Page 25 of 4331

NISSAN LATIO 2009 Service Repair Manual Component " . A/T FLUID COOLER FINAL INSPECTION After performing all procedures, ensure that all remaining oil is cleaned from all components. SCIA5659E

Page 26 of 4331

NISSAN LATIO 2009 Service Repair Manual AT N O P A/T CONTROL SYSTEM Cross-Sectional View INFOID:0000000004305298 HR16DE engine models

Page 27 of 4331

NISSAN LATIO 2009 Service Repair Manual

Page 28 of 4331

NISSAN LATIO 2009 Service Repair Manual AT N O P FUNCTION OF CLUTCH AND BRAKE CLUTCH AND BAND CHART 1. Torque converter 2. Oil pump 3. Input shaft 4. Brake band 5. Reverse clutch 6. High clutch 7. Front sun gear 8. Front pinion gear 9. Fron

Page 29 of 4331

NISSAN LATIO 2009 Service Repair Manual

Page 30 of 4331

NISSAN LATIO 2009 Service Repair Manual AT N O P “D 1 ” and “2 1” Positions * : Overrun clutch remains in engaged condition when throttle opening is less than 1/16.• Forward clutch • Forward one-way clutch • Overrun clutch •

Page 31 of 4331

NISSAN LATIO 2009 Service Repair Manual

Page 32 of 4331

NISSAN LATIO 2009 Service Repair Manual AT N O P “D 3 ”, “2 3” and “1 3” Positions * : Overrun clutch remains in engaged condition when throttle opening is less than 1/16.
