2GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEMES–487
ES
B
C
A
(a) Connect the intelligent tester to the DLC3.
(b) Turn the ignition switch to the ON position and turn the
tester on.
(c) Select the following menu items: DIAGNOSIS /
ENHANCED OBD II / DTC INFO / CURRENT CODES.
(d) Check if any DTCs have been stored. Note down any
DTCs.
(e) Clear the DTCs (See page ES-39).
(f) Check if the MIL goes off.
Standard:
MIL goes off.
OK
NG
(a) Disconnect the E5 ECM connector.
(b) Turn the ignition switch to the ON position.
(c) Check that the MIL is not illuminated.
OK:
MIL is not illuminated.
(d) Reconnect the ECM connector.
OK
NG Go to step 5
SYSTEM OK
2CHECK WHETHER MIL TURNS OFF
REPAIR CIRCUITS INDICATED BY OUTPUT
DTCS
3CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT IN WIRE HARNESS)
A163321E03
REPLACE ECM (See page ES-498)
Page 770 of 3000
ES–4882GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
(a) Disconnect the E5 ECM connector.
(b) Disconnect the C10 combination meter connector.
(c) Measure the resistance according to the value(s) in the
table below.
Standard resistance (Check for Open)
Standard resistance (Check for Short)
(d) Reconnect the ECM connector.
(e) Reconnect the combination meter connector.
OK
NG
(a) Turn the ignition switch to the ON position.
(b) Start the engine.
Result
HINT:
*: The intelligent tester cannot communicate with the
ECM.
B
4CHECK HARNESS AND CONNECTOR (COMBINATION METER - ECM)
A163122E02
Tester Connection Specified Condition
W (E5-30) - C10-8 Bellow 1
Tester Connection Specified Condition
W (E5-30) or C10-8 - Body ground 10 k
or higher
REPLACE COMBINATION METER
ASSEMBLY
REPAIR OR REPLACE HARNESS OR CONNECTOR (COMBINATION METER - ECM)
5CHECK THAT ENGINE STARTS
Result Proceed to
Engine starts A
Engine does not start* B
GO TO VC OUTPUT CIRCUIT (See page ES-
444)
Page 771 of 3000

2GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEMES–489
ES
A
(a) Disconnect the E5 ECM connector.
(b) Turn the ignition switch to the ON position.
(c) Measure the voltage according to the value(s) in the
table below.
Standard voltage
(d) Reconnect the ECM connector.
OK
NG
(a) Disconnect the E5 ECM connector.
(b) Disconnect the C10 combination meter connector.
(c) Measure the resistance according to the value(s) in the
table below.
Standard resistance (Check for short)
Standard resistance (Check for Short)
(d) Reconnect the ECM connector.
(e) Reconnect the combination meter connector.
NG
6CHECK HARNESS AND CONNECTOR (COMBINATION METER - BODY GROUND)
A163321E04
Tester Connection Condition Specified Condition
W (E5-30) - Body
groundIgnition switch ON 11 to 14 V
REPLACE ECM (See page ES-498)
7CHECK HARNESS AND CONNECTOR (COMBINATION METER - ECM)
A163122E02
Tester Connection Specified Condition
W (E5-30) - C10-8 Bellow 1
Tester Connection Specified Condition
W (E5-30) or C10-8 - Body ground 10 k
or higher
REPAIR OR REPLACE HARNESS OR
CONNECTOR (COMBINATION METER -
ECM)
Page 772 of 3000
ES–4902GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
OK
REPLACE COMBINATION METER ASSEMBLY
Page 773 of 3000

