Page 641 of 4331

NISSAN LATIO 2009 Service Repair Manual BL-180< SERVICE INFORMATION > BACK DOOR LOCK 13 V Instrument panel an- tenna (+) signal LOCK• Any door open → all door close • Press ignition knob switch: ON (Ignition knob switch) 14 LG Instr

Page 642 of 4331

NISSAN LATIO 2009 Service Repair Manual BACK DOOR LOCK BL-181 < SERVICE INFORMATION > C D E F G H J K L M A B BL N O P *1: With continuously variable transmission (CVT) or automatic transmission (A/T). *2: With manual transmission (M/T). CO

Page 643 of 4331

NISSAN LATIO 2009 Service Repair Manual System Description " . 3. Repair or replace any malfunctioning parts. Refer to BL-182, " Trouble Diagnosis Chart by Symptom " . 4. Does back door opener operate normally? If Yes, GO TO 5. If No, GO T

Page 644 of 4331

NISSAN LATIO 2009 Service Repair Manual BACK DOOR LOCK BL-183 < SERVICE INFORMATION > C D E F G H J K L M A B BL N O P OK >> GO TO 2. NG >> If fuse is blown, be sure to eliminate caus e of malfunction before installing new fuse. Refer to PG

Page 645 of 4331

NISSAN LATIO 2009 Service Repair Manual OK >> Back door opener switch is OK. NG >> GO TO 2 OK >> GO TO 3 NG >> Repair or replace harness. OK >> GO TO 4 NG >> Replace back door opener switch.

Page 646 of 4331

NISSAN LATIO 2009 Service Repair Manual BL N O P 3. Check continuity between back door opener switch connector (A) D408 terminal 2 and ground. OK or NG OK >> GO TO 5 NG >> Repair or replace harness between back door opener switch an

Page 647 of 4331

NISSAN LATIO 2009 Service Repair Manual BL-186< SERVICE INFORMATION > BACK DOOR LOCK OK or NG OK >> Check the condition of harness and connector. NG >> Replace BCM. Refer to BCS-18, " Removal and Installa- tion of BCM " . Check Back Door O

Page 648 of 4331

NISSAN LATIO 2009 Service Repair Manual BL N O P OK or NG OK >> GO TO 3 NG >> Repair or replace harness. OK >> GO TO 4 NG >> Replace back door opener switch. OK >> GO TO 5 NG >> Repair or replace harness between back door opener swi
