Page 409 of 4331

NISSAN LATIO 2009 Service Repair Manual AV N O P NG >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector. OK >> Inspection End. NG >> • Check connector housings for disconnected or loo

Page 410 of 4331

NISSAN LATIO 2009 Service Repair Manual OK >> GO TO 4. NG >> Repair harness or connector. OK >> GO TO 5. NG >> Replace audio unit. Refer to AV-37, " Removal and Installation " . OK >> GO TO 6. NG >> Replace audio unit. Refer to

Page 411 of 4331

NISSAN LATIO 2009 Service Repair Manual AV N O P Satellite Radio Tuner (Factory Installed) Left Channel Audio Signal Circuit Inspection INFOID:0000000004306971 OK >> GO TO 2. NG >> Repair harness or connector. OK >> Replace audio unit.

Page 412 of 4331

NISSAN LATIO 2009 Service Repair Manual OK >> GO TO 2. NG >> Repair harness or connector. OK >> Replace audio unit. Refer to AV-37, " Removal and Installation " . NG >> Replace satellite radio tuner. Refer to AV-37, " Remov

Page 413 of 4331

NISSAN LATIO 2009 Service Repair Manual AV N O P OK or NG OK >> GO TO 3. NG >> Repair harness. OK >> GO TO 4. NG >> Repair harness. OK >> GO TO 4. NG >> Replace spiral cable. Refer to SRS-37, " Removal and Installation " .Terminals

Page 414 of 4331

NISSAN LATIO 2009 Service Repair Manual Removal and Installation " . Sound Is Not Heard fr om Front Door Speaker (Base System) INFOID:0000000004306974OK >> GO TO 2. NG >> • Check connector housings for disconnected or loose terminals.

Page 415 of 4331

NISSAN LATIO 2009 Service Repair Manual AV N O P 4. Check the signal between audio unit harness connector termi- nals with CONSULT-III or oscilloscope. OK or NG OK >> Replace speaker. Refer to AV-37, " Removal and Instal- la

Page 416 of 4331

NISSAN LATIO 2009 Service Repair Manual OK >> Replace speaker. Refer to AV-37, " Removal and Instal- lation " . NG >> Replace audio unit. Refer to AV-37, " Removal and Installation " . Sound Is Not Heard from Front Door Sp
