Page 1641 of 4331

NISSAN LATIO 2009 Service Repair Manual EC NP O • If the fuel filler cap is not tigh tened properly, the MIL may come on. • Use only a genuine NISSAN rubber tube as a replacement. DTC CONFIRMATION PROCEDURE YES >> GO TO 2. NO >> GO TO 3

Page 1642 of 4331

NISSAN LATIO 2009 Service Repair Manual YES >> GO TO 2. NO >> Replace with genuine NISSAN fuel filler cap. YES >> GO TO 3. NO >> Open fuel filler cap, then clean cap and fuel filler neck threads using air blower. Then retigh

Page 1643 of 4331

NISSAN LATIO 2009 Service Repair Manual EC NP O 2. Does water drain from the EVAP canister? Does water drain from the EVAP canister?YES >> GO TO 9. NO-1 >> With CONSULT-III: GO TO 11. NO-2 >> Without CONSULT-III: GO TO 12. YES-1 >> With CO

Page 1644 of 4331

NISSAN LATIO 2009 Service Repair Manual Component Inspection " . Is the inspection result normal? YES >> GO TO 15. NO >> Replace EVAP canister purge volume control solenoid valve. Component Inspection " . Is the inspection result normal? YE

Page 1645 of 4331

NISSAN LATIO 2009 Service Repair Manual EC NP O NO >> Replace fuel level sensor unit. Diagnosis Procedure " . >> INSPECTION END Component Inspection (Fuel filler cap) INFOID:0000000004803116YES >> INSPECTION END NO >> GO TO 2.

Page 1646 of 4331

NISSAN LATIO 2009 Service Repair Manual EC-290< COMPONENT DIAGNOSIS > [HR16DE] P0442 EVAP CONTROL SYSTEM 4. Blow air into port A and check t hat it flows freely out of port B. 5. Block port B. 6. Blow air into port A and check that there is

Page 1647 of 4331

NISSAN LATIO 2009 Service Repair Manual EC NP O P0443 EVAP CANISTER PURGE VOLU ME CONTROL SOLENOID VALVE Description INFOID:0000000004780175 The EVAP canister purge volume control solenoid valve is used to control the flow rate of

Page 1648 of 4331

NISSAN LATIO 2009 Service Repair Manual OK >> INSPECTION END NG >> Go to EC-293, " Diagnosis Procedure " . YES >> Go to EC-293, " Diagnosis Procedure " . NO >> GO TO 5. YES >> Go to EC-293, " Diagnosis Procedure " . NO >> INSPECTION END
