Page 3689 of 4331

NISSAN LATIO 2009 Service Repair Manual LT N O P 1. Check continuity between front combination lamp harness con- nector and ground. 2. Check continuity between license plate lamp harness connector and ground. 3. Check continuity be

Page 3690 of 4331

NISSAN LATIO 2009 Service Repair Manual Bulb Replacement " . Removal and Installation INFOID:0000000004306621 PARKING LAMP Refer to LT-87, " Removal and Installation " . LICENSE PLATE LAMP-HATCHBACK Removal 1. Press the license plate lamp

Page 3691 of 4331

NISSAN LATIO 2009 Service Repair Manual LT N O P 2. Remove the license plate lamp assembly (1). Installation Installation is in the reverse order of removal. TAIL LAMP Refer to LT-87, " Removal and Installation " .

Page 3692 of 4331

NISSAN LATIO 2009 Service Repair Manual Removal and Installation " . 2. Turn bulb socket counterclockwise and unlock it. 3. Remove bulb. 4. Installation is in the reverse order of removal. SEDAN 1. Remove trunk side finisher. Refer to EI-5

Page 3693 of 4331

NISSAN LATIO 2009 Service Repair Manual LT N O P Removal and Installation INFOID:0000000004306624 HATCHBACK Removal 1. Remove rear combination lamp nuts. 2. Pull the rear combination lamp toward rear of the vehicle and remove from the vehic

Page 3694 of 4331

NISSAN LATIO 2009 Service Repair Manual PKIC1038E PKIC1039E

Page 3695 of 4331

NISSAN LATIO 2009 Service Repair Manual LT N O P 1. Remove luggage compartment lamp from the luggage side finisher LH. 2. Remove luggage compartment lamp cover. 3. Press tab A and remove the bulb. 4. Installation is in the reverse order of

Page 3696 of 4331

NISSAN LATIO 2009 Service Repair Manual
