Page 4097 of 4331

NISSAN LATIO 2009 Service Repair Manual System Description " . 3. According to the trouble diagnosis chart, repa ir or replace the cause of the malfunction. Refer to RF-17, " Trouble Diagnosis Chart by Symptom " . 4. Does sunroof system

Page 4098 of 4331

NISSAN LATIO 2009 Service Repair Manual RF N O P Work Support INFOID:0000000004307401 Active Test INFOID:0000000004307402 Data Monitor INFOID:0000000004307403 Trouble Diagnosis Chart by Symptom INFOID:0000000004307404 BCM Power Supply and G

Page 4099 of 4331

NISSAN LATIO 2009 Service Repair Manual OK >> Sunroof switch input signal circuits are OK. NG >> GO TO 2. OK >> GO TO 3. NG >> Repair or replace harness. OK >> GO TO 4. NG >> Repair or replace harness.

Page 4100 of 4331

NISSAN LATIO 2009 Service Repair Manual RF N O P Check continuity between sunroof switch terminals 1, 3 and 2. OK or NG OK >> Replace sunroof motor assembly. Refer to RF-22, " Removal and Installation " . NG >> Replace sunroof switch. Su

Page 4101 of 4331

NISSAN LATIO 2009 Service Repair Manual OK >> Sunroof motor assembly power supply circuits are OK. Further inspection is necessary. Refer to RF-17, " Trouble Diagnosis Chart by Symptom " . NG >> Repair or replace harness. Doo

Page 4102 of 4331

NISSAN LATIO 2009 Service Repair Manual RF N O P 1. Turn ignition switch OFF. 2. Disconnect door switch and BCM. 3. Check continuity between BCM connector M18, M19 terminals 12, 47 and door switch connectors B8, B108 terminal 2. 4. C

Page 4103 of 4331

NISSAN LATIO 2009 Service Repair Manual

Page 4104 of 4331

NISSAN LATIO 2009 Service Repair Manual RF N O P SUNROOF UNIT ASSEMBLY 1. Glass lid 2. Rear drain assembly 3. Link assembly (RH) 4. Sunroof bracket 5. Wind deflector 6. Drain hose 7. Sunroof unit assembly 8. Sunroof motor assembly 9. Sunsha
