NISSAN LATIO 2009 Service Repair Manual MT N O P Shift Control Component 1. Reverse output gear 2. Snap ring 3. Reverse baulk ring 4. Return spring 5. Needle bearing 6. Seal washer 7. Reverse idler shaft 8. Spacer 9. Reverse input gear 10.

Page 3858 of 4331

NISSAN LATIO 2009 Service Repair Manual

Page 3859 of 4331

NISSAN LATIO 2009 Service Repair Manual MT N O P DISASSEMBLY 1. Remove drain plug and gasket from clutch hous ing using a suitable tool and drain gear oil. 2. Remove filler plug and gasket from transaxle case. 3. Remove select lever (1)

Page 3860 of 4331

NISSAN LATIO 2009 Service Repair Manual PCIB1695E JPDIC0444ZZ PCIB1698E

Page 3861 of 4331

NISSAN LATIO 2009 Service Repair Manual MT N O P 11. Remove reverse idler shaft assembly (1) according to the follow- ing procedures. a. Pull up input shaft assembly (2), mainshaft assembly (3), fork rod (4), and 1st-2nd fork rod (

Page 3862 of 4331

NISSAN LATIO 2009 Service Repair Manual JPDIC0106ZZ PCIB1712E PCIB1710E

Page 3863 of 4331

NISSAN LATIO 2009 Service Repair Manual MT N O P 25. Remove mainshaft rear bearing outer race from transaxle case using a suitable tool. 26. Remove mainshaft rear bearing adjusting shim from transaxle case. 27. Remove snap ri

Page 3864 of 4331

NISSAN LATIO 2009 Service Repair Manual PCIB1719E PCIB1720E
