Page 1729 of 4331

NISSAN LATIO 2009 Service Repair Manual EC NP O 3. Check if foreign matter is c aught between the throttle valve (1) and the housing. - Electric throttle control actuator (2) Is the inspection result normal? YES >> GO TO 2. NO >>

Page 1730 of 4331

NISSAN LATIO 2009 Service Repair Manual EC-374< COMPONENT DIAGNOSIS > [HR16DE] P1226 TP SENSOR P1226 TP SENSOR Description INFOID:0000000004780257 Electric throttle control actuator consists of throttle control motor, throttle posit

Page 1731 of 4331

NISSAN LATIO 2009 Service Repair Manual P1226 TP SENSOR EC-375 < COMPONENT DIAGNOSIS > [HR16DE] C D E F G H I J K L M A EC NP O 3. Check if foreign matter is c aught between the throttle valve (1) and the housing. - Electric throt

Page 1732 of 4331

NISSAN LATIO 2009 Service Repair Manual YES >> Go to EC-376, " Diagnosis Procedure " . NO >> INSPECTION END Diagnosis Procedure INFOID:0000000004780263IDLE AIR VOLUME LEARNING : Special Repair Requirement " . Is Idle Air Volume Learning ca

Page 1733 of 4331

NISSAN LATIO 2009 Service Repair Manual EC NP O Is the inspection result normal? YES >> GO TO 3. NO >> Repair or replace malfunctioning part DTC Logic " . Is the inspection result normal? YES >> GO TO 4. NO >> Go to EC-231, " Diagnosis Pro

Page 1734 of 4331

NISSAN LATIO 2009 Service Repair Manual DTC Logic " . • If DTC P1715 is displayed with DTC P0340, first pe rform the trouble diagnosis for DTC P0340. Refer to EC-268, " DTC Logic " . • If DTC P1715 is displayed with DTC P0605, first pe

Page 1735 of 4331

NISSAN LATIO 2009 Service Repair Manual EC NP O >> INSPECTION END

Page 1736 of 4331

NISSAN LATIO 2009 Service Repair Manual YES >> Go to EC-381, " Diagnosis Procedure " . NO >> INSPECTION END DTC No. Trouble diagnosis name DTC detecting condition Possible cause P1805 Brake switch A brake switch signal is not sent to ECM
