ACCELERATOR CONTROL SYSTEMPFP:18005
ComponentsNBS004IQ
Removal and InstallationNBS005S6
REMOVAL
1. Disconnect accelerator pedal position sensor harness connector.
2. Loosen mounting nuts, and remove accelerator pedal assembly.
CAUTION:

Do not disassemble accelerator pedal assembly. Do not remove accelerator pedal position sen-
sor from accelerator pedal assembly.

Avoid impact from dropping etc. during handling.

Be careful to keep accelerator pedal assembly away from water.
INSTALLATION
Installation is the reverse order of removal.
INSPECTION AFTER INSTALLATION

Make sure accelerator pedal moves smoothly within the whole operation range when it is fully depressed
and released.

Make sure accelerator pedal securely returns to the fully released position.

For the electrical inspection of accelerator pedal position sensor, refer to the following.
–VQ35DE
EC-575, "
DTC P2122, P2123 APP SENSOR", EC-582, "DTC P2127, P2128 APP SENSOR" and EC-596,
"DTC P2138 APP SENSOR"
–VK45DE
EC-1254, "
DTC P2122, P2123 APP SENSOR", EC-1261, "DTC P2127, P2128 APP SENSOR" and EC-
1275, "DTC P2138 APP SENSOR"
CAUTION:
When harness connector of accelerator pedal position sensor is disconnected, perform “Acceler-
ator Pedal Released Position Learning”. Refer to EC-84, "
Accelerator Pedal Released Position
Learning" (VQ35DE) or EC-743, "Accelerator Pedal Released Position Learning" (VK45DE).
1. Accelerator pedal assembly
SBIA0332E
