that the front mark on the piston head and the
cylinder number on connecting rod are positioned as shown in
the figure.
c. Install new snap ring to the groove of the piston front side.
Insert it fully into groove to install.
After installing, make sure that connecting rod moves
smoothly.
10. Using a piston ring expander (commercial service tool), install piston rings.
CAUTION:
When installing piston rings, be careful not to damage
piston.
Be careful not to damage piston rings by expending them
excessively.
If there is stamped mark on ring, mount it with marked side
up.
NOTE:
If there is no stamp on ring, no specific orientation is required
for installation.
Position each ring with the gap as shown in the figure refer-
ring to the piston front mark.
Check the piston ring side clearance. Refer to EM-142, "PISTON RING SIDE CLEARANCE" .
11. Install connecting rod bearings to connecting rod and connecting rod bearing cap. CAUTION:
Be careful not to drop connecting rod bearing, and to scratch the surface.
Before installing connecting rod bearings, apply engine oil to the bearing surface (inside). Do not apply
engine oil to the back surface, but thoroughly clean it.
SEM838F
PBIC0087E
Stamped mark:
Top ring : —
Second ring : “R”
SEM757G
PBIC0808E
Page 2927 of 4462
![INFINITI FX35 2006 Service Manual CYLINDER BLOCK EM-133
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
When installing, align connecting rod bearing stopper protru-
sion with cutout of connect INFINITI FX35 2006 Service Manual CYLINDER BLOCK EM-133
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
When installing, align connecting rod bearing stopper protru-
sion with cutout of connect](/manual-img/42/57019/w960_57019-2926.png)
CYLINDER BLOCK EM-133
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
When installing, align connecting rod bearing stopper protru-
sion with cutout of connecting rods and connecting rod bear-
ing caps to install.
Ensure the oil hole on connecting rod and that on the corre-
sponding bearing are aligned.
12. Install piston and connecting rod assembly to crankshaft.
Position crankshaft pin corresponding to connecting rod to be installed onto the bottom dead center.
Apply engine oil sufficiently to the cylinder bore, piston and crankshaft pin journal.
Match the cylinder position with the cylinder number on connecting rod to install.
Be sure that front mark on piston crown is facing front of engine.
Using a piston ring compressor (SST) or suitable tool, install
piston with the front mark on the piston crown facing the front
of the engine.
CAUTION:
Be careful not to damage the cylinder wall and crankshaft
pin, resulting from an interference of the connecting rod big
end.
13. Install connecting rod bearing cap.
Match the stamped cylinder number marks on connecting rod
with those on connecting rod bearing cap to install.
Be sure that front mark on connecting rod bearing cap is fac-
ing front of the engine.
14. Tighten connecting rod bolt as follows:
a. Inspect the outer diameter of connecting rod bolt. Refer to EM-150, "
CONNECTING ROD BOLT OUTER
DIAMETER" .
b. Apply engine oil to the threads and seats of connecting rod bolts.
c. Tighten connecting rod bolts.
PBIC2067E
PBIC2945E
PBIC0809E
: 19.6 N·m (2.0 kg-m, 14 ft-lb)
Page 2928 of 4462
![INFINITI FX35 2006 Service Manual EM-134
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 December 2006 FX35/FX45
d. Then tighten all connecting rod bolts 90 degrees clockwise (Angle tightening).
CAUTION:
Always use the angle wrench [SST: KV1 INFINITI FX35 2006 Service Manual EM-134
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 December 2006 FX35/FX45
d. Then tighten all connecting rod bolts 90 degrees clockwise (Angle tightening).
CAUTION:
Always use the angle wrench [SST: KV1](/manual-img/42/57019/w960_57019-2927.png)
EM-134
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 December 2006 FX35/FX45
d. Then tighten all connecting rod bolts 90 degrees clockwise (Angle tightening).
CAUTION:
Always use the angle wrench [SST: KV10112100 (BT8653-
A)]. Avoid tightening based on visual check alone.
After tightening connecting rod bolts, make sure that crank-
shaft rotates smoothly.
Check the connecting rod side clearance. Refer to EM-141,
"CONNECTING ROD SIDE CLEARANCE" .
15. Install baffle plate to main bearing beam (2WD models).
16. Install new rear oil seal retainer to cylinder block.
Apply new engine oil to both oil seal lip and dust seal lip.
Apply a continuous bead of liquid gasket with the tube presser
[SST: WS39930000 ( — )] to rear oil seal retainer as
shown in the figure.
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-48, "
RECOMMENDED CHEMICAL PRODUCTS AND
SEALANTS" .
CAUTION:
Replace with a new parts.
Attaching should be done within 5 minutes after coating.
Make sure the garter spring is in position and seal lips
not inverted.
NOTE:
Regard both rear oil seal and retainer as an assembly.
17. Install pilot converter.
With a drift [outer diameter: approx. 33 mm (1.30 in)], press-fit
as far as it will go.
Press-fit pilot converter with its chamfer facing crankshaft as
shown in the figure.
SEM953E
PBIC2661E
PBIC0899E
SEM537E
