BCS-8
BCM (BODY CONTROL MODULE)
Revision: 2006 December 2006 FX35/FX45
SYSTEMS CONTROLLED BY BCM DIRECTLY
NOTE:
Power supply only. No system control.
SYSTEMS CONTROLLED BY BCM AND IPDM E/R
SYSTEMS CONTROLLED BY BCM AND COMBINATION METER
SYSTEMS CONTROLLED BY BCM AND INTELLIGENT KEY UNIT
System Reference
Power door lock BL-21, "
POWER DOOR LOCK SYSTEM"
Remote keyless entryBL-54, "REMOTE KEYLESS ENTRY SYSTEM"
Power window NOTEGW-15, "POWER WINDOW SYSTEM"
Sunroof NOTERF-10, "SUNROOF"
Room lamp timerLT-156, "INTERIOR ROOM LAMP"
Warning chimeDI-56, "WARNING CHIME"
Rear wiperWW-39, "REAR WIPER AND WASHER SYSTEM"
Low tire pressure warning systemWT-10, "LOW TIRE PRESSURE WARNING SYSTEM"
System Reference
Panic alarm BL-54, "
REMOTE KEYLESS ENTRY SYSTEM"
Theft warningBL-180, "VEHICLE SECURITY (THEFT WARNING) SYSTEM"
IVIS (NATS)BL-205, "IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)"
HeadlampLT- 7 , "HEADLAMP - XENON TYPE -"
Daytime light LT- 3 9 , "DAYTIME LIGHT SYSTEM"
Auto light systemLT- 5 6 , "AUTO LIGHT SYSTEM"
Parking, license plate, side marker and tail lamps
Battery saver control LT-133, "PARKING, LICENSE PLATE AND TAIL LAMPS"
Front fog lamp
LT- 7 8 , "FRONT FOG LAMP"
Front wiperWW-4, "FRONT WIPER AND WASHER SYSTEM"
Rear window defoggerGW-67, "REAR WINDOW DEFOGGER"
System Reference
Warning chime DI-56, "
WARNING CHIME"
Turn signal and hazard warning lampsLT- 9 0 , "TURN SIGNAL AND HAZARD WARNING LAMPS"
Daytime light systemLT- 3 9 , "DAYTIME LIGHT SYSTEM"
System Reference
Intelligent Key BL-86, "
INTELLIGENT KEY SYSTEM"
BL-196
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 December 2006 FX35/FX45
Trouble Diagnosis Symptom ChartNIS001PD
*1: Make sure the system is in the armed phase. Procedure
Diagnostic procedure Refer to page
Symptom
1 Vehicle security
system cannot be
set by ···· Door switch Diagnostic Procedure 1 (Check door, hood and back door switch)
BL-197
Lock / unlock switch Diagnostic Procedure 6 (Check door lock / unlock switch)BL-204
Door outside key Diagnostic Procedure 3 (Check door key cylinder switch)BL-204
Key fob Check remote keyless entry. BL-54
Intelligent Key Check Intelligent Key.BL-86
— If the above systems are “OK”, replace BCM.BCS-15
Security indicator does not turn “ON”. Diagnostic Procedure 2 (Check security indicator lamp)
BL-203If the above systems are “OK”, replace BCM.BCS-15
2 *1 Vehicle secu-
rity system does
not alarm when
···· Any door is opened. Diagnostic Procedure 1 (Check door, hood and back door switch)
BL-197If the above systems are “OK”, replace BCM.BCS-15
3 Vehicle security
alarm does not
activate. Horn alarm
Diagnostic Procedure 4 (Check vehicle security horn alarm)
BL-204
Check horn function. BL-80
If the above systems are “OK”, replace BCM.BCS-15
Head lamp alarm Diagnostic Procedure 5 (Check head lamp alarm)
BL-204If the above systems are “OK”, replace BCM.BCS-15
4 Vehicle security
system cannot be
canceled by ···· Door outside key
Diagnostic Procedure 3 (Check door key cylinder switch)
BL-204
If the above systems are “OK”, check power window main switch. EI-35
Key fob Check remote keyless entry function.
BL-55If the above systems are “OK”, replace BCM.BCS-15
Intelligent Key Check Intelligent Key
BL-88If the above systems are “OK”, replace BCM.BCS-15
