Page 3841 of 4331

NISSAN LATIO 2009 Service Repair Manual PREPARATION MT-47 < SERVICE INFORMATION > [RS6F94R] D E F G H I J K L M A B MT N O P Commercial Service Tool INFOID:0000000004305268 Tool name Description Socket Removing and installing drain plug a:

Page 3842 of 4331

NISSAN LATIO 2009 Service Repair Manual MT-48< SERVICE INFORMATION > [RS6F94R] PREPARATION Drift Installing differential side bearing inner race (clutch housing side) a: 45 mm (1.77 in) dia. b: 39 mm (1.54 in) dia . Drift Installing differ

Page 3843 of 4331

NISSAN LATIO 2009 Service Repair Manual MT N O P NOISE, VIBRATION AND HARSHN ESS (NVH) TROUBLESHOOTING NVH Troubleshooting Chart INFOID:0000000004305269 Use the chart below to help you find the cause of the symptom. The numbers indicate th

Page 3844 of 4331

NISSAN LATIO 2009 Service Repair Manual

Page 3845 of 4331

NISSAN LATIO 2009 Service Repair Manual MT N O P Triple-cone synchronizer is used for the 1st and the 2nd gears to reduce operating force of the shift lever. • 1st main gear (1) • 1st-2nd coupling sleeve (2) • Insert key (3

Page 3846 of 4331

NISSAN LATIO 2009 Service Repair Manual Dis- assembly and Assembly " . CAUTION: Do not reuse gasket. FILLING 1. Remove filler plug (1). Fill with new oil until oil level reaches the specified limit at filler plug hole as shown. 2. After re

Page 3847 of 4331

NISSAN LATIO 2009 Service Repair Manual MT N O P SIDE OIL SEAL Removal and Installation INFOID:0000000004305273 REMOVAL 1. Remove front drive shafts from transaxle assembly. Refer to FAX-9, " Removal and Installation (Left Sid

Page 3848 of 4331

NISSAN LATIO 2009 Service Repair Manual Disassembly and Assembly "
