Page 665 of 4331

NISSAN LATIO 2009 Service Repair Manual BL-204< SERVICE INFORMATION > TRUNK LID OPENER 13 V Instrument panel an- tenna (+) signal LOCK• Any door open → all door close • Press ignition knob switch: ON (Ignition knob switch) 14 LG Ins

Page 666 of 4331

NISSAN LATIO 2009 Service Repair Manual TRUNK LID OPENER BL-205 < SERVICE INFORMATION > C D E F G H J K L M A B BL N O P *1: With continuously variable transmission (CVT) or automatic transmission (A/T). *2: With manual transmission (M/T).

Page 667 of 4331

NISSAN LATIO 2009 Service Repair Manual System Description " . 3. Repair or replace any malfunctioning parts. Refer to BL-206, " Trouble Diagnosis Chart by Symptom " . 4. Does trunk lid opener operate normally? If Yes, GO TO 5. If No, GO T

Page 668 of 4331

NISSAN LATIO 2009 Service Repair Manual TRUNK LID OPENER BL-207 < SERVICE INFORMATION > C D E F G H J K L M A B BL N O P OK >> GO TO 2. NG >> If fuse is blown, be sure to eliminate caus e of malfunction before installing new fuse. Refer to

Page 669 of 4331

NISSAN LATIO 2009 Service Repair Manual BL-208< SERVICE INFORMATION > TRUNK LID OPENER OK or NG OK >> Trunk lid opener switch is OK. NG >> GO TO 2 2. CHECK TRUNK LID OPENER SWITCH CIRCUIT 1 1. Turn ignition switch OFF. 2. Disconnect BCM and

Page 670 of 4331

NISSAN LATIO 2009 Service Repair Manual TRUNK LID OPENER BL-209 < SERVICE INFORMATION > C D E F G H J K L M A B BL N O P 3. Check continuity between trunk lid opener switch connector (A) B128 terminal 2 and ground. OK or NG OK >> GO TO 5 NG

Page 671 of 4331

NISSAN LATIO 2009 Service Repair Manual BL-210< SERVICE INFORMATION > TRUNK LID OPENER OK or NG OK >> Check the condition of harness and connector. NG >> Replace BCM. Refer to BCS-18, " Removal and Installa- tion of BCM " . Check Trunk Lid

Page 672 of 4331

NISSAN LATIO 2009 Service Repair Manual TRUNK LID OPENER BL-211 < SERVICE INFORMATION > C D E F G H J K L M A B BL N O P OK or NG OK >> GO TO 3 NG >> Repair or replace harness. 3. CHECK TRUNK LID OPENER SWITCH Check continuity between trun
