Page 593 of 4331

NISSAN LATIO 2009 Service Repair Manual BL-132< SERVICE INFORMATION > INTELLIGENT KEY SYSTEM OK or NG OK >> Door switch circuit is OK. NG >> GO TO 2 2. CHECK DOOR SWITCH CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect door switch and BCM

Page 594 of 4331

NISSAN LATIO 2009 Service Repair Manual INTELLIGENT KEY SYSTEM BL-133 < SERVICE INFORMATION > C D E F G H J K L M A B BL N O P Check continuity between front door switch terminal 2 or rear door switch terminal 1 and exposed m

Page 595 of 4331

NISSAN LATIO 2009 Service Repair Manual BL-134< SERVICE INFORMATION > INTELLIGENT KEY SYSTEM Door Switch Check (Sedan) INFOID:00000000043050511. CHECK DOOR SWITCHES INPUT SIGNAL With CONSULT-III Check door switches ("DOOR SW-DR", "DOOR SW-A

Page 596 of 4331

NISSAN LATIO 2009 Service Repair Manual INTELLIGENT KEY SYSTEM BL-135 < SERVICE INFORMATION > C D E F G H J K L M A B BL N O P OK or NG OK >> GO TO 3 NG >> Repair or replace harness. 3. CHECK DOOR SWITCHES Check continuity between door swit

Page 597 of 4331

NISSAN LATIO 2009 Service Repair Manual OK >> GO TO 3 NG >> Repair or replace harness between Intelligent Key unit and front door request switch. OK >> GO TO 4 NG >> Replace front door request switch. OK >> GO TO 5 NG >> Repair or replace

Page 598 of 4331

NISSAN LATIO 2009 Service Repair Manual BL N O P OK or NG OK >> Check the condition of harness and connector. NG >> Replace Intelligent Key unit. Refer to BL-158, " Removal and Installation of Intelligent Key Unit " . Back Door Request Swi

Page 599 of 4331

NISSAN LATIO 2009 Service Repair Manual OK >> GO TO 3 NG >> Repair or replace harness between Intelligent Key unit and back door request switch. OK >> GO TO 4 NG >> Replace back door request switch. OK >> GO TO 5 NG >> Repair or replace

Page 600 of 4331

NISSAN LATIO 2009 Service Repair Manual INTELLIGENT KEY SYSTEM BL-139 < SERVICE INFORMATION > C D E F G H J K L M A B BL N O P Without CONSULT-III 1. Turn ignition switch OFF. 2. Check voltage between Intelligent Key unit connector and grou
