Page 4329 of 4331

NISSAN LATIO 2009 Service Repair Manual WW N O P 2. Remove the power socket (2) from the power socket ring (3), while pressing the hook (A) on the ring out from square hole (B). • Console mask (1) • Power socket cutout (C) INS

Page 4330 of 4331

NISSAN LATIO 2009 Service Repair Manual Removal and Installation " . B

Page 4331 of 4331

NISSAN LATIO 2009 Service Repair Manual WW N O P 2. Disconnect the horn connector. 3. Remove the horn nut (A) and remove the horn (1). INSTALLATION Installation is in the reverse order of removal.
