TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–189 AX 48. REMOVE GOVERNOR APPLY GASKET NO.1 (a) Using a screwdriver, remove the 3 apply gaskets. 49. REMOVE BRAKE APPLY TUBE (a) Remove th

Page 1634 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–190U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Remove the thrust needle roller bearing and thrust bearing race from the rear planetary sun gear assembly. (c) Remove the plan

Page 1635 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–191 AX 56. REMOVE PLANETARY CARRIER THRUST WASHER NO.1 (a) Remove the planetary carrier thrust washer No.1 from the planetary gear assemb

Page 1636 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–192U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Remove the rear planetary gear assembly from the transaxle case. 61. REMOVE INPUT SUN GEAR (a) Remove the 2 thrust needle rolle

Page 1637 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–193 AX (c) Using SST and a press, remove the front planetary gear assembly from the counter drive gear. SST 09950-60010 (09951-00450), 099

Page 1638 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–194U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 68. REMOVE 1ST AND REVERSE BRAKE PISTON (a) Apply compressed air (392 kPa, 4.0 kgf/cm 2, 57 psi) to the transaxle case to remove th

Page 1639 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–195 AX 70. REMOVE TRANSFER DRIVEN PINION FRONT BEARING (a) Using a snap ring expander, remove the snap ring. (b) Using SST and a press, re

Page 1640 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–196U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Remove the 2 O-rings from the underdrive brake piston. 75. REMOVE NEEDLE ROLLER BEARING (a) Using SST, remove the needleroller
