• Read freeze frame data using the intelligent tester. The ECM records vehicle and driving condition
information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame
data can be helpful in determining whether the vehicle was running or stopped, whether the engine
was warmed up or not, whether the air-fuel ratio was lean or rich, as well as other data recorded at the
time of a malfunction.
(a) Connect the intelligent tester to the DLC3.
(b) Turn the ignition switch to the ON position.
(c) Turn the tester on.
(d) Select the following menu items: DIAGNOSIS /
ENHANCED OBD II / DATA LIST / PRIMARY /
COOLANT TEMP.
(e) Read the value displayed on the tester.
Standard:
Between 80
C and 97C (176F and 207F) with
warm engine.
Result
HINT:
• If there is an open circuit, the intelligent tester
indicates -40
C (-40F).
• If there is a short circuit, the intelligent tester indicates
140
C (284F) or higher.
B
C
A
1READ VALUE OF INTELLIGENT TESTER (ENGINE COOLANT TEMPERATURE)
Temperature Displayed Proceed to
-40
C (-40F) A
140
C (284F) or higher B
Between 80
C and 97C (176F and 207F) C
Go to step 4
CHECK FOR INTERMITTENT PROBLEMS
Page 450 of 3000

ES–1442GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
(a) Disconnect the E12 Engine Coolant Temperature (ECT)
sensor connector.
(b) Connect terminals 1 and 2 of the ECT sensor connector
on the wire harness side.
(c) Connect the intelligent tester to the DLC3.
(d) Turn the ignition switch to the ON position.
(e) Turn the tester on.
(f) Select the following menu items: DIAGNOSIS /
ENHANCED OBD II / DATA LIST / PRIMARY /
COOLANT TEMP.
(g) Read the value displayed on the tester.
Standard:
140
C (284F) or higher
(h) Reconnect the ECT sensor connector.
OK
NG
(a) Disconnect the E12 ECT sensor connector.
(b) Disconnect the E9 ECM connector.
(c) Measure the resistance according to the value(s) in the
table below.
Standard resistance
(d) Reconnect the ECM connector.
(e) Reconnect the ECT connector.
OK
2READ VALUE OF INTELLIGENT TESTER (CHECK FOR OPEN IN WIRE HARNESS)
A114610E05
REPLACE ENGINE COOLANT
TEMPERATURE SENSOR (See page ES-516)
3CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR -
ECM)
A162492E01
Tester Connection Specified Condition
THW (E9-21) - E12-2 Below 1
E2 (E9-28) - E12-1 Below 1
REPAIR OR REPLACE HARNESS OR
CONNECTOR (ENGINE COOLANT
TEMPERATURE SENSOR - ECM)
Page 451 of 3000

2GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEMES–145
ES
NG
(a) Disconnect the E12 ECT sensor connector.
(b) Connect the intelligent tester to the DLC3.
(c) Turn the ignition switch to the ON position.
(d) Turn the tester on.
(e) Select the following menu items: DIAGNOSIS /
ENHANCED OBD II / DATA LIST / PRIMARY /
COOLANT TEMP.
(f) Read the value displayed on the tester.
Standard:
-40
C (-40F)
(g) Reconnect the ECT sensor connector.
OK
NG
(a) Disconnect the E12 ECT sensor connector.
(b) Disconnect the E9 ECM connector.
(c) Measure the resistance according to the value(s) in the
table below.
Standard resistance
(d) Reconnect the ECT sensor connector.
(e) Reconnect the ECM connector.
OK REPLACE ECM (See page ES-498)
4READ VALUE OF INTELLIGENT TESTER (CHECK FOR SHORT IN WIRE HARNESS)
A084869E98
REPLACE ENGINE COOLANT
TEMPERATURE SENSOR (See page ES-516)
5CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR -
ECM)
A162492E02
Tester Connection Specified Condition
THW (E9-21) or E12-2 - Body ground 10 k
or higher
REPAIR OR REPLACE HARNESS OR
CONNECTOR (ENGINE COOLANT
TEMPERATURE SENSOR - ECM)
Page 452 of 3000
ES–1462GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
NG
REPLACE ECM (See page ES-498)
Page 453 of 3000

2GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEMES–147
ES
DESCRIPTION
Refer to DTC P0115 (See page ES-133).
MONITOR DESCRIPTION
The ECT sensor is used to monitor the ECT. The ECT sensor has a built-in thermistor with a resistance
that varies according to the temperature of the engine coolant. When the ECT becomes low, the
resistance of the thermistor increases. When the temperature becomes high, the resistance drops. These
variations in the resistance are reflected in the voltage output from the ECT sensor.
The ECM monitors the sensor voltage and uses this value to calculate the ECT. If the sensor voltage
output deviates from the normal operating range, the ECM interprets this deviation as a malfunction in the
ECT sensor and sets the DTC.
Examples:
• Upon starting the engine, the ECT is between 35
C and 60C (95F and 140F). If the ECT remains
within 3
C (5.4F) of the stating temperature after driving for 250 seconds, the DTC is set (2 trip
detection logic).
• Upon starting the engine, the ECT is over 60
C (140F). If the ECT remains within 1C (1.8F) of the
starting temperature after driving for 250 seconds, the DTC is set (6 trip detection logic).
MONITOR STRATEGY
DTC P0116Engine Coolant Temperature Circuit Range /
Performance Problem
DTC No. DTC Detection Condition Trouble Area
P0116ECTs as listed below are nearly same (2 trip detection
logic):
– ECT when engine is started at lower than 60
C
(140
F) of ECT
– ECT when engine is warmed up
•Thermostat
• ECT sensor ECTs as listed below are nearly same when engine is
started at higher than 60
C (140F) of ECT (2 trip
detection logic)
– ECT when engine is stopped after driving
– ECT when engine is started at lower than 60
C
(140F) of ECT
When either of following conditions is met (2 trip
detection logic):
• When cold engine started and engine warmed up,
Engine Coolant Temperature (ECT) sensor value
does not change
• After engine is warmed up, ECT sensor value does
not change when engine stopped and then next
cold engine start is performed
Related DTCsP0116: Engine coolant temperature sensor output stuck at low engine coolant
temperature
P0116: Engine coolant temperature sensor output stuck at high engine coolant
temperature
Required Sensors / Components (Main) Engine Coolant Temperature (ECT) sensor
Required Sensors / Components (Related) Crankshaft position sensor, intake air temperature sensor and mass air flow meter
Frequency of Operation Continuous
Duration 5 hours
MIL Operation 2 driving cycles
Sequence of Operation None
Page 454 of 3000

ES–1482GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
TYPICAL ENABLING CONDITIONS
All:
ECT sensor cold start monitor:
ECT sensor soak monitor:
TYPICAL MALFUNCTION THRESHOLDS
ECT sensor cold start monitor:
ECT sensor soak monitor:
COMPONENT OPERATING RANGE
INSPECTION PROCEDURE
HINT:
• If any of DTC P0115, P0117, P0118 or P0125 are set simultaneously with DTC P0116, the ECT sensor
may have an open or a short circuit. Troubleshoot those DTCs first.
• Read freeze frame data using the intelligent tester. The ECM records vehicle and driving condition
information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame
data can be helpful in determining whether the vehicle was running or stopped, whether the engine
was warmed up or not, whether the air-fuel ratio was lean or rich, as well as other data recorded at the
time of a malfunction.
(a) Connect the intelligent tester to the DLC3.
(b) Turn the ignition switch to the ON position.
(c) Turn the tester on.
(d) Enter the following menus: DIAGNOSIS / ENHANCED II
/ DTC INFO / CURRENT CODES.
(e) Read the DTC.
Monitor will run whenever these DTCs are not present. P0100, P0102, P0103 (MAF Sensor)
Battery voltage 10.5 V or more
Time after engine start 1 second or more
ECT at engine start Less than 60
C (140F)
IAT sensor circuit OK
Soak time 5 hours or more
Accumulated MAF 1421.2 g or more
Engine Running
Fuel cut OFF
Difference between ECT at engine start and IAT Less than 40
C (72F)
Battery voltage 10.5 V or more
Engine Running
Soak time 5 hours or more
ECT at engine start 60
C (140F) or more
Accumulated MAF 3298.1 g or more
ECT sensor value change Less than 5
C (9F)
ECT sensor value change Less than 5
C (9F)
Engine coolant temperature Varies with actual engine coolant temperature
1CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0166)
Page 455 of 3000
2GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEMES–149
ES
Result
B
A
(a) Remove the thermostat (See page CO-16).
(b) Check the valve opening temperature of the thermostat.
Standard:
80 to 84
C (176 to 183F)
HINT:
In addition to the above check, confirm that the valve is
completely closed when the temperature is below the
standard.
(c) Reinstall the thermostat (See page CO-17).
NG
OK
Display (DTC output) Proceed to
P0116 A
P0116 and other DTCs B
GO TO DTC CHART
2INSPECT THERMOSTAT
REPLACE THERMOSTAT
REPLACE ENGINE COOLANT TEMPERATURE SENSOR
Page 456 of 3000

ES–1502GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
DESCRIPTION
The ECM calculates the difference between the readings of the coolant temperature sensor and intake air
temperature sensor. If the difference is greater than 20
C (68F), the ECM will judge this as a malfunction
and will set this DTC.
HINT:
• Waiting is required to prevent the temperature of the engine from affecting the readings. If the engine
has been operated recently, it will not be possible to accurately compare the readings.
• For diagnosis, in order to duplicate the detection conditions of the DTC, it is necessary to park the
vehicle for 7 hours. Parking the vehicle for 7 hours ensures that the actual temperature of the ECT and
IAT are very similar. When the vehicle has been parked for less than 7 hours, differences in the
readings may exist, this does not necessarily indicate a fault.
DTC P011BEngine Coolant Temperature / Intake Air Tem-
perature Correlation
DTC No. DTC Detection Condition Trouble Area
P011BWhen conditions (a), (b), (c), (d) and (e) are met (2 trip
detection)
(a) Battery voltage is 10.5 V or more
(b) 37.5 seconds after the engine has been started after
the ignition switch has been OFF for more than 7 hours
(c) The minimum intake air temperature after the engine
has been started is more than -10
C (14F)
(d) The average coolant temperature before the engine
is started is more than -10
C (14F)
(e) The difference between the readings of the ECT and
IAT is greater than 20
C (36F)•IAT sensor
• ECT sensor
•ECM