ED–214ENGINE HOOD / DOOR – BACK DOOR
ED
DISASSEMBLY
1. REMOVE BACK DOOR GARNISH CENTER
(a) Using a clip remover, disengage the 5 clips and
remove the garnish center.
2. REMOVE BACK DOOR SIDE GARNISH LH
(a) Using a clip remover, disengage the 3 clips and
remove the side garnish.
3. REMOVE BACK DOOR SIDE GARNISH RH
(a) Using a clip remover, disengage the 3 clips and
remove the side garnish.
4. REMOVE BACK DOOR PULL STRAP
(a) Using a screwdriver, disengage the claws and
remove the strap cover.
HINT:
Tape the screwdriver tip before use.
(b) Remove the bolt and strap.
5. REMOVE BACK DOOR TRIM BOARD ASSEMBLY
(a) Using the screwdriver, disengage the 14 clips and
remove the trim board.
HINT:
Tape the screwdriver tip before use.
(b) Remove the service hole cover from the trim board.
6. REMOVE BACK-UP LIGHT ASSEMBLY LH (See page
LI-90)
7. REMOVE BACK-UP LIGHT ASSEMBLY RH (See page
LI-90)
8. REMOVE BACK DOOR GARNISH SUB-ASSEMBLY
OUTSIDE (See page ET-39)
9. REMOVE BACK DOOR LOCK ASSEMBLY
(a) Disconnect the connector.
(b) Remove the 3 bolts and lock.
10. REMOVE BACK DOOR BASE STOPPER BRACKET
(a) Remove the 4 bolts and 2 stopper brackets.
11. REMOVE BACK DOOR STOPPER LOWER
(a) Remove the 4 bolts and 2 stoppers.
12. REMOVE REAR SPOILER COVER (See page ET-18)
13. REMOVE BACK DOOR STAY SUB-ASSEMBLY LH
(See page ED-231)
14. REMOVE BACK DOOR STAY SUB-ASSEMBLY RH
(See page ED-231)
B069688E01
B067784E01
B067783E01
B067787
Page 774 of 3000

ENGINE HOOD / DOOR – BACK DOORED–215
ED
ADJUSTMENT
HINT:
• On the RH side, use the same procedures as on the LH
side.
• Since a centering bolt is used as door hinge mounting
bolts on the body side and the door side, the door cannot
be adjusted with them on. Substitute a bolt with a washer
for the centering bolt.
1. INSPECT BACK DOOR PANEL SUB-ASSEMBLY
(a) Check that the clearance is within the standard
range.
Standard
2. ADJUST BACK DOOR PANEL SUB-ASSEMBLY
(a) Adjust the door forward / rearward and vertically by
loosening the body side hinge nuts and bolt.
(b) Tighten the body side hinge nuts and bolt after the
adjustment.
Torque: 19.5 N*m (200 kgf*cm, 14 ft.*lbf)
(c) Horizontally and vertically adjust the door by
loosening the door side hinge bolts.
(d) Tighten the body side hinge bolts after the
adjustment.
Torque: 19.5 N*m (200 kgf*cm, 14 ft.*lbf)
(e) Using a screwdriver, remove the back door scuff
plate.
HINT:
Tape the screwdriver tip before use.
ABCD
106. +- 1.5 mm (0.417 +- 0.059
in.)7.0 +- 1.5 mm (0.276 +- 0.059
in.)6.0 +- 1.5 mm (0.236 +- 0.059
in.)5.7 +- 1.5 mm (0.224 +- 0.059
in.)
B067794E01
B067789E01
B067788E01
Page 775 of 3000
ED–216ENGINE HOOD / DOOR – BACK DOOR
ED
(f) Adjust the striker position by slightly loosening the
striker mounting screws and hitting the striker with a
plastic-faced hammer.
(g) Tighten the striker mounting screws after the
adjustment.
Torque: 27 N*m (275 kgf*cm, 20 ft.*lbf)
B067790
Page 776 of 3000
ES–142GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
CHECK FOR INTERMITTENT
PROBLEMS
1. CHECK FOR INTERMITTENT PROBLEMS
HINT:
For use of the intelligent tester only:
Inspect the vehicle's ECM using check mode.
Intermittent problems are easier to detect with an
intelligent tester when the ECM is in check mode. In
check mode, the ECM uses 1 trip detection logic, which
is more sensitive to malfunctions than normal mode
(default), which uses 2 trip detection logic.
(a) Clear the DTCs (See page ES-39).
(b) Switch the ECM from normal mode to check mode
using an intelligent tester (See page ES-43).
(c) Perform a simulation test (See page IN-35).
(d) Check and wiggle the harness(es), connector(s)
and terminal(s) (See page IN-30).
