Page 1881 of 4331

NISSAN LATIO 2009 Service Repair Manual EC NP O RESUME OPERATION When the RESUME/ACCELERATE swit ch is depressed after cancel operation other than depressing MAIN switch is performed, vehicle speed will return to last set speed.

Page 1882 of 4331

NISSAN LATIO 2009 Service Repair Manual CAN Communication Signal Chart " , about CAN communication for detail.

Page 1883 of 4331

NISSAN LATIO 2009 Service Repair Manual EC NP O EVAPORATIVE EMISSION SYSTEM Description INFOID:0000000004537028 SYSTEM DESCRIPTION The evaporative emission system is used to reduce hydr ocarbons emitted into the atmosphere from

Page 1884 of 4331

NISSAN LATIO 2009 Service Repair Manual EC-528< SERVICE INFOMATION > [MR TYPE 1] EVAPORATIVE EMISSION SYSTEM NOTE: Do not use soapy water or any type of so lvent while installing vacuum hose or purge hoses. : Vehicle front :From next figure

Page 1885 of 4331

NISSAN LATIO 2009 Service Repair Manual EVAPORATIVE EMISSION SYSTEM EC-529 < SERVICE INFOMATION > [MR TYPE 1] C D E F G H I J K L M A EC NP O Component Inspection INFOID:0000000004537029 EVAP CANISTER (A): To previous figure 1. EVAP control

Page 1886 of 4331

NISSAN LATIO 2009 Service Repair Manual EC-530< SERVICE INFOMATION > [MR TYPE 1] EVAPORATIVE EMISSION SYSTEM Check EVAP canister as follows: 1. Block port B. 2. Blow air into port Aand check that it flows freely out of port C. 3. Release

Page 1887 of 4331

NISSAN LATIO 2009 Service Repair Manual EVAPORATIVE EMISSION SYSTEM EC-531 < SERVICE INFOMATION > [MR TYPE 1] C D E F G H I J K L M A EC NP O Positive pressure is delivered to the EVAP system through the EVAP service port. If fuel vapor lea

Page 1888 of 4331

NISSAN LATIO 2009 Service Repair Manual EC-532< SERVICE INFOMATION > [MR TYPE 1] EVAPORATIVE EMISSION SYSTEM 3. Turn ignition switch ON. 4. Select the “EVAP SYSTEM CLOSE” of “WORK SUPPORT” mode with CONSULT-III. 5. Touch “START
