Page 177 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TIRE AND WHEEL – TIRE AND WHEEL SYSTEMTW–7
TW
5. EXTERNAL TIRE INSPECTION
(a) Inspection procedure
C113006E01

Page 178 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TW–8TIRE AND WHEEL – TIRE AND WHEEL SYSTEM
TW
6. INTERNAL TIRE INSPECTION
(a) Inspection procedure
C113007E01

Page 179 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TIRE AND WHEEL – TIRE AND WHEEL SYSTEMTW–9
TW
7. RUN-FLAT TIRE REPAIR LIMIT CHART
(a) Tires that have a penetration in the tread area but
meet the above inspection criteria may be repaired
if

Page 180 of 3000

TOYOTA SIENNA 2007 Service Repair Manual BC–4BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEM
BC
TEST MODE PROCEDURE
1. SPEED SENSOR SIGNAL CHECK (WHEN USING SST
CHECK WIRE):
HINT:
• If the ignition switch is turned from the ON to the ACC
or

Page 181 of 3000

TOYOTA SIENNA 2007 Service Repair Manual BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEMBC–5
BC
• After the ABS warning light goes off and if
vehicle speed exceeds 50 mph (80 km/h), the
signal check code will be stored again.
Decelerate or

Page 182 of 3000

TOYOTA SIENNA 2007 Service Repair Manual BC–6BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEM
BC
HINT:
The codes in this table are output only in Test Mode
(signal check).
4. SPEED SENSOR SIGNAL CHECK (WHEN USING
INTELLIGENT TESTER):
HINT:
•

Page 183 of 3000

TOYOTA SIENNA 2007 Service Repair Manual BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEMBC–7
BC
(f) Check that the ABS warning light is blinking in the
Test Mode.
HINT:
If the ABS warning light does not blink, inspect the
TS and CG terminal c

Page 184 of 3000

TOYOTA SIENNA 2007 Service Repair Manual BC–8BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEM
BC
HINT:
The codes in this table are output only in Test Mode
(signal check).
C1274/74 Low output signal of rear speed sensor LH• Rear speed sensor
