DTC P0460 FUEL LEVEL SENSOR
EC-1381
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
DTC P0460 FUEL LEVEL SENSOR
Component Description INFOID:0000000004500235
The fuel level sensor (3) is mounted in the fuel level sensor unit. The
sensor detects a fuel level in the fuel tank and transmits a signal to
the combination meter. The combination meter sends the fuel level
sensor signal to the ECM through CAN communication line.
It consists of two parts, one is mechanical float and the other is vari-
able resistor. Fuel level sensor output voltage changes depending on
the movement of the fuel mechanical float.
• Fuel level sensor unit and fuel pump (1)
• Fuel pressure regulator (2)
• Fuel tank temperature sensor (4)
On Board Diagnosis Logic INFOID:0000000004500236
NOTE:
• If DTC P0460 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
• If DTC P0460 is displayed with DT C P0607, first perform the trouble diagnosis for DTC P0607. Refer
to EC-1395 .
When the vehicle is parked, naturally the fuel level in the fuel tank is stable. It means that output signal of the
fuel level sensor does not change. If ECM senses sloshi ng signal from the sensor, fuel level sensor malfunc-
tion is detected.
DTC Confirmation Procedure INFOID:0000000004500237
NOTE:
If DTC Confirmation Procedure has been previously conduc ted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
1. Start engine and wait maximum of 2 consecutive minutes.
2. Check 1st trip DTC.
3. If 1st trip DTC is detected, go to EC-1381, " Diagnosis Procedure " .
Diagnosis Procedure INFOID:00000000045002381.
CHECK FUEL GAUGE OPERATION
Refer to DI-10, " Self-Diagnosis Mode of Combination Meter " .
OK or NG OK >> GO TO 2.
NG >> Follow the instruction of DI-10, " Self-Diagnosis Mode of Combination Meter " .
2.
CHECK FUEL LEVEL SENSOR AND CIRCUIT
Refer to DI-16, " Fuel Level Sensor Signal Inspection " .
OK or NG OK >> GO TO 3.
NG >> Repair or replace malfunctioning parts. BBIA0704E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0460
0460 Fuel level sensor circuit
noise Even though the vehicle is parked, a signal be-
ing varied is sent from the fuel level sensor to
ECM. • Harness or connectors
(CAN communication line is open or
shorted)
• Harness or connectors (Fuel level sensor circuit is open or short-
ed)
• Combination meter
• Fuel level sensor
Page 2738 of 4331
.
>> INSPECTION END
Removal and Installation INFOID:0000000004500239
FUEL LEVEL SENSOR
Refer to FL-5 .
Page 2739 of 4331
![NISSAN LATIO 2009 Service Repair Manual DTC P0461 FUEL LEVEL SENSOR
EC-1383
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
DTC P0461 FUEL LEVEL SENSOR
Component Description INFOID:0000000004501200
The fuel level sensor ( NISSAN LATIO 2009 Service Repair Manual DTC P0461 FUEL LEVEL SENSOR
EC-1383
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
DTC P0461 FUEL LEVEL SENSOR
Component Description INFOID:0000000004501200
The fuel level sensor (](/manual-img/5/57359/w960_57359-2738.png)
DTC P0461 FUEL LEVEL SENSOR
EC-1383
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
DTC P0461 FUEL LEVEL SENSOR
Component Description INFOID:0000000004501200
The fuel level sensor (3) is mounted in the fuel level sensor unit. The
sensor detects a fuel level in the fuel tank and transmits a signal to
the combination meter. The combination meter sends the fuel level
sensor signal to the ECM through CAN communication line.
It consists of two parts, one is mechanical float and the other is vari-
able resistor. Fuel level sensor output voltage changes depending on
the movement of the fuel mechanical float.
• Fuel level sensor unit and fuel pump (1)
• Fuel pressure regulator (2)
• Fuel tank temperature sensor (4)
On Board Diagnosis Logic INFOID:0000000004500241
NOTE:
• If DTC P0461 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
• If DTC P0461 is displayed with DT C P0607, first perform the trouble diagnosis for DTC P0607. Refer
to EC-1395 .
This diagnosis detects the fuel gauge malfunction of the gauge not moving even after a long distance has
been driven.Driving long distances naturally affect fuel gauge level.
Overall Function Check INFOID:0000000004500242
Use this procedure to check the overall function of the f uel level sensor function. During this check, a 1st trip
DTC might not be confirmed.
WARNING:
When performing following procedure, be sure to observe the handling of the fuel.
