Page 113 of 3000

TOYOTA SIENNA 2007 Service Repair Manual DS–8DRIVE SHAFT – FRONT DRIVE SHAFT
DS
DISASSEMBLY
1. REMOVE NO. 2 FRONT AXLE INBOARD JOINT
BOOT LH CLAMP
(a) Using pliers, remove the No. 2 front axle inboard
joint boot LH clamp, as shown in

Page 114 of 3000

TOYOTA SIENNA 2007 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFTDS–9
DS
(f) Using a brass bar and hammer, remove the tripod
from the outboard joint shaft.
NOTICE:
Do not tap the roller.
5. REMOVE FR AXLE INBOARD JOINT BOOT
(a)

Page 115 of 3000

TOYOTA SIENNA 2007 Service Repair Manual DS–10DRIVE SHAFT – FRONT DRIVE SHAFT
DS
12. REMOVE FRONT DRIVE SHAFT DUST COVER LH
(a) Using SST and a press, remove the drive shaft dust
cover LH.
SST 09950-00020
NOTICE:
Be careful not to dro

Page 116 of 3000

TOYOTA SIENNA 2007 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFTDS–11
DS
17. REMOVE FRONT DRIVE SHAFT BEARING
(a) Using SST and a press, remove the front drive shaft
bearing.
SST 09527-10011
INSPECTION
1. INSPECT FRONT DRIVE S

Page 117 of 3000

TOYOTA SIENNA 2007 Service Repair Manual DS–12DRIVE SHAFT – FRONT DRIVE SHAFT
DS
3. INSTALL FRONT DRIVE SHAFT DUST COVER
(a) Using SST and a press, install a new drive shaft
dust cover until the distance from the tip of the
center dr

Page 118 of 3000

TOYOTA SIENNA 2007 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFTDS–13
DS
(a) Install new parts to the outboard joint shaft
assembly in the following order.
(1) Outboard joint boot No. 2 clamp (A)
(2) Outboard joint boot (B)
(3

Page 119 of 3000

TOYOTA SIENNA 2007 Service Repair Manual DS–14DRIVE SHAFT – FRONT DRIVE SHAFT
DS
(c) Set the distance, as specified below.
Distance:
221.0 +- 2.0 mm (8.701 +- 0.079 in.)
12. INSTALL FRONT DRIVE SHAFT DAMPER RH CLAMP
(a) Hold the outboa

Page 120 of 3000

TOYOTA SIENNA 2007 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFTDS–15
DS
(d) Align the matchmarks.
(e) Using a brass bar and hammer, tap in the tripod to
the outboard joint shaft.
NOTICE:
• Do not tap the roller.
• Be sure
