Page 1121 of 4331

NISSAN LATIO 2009 Service Repair Manual KEY INTERLOCK CABLE CVT-177 < SERVICE INFORMATION > [RE0F08A] D E F G H I J K L M A B CVT N O P KEY INTERLOCK CABLE Removal and Installation INFOID:0000000004667113 COMPONENTS REMOVAL Refer to the fig

Page 1122 of 4331

NISSAN LATIO 2009 Service Repair Manual CVT-178< SERVICE INFORMATION > [RE0F08A] KEY INTERLOCK CABLE 4. Slide the slider (A) toward the casing cap (B) while pressing tabs (C) on the slider to separate the slider (A) from the adjust holder (

Page 1123 of 4331

NISSAN LATIO 2009 Service Repair Manual KEY INTERLOCK CABLE CVT-179 < SERVICE INFORMATION > [RE0F08A] D E F G H I J K L M A B CVT N O P 6. Temporarily install the adjust holder (A) to the key interlock rod (B). 7. Install the casi

Page 1124 of 4331

NISSAN LATIO 2009 Service Repair Manual . 2. Remove air breather hose. INSTALLATION Installation is in the reverse order of removal. CAUTION: Make sure air breather hose is not collapsed or bl ocked due to folding or bending when installed.

Page 1125 of 4331

NISSAN LATIO 2009 Service Repair Manual CVT N O P DIFFERENTIAL SIDE OIL SEAL Removal and Installation INFOID:0000000004667115 COMPONENTS REMOVAL 1. Remove drive shaft assembly. Refer to FAX-9 . 2. Remove differential side oil seal using a

Page 1126 of 4331

NISSAN LATIO 2009 Service Repair Manual Removal and Installation " . 2. Disconnect the secondary speed sensor connector (A) and CVT unit connector (B). Refer to CVT-13, " Removal and Installation Procedure for CVT Unit Connector "

Page 1127 of 4331

NISSAN LATIO 2009 Service Repair Manual TRANSAXLE ASSEMBLY CVT-183 < SERVICE INFORMATION > [RE0F08A] D E F G H I J K L M A B CVT N O P 4. Remove the four drive plate to torque converter nuts. NOTE: Rotate the crankshaft clockwise as vi

Page 1128 of 4331

NISSAN LATIO 2009 Service Repair Manual CVT-184< SERVICE INFORMATION > [RE0F08A] TRANSAXLE ASSEMBLY • When installing the cooler outlet tube (1) to the transaxle assembly (2), align the cooler tube bracket (A) against the transax