Refer to FL-4 .
TESTING CONDITION:
Before starting overall function check, preparation of draining fuel and refilling fuel is required.
WITH CONSULT-III
NOTE:
Start from step 10, if it is possible to confirm that the fuel cannot be drained by 30 (7-7/8 US gal, 6-5/
8 Imp gal) in advance.
1. Prepare a fuel container and a spare hose.
2. Release fuel pressure from fuel line, refer to EC-1086, " Fuel Pressure Check " .
3. Remove the fuel feed hose on the fuel level sensor unit.
4. Connect a spare fuel hose where the fuel feed hose was removed.
5. Turn ignition switch OFF and wait at least 10 seconds then turn ON.
6. Select “FUEL LEVEL SE” in “DAT A MONITOR” mode with CONSULT-III.
7. Check “FUEL LEVEL SE” output voltage and note it.
8. Select “FUEL PUMP RELAY” in “A CTIVE TEST” mode with CONSULT-III.
9. Touch “ON” and drain fuel approximately 30 (7-7/8 US gal, 6-5/8 Imp gal) and stop it.
10. Check “FUEL LEVEL SE” output voltage and note it.
11. Fill fuel into the fuel tank for 30 (7-7/8 US gal, 6-5/8 Imp gal). BBIA0704E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0461
0461 Fuel level sensor circuit
range/performance The output signal of the fuel level sensor does
not change within the specified range even
though the vehicle has been driven a long dis-
tance. • Harness or connectors
(CAN communication line is open or
shorted)
• Harness or connectors (Fuel level sensor circuit is open or short-
ed)
• Combination meter
• Fuel level sensor
Page 2740 of 4331

Diagnosis Procedure " .
WITH GST
NOTE:
Start from step 8, if it is possible to confirm that the fuel cannot be drained by 30 (7-7/8 US gal, 6-5/8
Imp gal) in advance.
1. Prepare a fuel container and a spare hose.
2. Release fuel pressure from fuel line, refer to EC-1086, " Fuel Pressure Check " .
3. Remove the fuel feed hose on the fuel level sensor unit.
4. Connect a spare fuel hose where the fuel feed hose was removed.
5. Turn ignition switch ON.
6. Drain fuel by 30 (7-7/8 US gal, 6-5/8 Imp gal) from the fuel tank using proper equipment.
7. Confirm that the fuel gauge indication varies.
8. Fill fuel into the fuel tank for 30 (7-7/8 US gal, 6-5/8 Imp gal).
9. Confirm that the fuel gauge indication varies.
10. If NG, go to EC-1384, " Diagnosis Procedure " .
Diagnosis Procedure INFOID:0000000004501202Self-Diagnosis Mode of Combination Meter " .
OK or NG OK >> GO TO 2.
NG >> Follow the instruction of DI-10, " Self-Diagnosis Mode of Combination Meter " .
Fuel Level Sensor Signal Inspection " .
OK or NG OK >> GO TO 3.
NG >> Repair or replace malfunctioning parts. .
>> INSPECTION END
Removal and Installation INFOID:0000000004501203
FUEL LEVEL SENSOR
Refer to FL-5 .
Page 2741 of 4331
![NISSAN LATIO 2009 Service Repair Manual DTC P0462, P0463 FUEL LEVEL SENSOR
EC-1385
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
DTC P0462, P0463 FUEL LEVEL SENSOR
Component Description INFOID:0000000004501201
The fuel NISSAN LATIO 2009 Service Repair Manual DTC P0462, P0463 FUEL LEVEL SENSOR
EC-1385
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
DTC P0462, P0463 FUEL LEVEL SENSOR
Component Description INFOID:0000000004501201
The fuel](/manual-img/5/57359/w960_57359-2740.png)
DTC P0462, P0463 FUEL LEVEL SENSOR
EC-1385
< SERVICE INFOMATION >
[MR TYPE 2] C
D E
F
G H
I
J
K L
M A EC
NP
O
DTC P0462, P0463 FUEL LEVEL SENSOR
Component Description INFOID:0000000004501201
The fuel level sensor (3) is mounted in the fuel level sensor unit. The
sensor detects a fuel level in the fuel tank and transmits a signal to
the combination meter. The combination meter sends the fuel level
sensor signal to the ECM through CAN communication line.
It consists of two parts, one is mechanical float and the other is vari-
able resistor. Fuel level sensor output voltage changes depending on
the movement of the fuel mechanical float.
