Page 1161 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE FUEL – FUEL TANKFU–41
FU
REMOVAL
1. DISCHARGE FUEL SYSTEM PRESSURE
(See page FU-1)
2. REMOVE CHARCOAL CANISTER PROTECTOR (See
page FU-30)
3. REMOVE REAR FLOOR NO. 2 CROSSMEMBER
BRACE LH

Page 1162 of 3000

TOYOTA SIENNA 2007 Service Repair Manual FU–422GR-FE FUEL – FUEL TANK
FU
• Do not use any tool in this operation.
• Do not bend or twist the nylon tube.
Protect the connector by covering it with
a vinyl or plastic bag.
• When t

Page 1163 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE FUEL – FUEL TANKFU–43
FU
(f) Set up a transmission jack under the fuel tank
assembly.
(g) Remove the 6 set bolts of the 3 fuel tank bands.
(h) While operating the transmission jack, unfa

Page 1164 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE FUEL – FUEL TANKFU–41
FU
REMOVAL
1. DISCHARGE FUEL SYSTEM PRESSURE
(See page FU-1)
2. REMOVE CHARCOAL CANISTER PROTECTOR (See
page FU-30)
3. REMOVE REAR FLOOR NO. 2 CROSSMEMBER
BRACE LH

Page 1165 of 3000

TOYOTA SIENNA 2007 Service Repair Manual FU–422GR-FE FUEL – FUEL TANK
FU
• Do not use any tool in this operation.
• Do not bend or twist the nylon tube.
Protect the connector by covering it with
a vinyl or plastic bag.
• When t

Page 1166 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE FUEL – FUEL TANKFU–43
FU
(f) Set up a transmission jack under the fuel tank
assembly.
(g) Remove the 6 set bolts of the 3 fuel tank bands.
(h) While operating the transmission jack, unfa

Page 1167 of 3000

TOYOTA SIENNA 2007 Service Repair Manual FU–442GR-FE FUEL – FUEL TANK
FU
INSTALLATION
1. CONNECT FUEL TANK VENT HOSE
2. INSTALL FUEL TANK TO FILLER PIPE HOSE
(a) Install a new fuel tank to filler pipe hose as shown in
the illustration

Page 1168 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE FUEL – FUEL TANKFU–45
FU
(f) Connect the fuel tank to filler pipe hose as shown in
the illustration.
(g) Connect the fuel tank main tube.
(1) Push in the fuel tube connector to the pipe

Load next 8 pages
