NISSAN LATIO 2009 Service Repair Manual BL-68< SERVICE INFORMATION >
REMOTE KEYLESS ENTRY SYSTEM
43 5
R Back door switch Input OFF ON (open) 0V
OFF (closed) Ba ttery voltage
44 5
LG Rear wiper auto stop Input ON Rear wiper operating 0
Rear

Page 530 of 4331

NISSAN LATIO 2009 Service Repair Manual BL
N
O P
1: With Intelligent Key
2: Without Intelligent Key
3: Hatchback without Intelligent Key
4: Sedan without Intelligent Key
5: Hatchback
6: Sedan
7: With power door locks
8: With power windows
H

Page 531 of 4331

NISSAN LATIO 2009 Service Repair Manual Test Item Description
REMO CONT ID REGIST Keyfob ID code can be registered.
REMO CONT ID ERASER Keyfob ID code can be erased.
REMO CONT ID CONFIR It can be c hecked whether keyfob ID code is register

Page 532 of 4331

NISSAN LATIO 2009 Service Repair Manual BL
N
O P
Active Test
Work Flow INFOID:0000000004305015
1. Check the symptom and customers requests.
2. Understand outline of system. Refer to BL-58, " System Description " .
3. Confirm that power d

BL
N
O P
Active Test
Work Flow INFOID:0000000004305015
1. Check the symptom and customer's requests.
2. Understand outline of system. Refer to BL-58, " System Description " .
3. Confirm that power door lock system operates normally. Refer to BL-22 .
4. Repair or replace any malfunctioning parts. Refer to BL-71, " Trouble Diagnosis Symptom Chart " .
5. Does remote keyless entry system operate normally? If Yes, GO TO 6. If No, GO TO 4.
6. INSPECTION END
Trouble Diagnosis Symptom Chart INFOID:0000000004305016
NOTE:
• Always check the “Work Flow” before troubleshooting. Refer to BL-71, " Work Flow " .
• Always check keyfob battery before replacing keyfob. DOOR SW-DR Indicates [ON/OFF] condition of front door switch driver side.
DOOR SW-AS Indicates [ON/OFF] condition of front door switch passenger side.
DOOR SW-RR Indicates [ON/OFF] condition of rear door switch RH.
DOOR SW-RL Indicates [ON/OFF] condition of rear door switch LH.
BACK DOOR SW Indicates [ON/OFF] condition of back door switch (hatchback).
TRNK/HAT MNTR Indicates [ON/OFF] condition of trunk room lamp switch (sedan).
CDL LOCK SW Indicates [ON/OFF] condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW Indicates [ON/OFF] condition of unlock signal from door lock and unlock switch.
KEYLESS PANIC Indicates [ON/OFF] condition of panic alarm signal from keyfob.
Monitored Item Description Test Item Description
INT LAMP This test is able to check interior room lamp operation.
The interior room lamp turns on when “ON” on CONSULT-III screen is touched.
FLASHER This test is able to check right hazard reminder operation.
The right hazard lamp turns on when “ON” on CONSULT-III screen is touched.
DOOR LOCK This test is able to check door lock actuator operation.
• The all door lock actuator are locked when “ALL LOCK” on CONSULT-III screen is touched.
• The all door lock actuator are unlocked when “ALL UNLOCK” on CONSULT-III screen is touched. Symptom Diagnoses/service procedure
Reference
page
All function of remote keyless entry system do not
operate. 1. Check key switch.
BL-782. Check keyfob battery and function.
NOTE:
If the result of keyfob function check with CONSULT-III is OK, key-
fob is not malfunctioning. BL-723. Check remote keyless entry receiver.
BL-804. Refer to ID Code Entry Procedure.
BL-825. Replace BCM.
BCS-18

Page 533 of 4331

NISSAN LATIO 2009 Service Repair Manual 2. Check key switch.
BL-783. Check door switch (hatchback).
BL-744. Check door switch (sedan).
BL-765. Check ACC switch.
BL-746. Replace keyfob. Refer to ID Code Entry Procedure.
BL-827. Replace BCM.

2. Check key switch.
BL-783. Check door switch (hatchback).
BL-744. Check door switch (sedan).
BL-765. Check ACC switch.
BL-746. Replace keyfob. Refer to ID Code Entry Procedure.
BL-827. Replace BCM.
BCS-18Door lock does not function with keyfob.
(Power door lock system is “OK”.) 1. Check keyfob function. (Lock)
NOTE:
If the result of keyfob function check with CONSULT-III is OK, key-
fob is not malfunctioning. BL-822. Replace keyfob. Refer to ID Code Entry Procedure.
BL-823. Check door switch (hatchback).
BL-744. Check door switch (sedan).
BL-765. Replace BCM.
BCS-18Door unlock does not function with keyfob
(Power door lock system is “OK”) 1. Check keyfob function. (Unlock)
BL-822. Replace keyfob. Refer to ID Code Entry Procedure.
NOTE:
If the result of keyfob function check with CONSULT-III is OK, key-
fob is not malfunctioning. BL-823. Replace BCM.
BCS-18Hazard reminder does not activate properly when
pressing lock or unlock button of keyfob. 1. Check hazard reminder mode.*
*: Hazard reminder mode can be changed.
First check the hazard reminder setting. BL-692. Check hazard function.
BL-783. Replace BCM.
BCS-18Panic alarm does not activate when panic alarm but-
ton is continuously pressed. 1. Check panic alarm mode.*
*: Panic alarm mode can be changed.
First check the panic alarm setting. BL-692. Check keyfob battery and function.
NOTE:
If the result of keyfob function check with CONSULT-III is OK, key-
fob is not malfunctioning. BL-723. Check horn function.
BL-794. Check key switch.
BL-785. Replace keyfob. Refer to ID Code Entry Procedure.
BL-826. Replace BCM.
BCS-18Auto door lock operation does not activate properly.
(All other remote keyless entry system functions are
OK.) 1. Check auto door lock operation mode.*
*: Auto door lock operation mode can be changed.
First check the auto door lock operation setting. BL-692. Replace BCM.
BCS-18Interior lamp operation does not activate properly.
1. Check interior lamp operation.
BL-792. Replace BCM.
BCS-18Symptom Diagnoses/service procedure
Reference
page

Page 534 of 4331

NISSAN LATIO 2009 Service Repair Manual BL
N
O P
With CONSULT-III
Check keyfob function in “DATA MONITOR” mode wit h CONSULT-III. When pushing each button of keyfob,
the corresponding monitor item should be turned as follo

Page 535 of 4331

NISSAN LATIO 2009 Service Repair Manual YES >> Key fob is OK.
NO >> Check remote keyless entry receiver. Refer to BL-80," Remote Keyless Entry Receiver Check " .
ACC Switch Check INFOID:0000000004305018OK >> ACC switch is OK.
NG >>

Page 536 of 4331

NISSAN LATIO 2009 Service Repair Manual REMOTE KEYLESS ENTRY SYSTEM
BL-75
< SERVICE INFORMATION >
C
D E
F
G H
J
K L
M A
B BL
N
O P
• When doors are closed:
Without CONSULT-III
Check voltage between BCM connector M18 or M19 terminals 12,