• Fuel level sensor unit and fuel pump (1)
• Fuel pressure regulator (2)
• Fuel tank temperature sensor (4)
On Board Diagnosis Logic INFOID:0000000004500246
NOTE:
• If DTC P0462 or P0463 is displayed with DTC UXXXX, first perform the trouble diagnosis for DTC
UXXXX.
• If DTC P0462 or P0463 is displayed with DTC P0607, first perform the trouble diagnosis for DTC
P0607. Refer to EC-1395 .
DTC Confirmation Procedure INFOID:0000000004500247
NOTE:
If DTC Confirmation Procedure has been previously conduc ted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm th at battery voltage is more than 11V at ignition
switch ON.
1. Turn ignition switch ON and wait at least 5 seconds.
2. Check 1st trip DTC.
3. If 1st trip DTC is detected, go to EC-1385, " Diagnosis Procedure " .
Diagnosis Procedure INFOID:00000000045012041.
CHECK FUEL GAUGE OPERATION
Refer to DI-10, " Self-Diagnosis Mode of Combination Meter " .
OK or NG OK >> GO TO 2.
NG >> Follow the instruction of DI-10, " Self-Diagnosis Mode of Combination Meter " .
2.
CHECK FUEL LEVEL SENSOR AND CIRCUIT
Refer to DI-16, " Fuel Level Sensor Signal Inspection " .
OK or NG OK >> GO TO 3.
NG >> Repair or replace malfunctioning parts. BBIA0704E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0462
0462 Fuel level sensor circuit
low input An excessively low voltage from the sensor is
sent to ECM. • Harness or connectors
(CAN communication line is open or
shorted)
• Harness or connectors
(Fuel level sensor circuit is open or short-
ed)
• Combination meter
• Fuel level sensor
P0463
0463 Fuel level sensor circuit
high input An excessively high voltage from the sensor is
sent to ECM.
Page 2742 of 4331
.
>> INSPECTION END
Removal and Installation INFOID:0000000004501205
FUEL LEVEL SENSOR
Refer to FL-5 .
Page 2743 of 4331

EC
NP
O
DTC P0500 VSS
Description INFOID:0000000004500250
NOTE:
• If DTC P0500 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
• If DTC P0500 is displayed with DT C P0607, first perform the trouble diagnosis for DTC P0607. Refer
to EC-1395 .
The vehicle speed signal is sent from “ABS actuator and electric unit (control unit)” or combination meter
through CAN communication line
On Board Diagnosis Logic INFOID:0000000004500251
FAIL-SAFE MODE When the malfunction is detect ed, ECM enters fail-safe mode.
DTC Confirmation Procedure INFOID:0000000004500252
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If DTC Confirmation Procedure has been previously conduc ted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Steps 1 and 2 may be conducted with the drive wheels li fted in the shop or by driving the vehicle. If a
road test is expected to be easier, it is unnecessary to lift the vehicle.
WITH CONSULT-III
1. Start engine.
2. Read “VHCL SPEED SE” in “DATA MONITOR” m ode with CONSULT-III. The vehicle speed on CON-
SULT-III should exceed 10 km/h (6 MPH) when rotating wheels with suitable gear position.
If NG, go to EC-1388, " Diagnosis Procedure " .
If OK, go to following step.
3. Select “DATA MONITOR” mode with CONSULT-III.
4. Warm engine up to normal operating temperature.
5. Maintain the following conditions for at least 60 consecutive seconds.
6. Check 1st trip DTC.
7. If 1st trip DTC is detected, go to EC-1388, " Diagnosis Procedure " .
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0500
0500 Vehicle speed sensor The vehicle speed signal sent to ECM is
almost km/h (0 MPH) even when vehicle
is being driven. • Harness or connectors
(CAN communication line is open or shorted.)
• Harness or connectors (Vehicle speed signal circuit is open or shorted)
• ABS actuator and electric unit (control unit)
• Combination meter Detected item Engine operating condition in fail-safe mode
Vehicle speed sensor The cooling fan operates (High) while engine is running. ENG SPEED More than 1,600 rpm
COOLAN TEMP/S More than 70 °C (158 °F)
B/FUEL SCHDL 5.5 - 31.8 msec
Shift lever Suitable position
PW/ST SIGNAL OFF
Page 2744 of 4331
Diagnosis Procedure " .
Diagnosis Procedure INFOID:0000000004500254.
OK or NG OK >> GO TO 2.
NG >> Repair or replace. .
>> INSPECTION END
