Page 601 of 4331

NISSAN LATIO 2009 Service Repair Manual BL-140< SERVICE INFORMATION > INTELLIGENT KEY SYSTEM4. CHECK TRUNK OPENER REQU EST SWITCH GROUND CIRCUIT Check continuity between trunk opener request switch connector B129 terminal 2 and ground. OK o

Page 602 of 4331

NISSAN LATIO 2009 Service Repair Manual BL N O P 4. Check continuity between Intelligent Key unit connector and ground. OK or NG OK >> GO TO 3 NG >> Repair or replace harness between Intelligent Key unit and front door loc

Page 603 of 4331

NISSAN LATIO 2009 Service Repair Manual BL-142< SERVICE INFORMATION > INTELLIGENT KEY SYSTEM OK or NG OK >> Replace front door lock actuator LH (door unlock sen- sor). Refer to BL-166, " Removal and Installation " . NG >> Replace I

Page 604 of 4331

NISSAN LATIO 2009 Service Repair Manual BL N O P OK or NG OK >> Intelligent Key warning buzzer is OK. NG >> Replace inoperative Intelligent Key warning buzzer. Outside Key Antenna (Driver Si de and Passenger Side) Check INFOID:0000000004305

Page 605 of 4331

NISSAN LATIO 2009 Service Repair Manual OK >> GO TO 4 NG >> Repair or replace harness between Intelligent Key unit and outside key antenna. OK >> Replace malfunctioning outside key antenna. NG >> Replace Intelligent Key unit. Refer to BL-1

Page 606 of 4331

NISSAN LATIO 2009 Service Repair Manual BL N O P Do the hazard lamps flash? Yes >> Rear bumper antenna is OK. No >> GO TO 2 OK >> Rear bumper antenna is OK. NG >> GO TO 3 OK >> GO TO 4 NG >> Repair or replace harness between Intelligent Key

Page 607 of 4331

NISSAN LATIO 2009 Service Repair Manual BL-146< SERVICE INFORMATION > INTELLIGENT KEY SYSTEM OK or NG OK >> Replace rear bumper antenna. NG >> Replace Intelligent Key unit. Refer to BL-158, " Removal and Installation of Intelligent Key Uni

Page 608 of 4331

NISSAN LATIO 2009 Service Repair Manual INTELLIGENT KEY SYSTEM BL-147 < SERVICE INFORMATION > C D E F G H J K L M A B BL N O P OK or NG OK >> GO TO 3 NG >> Repair or replace harness between Intelligent Key unit and inside key antenna. 3. CH
