2009 NISSAN LATIO Service Repair Manual

jack points radio controls cruise control fuse box ECU checking oil

Load previous 8 pages

Page 2393 of 4331

NISSAN LATIO 2009 Service Repair Manual EVAPORATIVE EMISSION SYSTEM
EC-1037
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
NOTE: Do not use soapy water or any type of so
lvent while installing vacuum hose or purge hoses.

Page 2394 of 4331

NISSAN LATIO 2009 Service Repair Manual EC-1038< SERVICE INFOMATION >
[MR TYPE 2]
EVAPORATIVE EMISSION SYSTEM
Component Inspection INFOID:0000000004499915
EVAP CANISTER (A): To previous figure
1. EVAP control system pressure sensor 2. EVAP

Page 2395 of 4331

NISSAN LATIO 2009 Service Repair Manual EVAPORATIVE EMISSION SYSTEM
EC-1039
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
Check EVAP canister as follows:
1. Block port B.
2. Blow air into port Aand check that it flows

Page 2396 of 4331

NISSAN LATIO 2009 Service Repair Manual EC-1040< SERVICE INFOMATION >
[MR TYPE 2]
EVAPORATIVE EMISSION SYSTEM
Positive pressure is delivered to the EVAP system through the EVAP
service port. If fuel vapor leak age in the EVAP system occurs,

Page 2397 of 4331

NISSAN LATIO 2009 Service Repair Manual EVAPORATIVE EMISSION SYSTEM
EC-1041
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
3. Turn ignition switch ON.
4. Select the “EVAP SYSTEM CLOSE” of “WORK SUPPORT” mode wit

Page 2398 of 4331

NISSAN LATIO 2009 Service Repair Manual EC-1042< SERVICE INFOMATION >
[MR TYPE 2]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
System Description INFOID:0000000004499918
From the beginning of refueli

EC-1042< SERVICE INFOMATION >
[MR TYPE 2]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
System Description INFOID:0000000004499918
From the beginning of refueling, the air and vapor insi de the fuel tank go through refueling EVAP vapor cut
valve and EVAP/ORVR line to the EVAP canister. The vapor is absorbed by the EVAP canister and the air is
released to the atmosphere.
When the refueling has reached the full level of the fuel tank, the refueling EVAP vapor cut valve is closed and
refueling is stopped because of auto shut-off. The vapor which was absorbed by the EVAP canister is purged
during driving.
WARNING:
When conducting inspections below, be sure to observe the following:
• Put a “CAUTION: FLAMMABLE” sign in workshop.
• Do not smoke while servicing fuel system. Keep open flames and sparks away from work area.
• Be sure to furnish the workshop with a CO 2
fire extinguisher.
CAUTION:
• Before removing fuel line parts, carry out the following procedures:
- Put drained fuel in an explosion-pr oof container and put lid on securely.
- Release fuel pressure from fuel line. Refer to EC-1086, " Fuel Pressure Check " .
- Disconnect negative battery cable.
• Always replace O-ring when the fu el gauge retainer is removed.
• Do not kink or twist hose and tube when they are installed.
• Do not tighten hose and clamps excessively to avoid damaging hoses.
• After installation, run engine an d check for fuel leaks at connection.
• Do not attempt to top off the fuel tank afte r the fuel pump nozzle shuts off automatically.
Continued refueling may cause fuel overflow, r esulting in fuel spray and possibly a fire.
Diagnosis Procedure INFOID:0000000004499919
SYMPTOM: FUEL ODOR FROM EVAP CANISTER IS STRONG. 1.
CHECK EVAP CANISTER
1. Remove EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
2. Weigh the EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
The weight should be l ess than 1.9 kg (4.2 lb).
OK or NG OK >> GO TO 2.
NG >> GO TO 3. 2.
CHECK IF EVAP CANISTER SATURATED WITH WATER PBIB1387E

Page 2399 of 4331

NISSAN LATIO 2009 Service Repair Manual ON BOARD REFUELING VAPOR RECOVERY (ORVR)
EC-1043
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
Does water drain from
the EVAP canister?
Yes or No Yes >> GO TO 3.
No >> GO TO 6.

Page 2400 of 4331

NISSAN LATIO 2009 Service Repair Manual EC-1044< SERVICE INFOMATION >
[MR TYPE 2]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
Does water drain from the EVAP canister?
Yes or No Yes >> GO TO 3.
No >> GO TO 5. 3.
REPLACE EVAP CANISTER
Replac
